Summary of Contents for Costway SP36172
- Page 3 Φ WASHER PHONE HOLDER Φ WASHER DOMED NUT M8 LEVEL FOOT LOCK NUT(L/R)
- Page 4 Anti-Clockwise Clockwise a. A pair of Pedals (23/ 24) has a sign, "L" is the left pedal, and "R" is the right pedal. b. Loosen nuts on Pedals (23/ 24). Connect Pedals (23/ 24) to Cranks (21/ 22) as shown in above diagram.
- Page 5 a. Loosen PULL PIN KNOB (28) and pull out, insert Seat Post (5) into the rear opening tube of the Main Frame (1). Adjust the Seat Post (5) to your desired height, then tighten the PULL PIN KNOB (28). a. Insert Handlebar Post (6) into the front opening tube b.
-
Page 6: Level Adjustment
Vertical Seat Adjustment To adjust the seat height, slacken Pull Pin Knob on the vertical post stem on the main frame and pullback the knob. Position the vertical seat post for the desired height so that holes are aligned, then release the knob and retighten it. Horizontal Seat Adjustment To move the seat forward in the direction of the handlebar or backwards away from it, loosen the O ctagonal Knob and washer and pull the knob back. - Page 7 -clip to...
