Gree G17-14ESCWAC1 Owner's Manual

Gree G17-14ESCWAC1 Owner's Manual

Window air conditioner
Hide thumbs

Advertisement

Quick Links

Download this manual
Owner's
Manual
Window
Air Conditioner
G17-14ESCWAC1
Write the model and serial numbers below for your records:
Model #
Serial #
Date Purchased
Please read the entire manual carefully to
ensure proper operation of the product.
To find an electronic version of this manual,
please visit www.greeproducts.com
Phone: 1-866-658-0466
Email: customerservice@greeproducts.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the G17-14ESCWAC1 and is the answer not in the manual?

Questions and answers

Related Manuals for Gree G17-14ESCWAC1

Summary of Contents for Gree G17-14ESCWAC1

  • Page 1 Owner’s Manual Window Air Conditioner G17-14ESCWAC1 Write the model and serial numbers below for your records: Model # Serial # Date Purchased Please read the entire manual carefully to ensure proper operation of the product. To find an electronic version of this manual, please visit www.greeproducts.com...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS PAGE IMPORTANT SAFETY INFORMATION ....................3-4 INSTALLATION INSTRUCTIONS ......................5-17 OPERATING INSTRUCTIONS ......................18-21 CLEANING & MAINTENANCE ......................22-23 BEFORE YOU CALL ........................24-26 WARRANTY ............................27 NOTICE: Pictures within this manual are for reference only. Please refer to the actual product for the appearance.

  • Page 3: Important Safety Information

    SAFETY INFORMATION SYMBOL INDICATES A HAZARDOUS SITUATION WHICH IF NOT AVOIDED COULD RESULT IN SERIOUS INJURY OR DEATH. Please read and understand this entire manual before attempting to assemble, operate or install your window air conditioner unit. Use this air conditioner only as instructed in this manual. While this manual covers a wide variety of troubleshooting, the instructions are not meant to cover every situation that may occur.
  • Page 4 SAFETY INFORMATION SAFETY INFORMATION Electrical Information The power cord with this air conditioner contains a current detection device designed to reduce the risk of fire. Please refer to the section “operation of current device” for details. In the event that the power cord is damaged, it cannot be repaired. It must be replaced with a power cord from the product manufacturer.

  • Page 5: Installation Instructions

    INSTALLATION INSTRUCTIONS INSTALLATION INSTRUCTIONS Before You Begin CAUTION When handling the unit be careful to avoid cuts from any sharp metal edges and the aluminum fins on the front / rear coils. IMPORTANT : Save these instructions for future reference. Product failure due to any improper installation is not covered under the One Year Limited Warranty.
  • Page 6 INSTALLATION INSTRUCTIONS Where to Install the Unit • Ensure there is no obstruction near the air-inlet or air-outlet. • Select a window where the condensation water can be dispersed easily out the back of the unit and won’t affect others. •...
  • Page 7 INSTALLATION INSTRUCTIONS Parts and Tools Needed Upper Guide Rail Location* Air-Outlet Frame Control Panel Fan Direction Adjusting Rod Air-Inlet Panel Phillips screwdriver Screwdriver Power Cord Power Plug *Upper guide rail may be attached on some units Parts List Level bar Scissors Pencil Measuring tape...
  • Page 8 INSTALLATION INSTRUCTIONS Preparing Unit and Case Pull down the Front Panel slightly, and lift panel Remove Filter. upwards to remove. Screw Front Case Screws Remove 4 Screws from Front Frame. Grasp the lower corners of the Front Frame while Set aside, you will need later during pressing in on the sides with your fingertips.
  • Page 9 INSTALLATION INSTRUCTIONS Outer Case Remove 1 Grounding Screw from side of Outer Case. Note: Set aside the Grounding Screw in a safe location. You will need it later during the installation. Grounding Screw Main Unit Do NOT pull or lift in this area. Pull the main unit from outer case by griping the Damage to the unit may result! base pan handle.
  • Page 10 INSTALLATION INSTRUCTIONS Upper Guide Rail Upper Guide Rail Remove Mounting backing from seal Rail Seal strip Strip Lower Guide Rail A) To install the Upper Guide Rail, peel off B) Use 4 Type A Screws to attach the Upper Guide the back side of the Top Mounting Rail Seal Rail onto the outer case of the air conditioner unit.
  • Page 11 INSTALLATION INSTRUCTIONS Upper Guide Rail Upper Guide Rail Flexible Screen Left Right Lower Guide Rail Slide the upper and lower ends of the Flexible Screen Frame into the Upper and Lower Guide Rails. Attach Side Rails to Outer Case using 6 Type A Screws.
  • Page 12 INSTALLATION INSTRUCTIONS Preparing Window and Installing Case To install the Window Sill & Sash Seal, cut the seal to fit the length of the window. Peel off the backing, and attach to window sash and window sill. Sash Window Sill & Note: To install the air conditioner onto Sash Seal the window sill, it is recommended to use 2...
  • Page 13 INSTALLATION INSTRUCTIONS outer case type E screw Type E Bolt w/Nut supporter Left V-Support Place the V-Supports underneath the Outer Case on left and right sides, at Window Sill, near outside wall. Attach V-Supports to each side of bottom of case with 2 Type E Bolts w/Nuts, 2 for each support. Note: Ensure placement of V-Supports will bear the weight of window unit.
  • Page 14 INSTALLATION INSTRUCTIONS Extend the left and right to the Window Flexible Panels Sashes. Type C Screw Attach top corners with 2 Type Type C C Screws Screw Note: In order to prevent the window sill from splitting drive the pilot holes before inserting the screws.
  • Page 15 INSTALLATION INSTRUCTIONS Installing Unit In Outer Case Note: To install the air conditioner onto the window sill, it is recommended to use 2 PEOPLE. Slide the Main Unit slowly into the Outer Case by the Base Pan. Make sure the unit is firmly seated Note: Do NOT push on the controls, styrofoam air discharge housing or the finned coils.
  • Page 16 INSTALLATION INSTRUCTIONS A) Attach the Front Frame to the Outer Case Replace 4 Screws removed in Step 2. by inserting the tabs into slots on the top of Outer Case. B) Push bottom of Front Frame in until secure. A) Install the Filter B) Replace Front Panel.
  • Page 17 Width Width After finishing installation, measure the width between Note: Be sure to measure each screen, as the outer case of the air conditioner and the window the length could be different on each side. frame (see Figure 10, length). Width A) Locate both pieces of the Foam Insulation from B) Remove adhesive from back of Foam Insulation.

