RE934ZT Translator and Zwave Expansion Card
Features
• Expansion Card that plugs into the Connect+ Panel
• Provides communications with Z-Wave devices enabling a broad range of
home automation features
• Enables system to receive signals from Honeywell, 2GIG, GE, Napco & DSC sensors
• All sensor alarm, supervisory and trouble signals are reported
• Dual antennas for reliable range
Installation
• Power down the Panel:
• Open cover
• Unplug battery cord
• Unplug the power cord
• Insert the RE934ZT into expansion slot 3 of the Control Panel, gently
inserting the connector and snapping the stand-offs into place
• Connect battery cord, plug the power, and close the cover to the panel
Battery
Cord
Plug
Enrollment
47-0052-00_Rev A00 Tech Support Line: (888) 88-ALULA (888) 882-5852
Expansion
Slot
3
RE934ZT_Translator and Z Wave Expansion Card
alula.net
Power
Cord
Plug
RE934ZT
Installed
in panel
Advertisement
Table of Contents
Related Manuals for Alula RE934ZT
Summary of Contents for Alula RE934ZT
- Page 1 • Unplug battery cord • Unplug the power cord • Insert the RE934ZT into expansion slot 3 of the Control Panel, gently inserting the connector and snapping the stand-offs into place • Connect battery cord, plug the power, and close the cover to the panel...
- Page 2 PIR & Glass break: Open and close the cover of the sensor ◦ Key fobs: Press the Aux2 (Panic) button ◦ Panic: Napco Panic is not supported by the translator ◦ Enrolling 2GIG Devices RE934ZT_Translator and Z Wave Expansion Card 47-0052-00_Rev A00 Tech Support Line: (888) 88-ALULA (888) 882-5852 alula.net...
- Page 3 OFF – When panel does not have AC power Flickers – With each sensor packet received Red LED: Normally Off, flashes with each Zwave message received from panel RE934ZT_Translator and Z Wave Expansion Card 47-0052-00_Rev A00 Tech Support Line: (888) 88-ALULA (888) 882-5852 alula.net...
-
Page 4: Specifications
Specifications subject to change without notice. Notices Warranty Alula will replace products that are defective in their first five (5) years. FCC Notice This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: This device may not cause harmful interference.
