RE934ZT Translator & Z-Wave Expansion Card
capabilities to the system enabling control of 3
also includes a wireless sensor translator for the takeover of existing sensors
in the home.
Features
• Enables the system to create a new, or join an
existing, Z-Wave network
• Provides communication with Z-Wave devices
enabling a broad range of home automation
features
• Allows Connect+ to receive Interlogix
GE
), Honeywell
®
wireless sensors reducing takeover cost and
installation time
• Dual antennas for reliable sensor range
Installation
Ensure Connect+ firmware version is 1.1.20.0 or greater before proceeding
STOP
1. Disarm Connect+ and disconnect the power cord.
2. Remove Connect+ cover and then disconnect the battery cord.
3. Install the RE934ZT into expansion slot 3 of Connect+.
• Carefully align the 8 pin
connector and the nylon
retention posts.
• Firmly push on each
corner of the card until
the posts are fully seated.
4. Hook the lower antenna beneath
the retention tab in the housing.
5. Reconnect the battery cord and
reinstall the cover.
6. Reconnect the power cord.
7. Configure the RF Translator
protocol using the AlulaConnect
Dealer Portal or the Installer App.
RF Translator Protocol Options:
• None (Default setting)
• GE
• DSC
• HW (Honeywell)
• 2GIG
• NAPCO
8. Enroll sensors following the protocol and device type instructions that follow.
, 2GIG
, Napco
, or DSC
®
®
®
RE934ZT Translator & Z-Wave
Connect+
Expansion Card
™
adds home automation
party Z-Wave devices. It
rd
(formerly
®
®
I
®
Antenna
Retention
Tab