  • Page 18: Operating Instructions

    OPERATING INSTRUCTIONS Features of Your Window Air Conditioner i-Feel LCD Remote Control The remote acts as a separate thermostat for enhanced comfort. The mini thermostat in the remote control can sense its surrounding temperature and transmit the signal back to the unit. The unit will cool the room until the desired temperature is met at the location of the remote.
  • Page 19 OPERATING INSTRUCTIONS Function & Control Display Light indicates the unit is in the temperature or delay Time Set Mode Temp/Time Cooling indicator Filter Check Cool Auto Auto speed indicator SE indicatorfan Energy Saver High High speed indicator Timer Fan Only Medium speed indicator Fan indicator Low speed indicator...
  • Page 20 OPERATING INSTRUCTIONS OPERATING INSTRUCTIONS Remote Control Operation NOTICE: • The distance between remote and receiving window should be no more than 8 m (26 ft.), and there should be no obstacles between them. • When not using the remote control for extended periods of time, please take out the batteries.
  • Page 21 OPERATING INSTRUCTIONS Air Flow Adjustment Adjust the air frame left or right to direct the air flow according to the user’s preference. Air outlet frame Adjust the air frame up or down to direct the air flow according to the user’s preference. NOTICE: This picture is for reference only.

  • Page 22: Cleaning & Maintenance

    CLEANING AND MAINTENANCE WARNING • Turn off the air conditioner and disconnect the power cord from outlet before cleaning the air conditioner to avoid electric shock. • Do NOT wash the air conditioner with water to avoid electric shock. • Do NOT use harsh cleansers to clean the air conditioner. •...
  • Page 23 CLEANING AND MAINTENANCE Remote Control Battery Replacement AAA Battery Signal Sender Reinstall Remove Battery Cover Replacement of Batteries in Remote Control 1. Press the back side of remote control marked with OPEN, as shown in the figure, and then push out the BATTERY COVER of battery box along the arrow direction.

  • Page 24: Before You Call

    BEFORE YOU CALL WARNING If the below errors occur, please turn off the air conditioner and disconnect the power cord from the outlet immediately. Please contact Customer Service at once. • Power cord is overheating or damaged. • Abnormal sound during operation. •...
  • Page 25 BEFORE YOU CALL Malfunction Code If any of the following Malfunction Codes appear, please call Customer Service. MALFUNCTION CODE SOLUTION Please contact Customer Service. IF THESE SOLUTIONS FAIL, PLEASE CALL 1-866-658-0466 FOR GREE CUSTOMER SERVICE...
  • Page 26 (26 ft.) of the unit. Remote sensing deactivating (some models) Remote control signal is obstructed- remove any item blocking front of unit. Low batteries. Replace batteries on remote control. IF THESE SOLUTIONS FAIL, PLEASE CALL 1-866-658-0466 FOR GREE CUSTOMER SERVICE...

  • Page 27: Warranty

    Air Conditioner unit. This warranty does not cover, and is not intended to exclude any liability on the part of GREE, whether under this warranty or implied by law for any indirect or consequential damages for breach of warranty.
  • Page 28 Gree Customer Service Hours: 9am–5pm CST Monday–Friday Phone: 1-866-658-0466 Email: customerservice@greeproducts.com Website: www.greeproducts.com M110516-14ECWAC...
