Economy Cold Frames
Photo may show a different but similar model. Frame is shown with optional cover.
GrowSpan
™
STK#
DIMENSIONS
105163F
8' W x 7' H x 10' L
105164F
8' W x 7' H x 15' L
105165F
8' W x 7' H x 20' L
105166F
8' W x 7' H x 25' L
105167F
8' W x 7' H x 30' L

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 105163F and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for GrowSpan 105163F

Summary of Contents for GrowSpan 105163F

  • Page 1 ™ Economy Cold Frames Photo may show a different but similar model. Frame is shown with optional cover. STK# DIMENSIONS 105163F 8' W x 7' H x 10' L ©2016 GrowSpan 105164F 8' W x 7' H x 15' L All Rights Reserved.

  • Page 2: Safety Precautions

    GROWSPAN ECONOMY COLD FRAMES ™ LOCATION Choosing the proper location is an important step before you begin to assemble the structure. The following suggestions and precautions will help you determine whether your selected location is the best location. • Never erect the structure under power lines.

  • Page 3: Assembly Procedure

    These words and phrases are common to most GrowSpan™ shelters and identify the different parts of • Tek Screw: A self-tapping fastener used to secure pipe the shelter.

  • Page 4: Required Tools

    GROWSPAN ECONOMY COLD FRAMES ™ SPECIAL NOTE: Baseboard Installation Procedure REQUIRED TOOLS These instructions describe installing a baseboard The following list identifies the main tools needed to (recommended) at ground level along each side of the assemble the shelter. Additional tools and supports may be frame.
  • Page 5 GROWSPAN ECONOMY COLD FRAMES ™ The following diagrams and photos will help you identify the different parts and show you how they are used. (Not all parts are shown.) FA4482B Tek Screw 104545 QH1070 105108 Post Driver Pipe Strap Cross Connector...
  • Page 6 GROWSPAN ECONOMY COLD FRAMES ™ GrowSpan ™ Economy Cold Frames OVERVIEW This section describes assembling your cold frame. For details of each assembly procedure, consult the individual sections of these instructions. See illustration below to identify main parts of the cold frame.
  • Page 7 GROWSPAN ECONOMY COLD FRAMES ™ LAY OUT THE BUILDING SITE 8. After all corner posts are accurately installed, tie a string line between the tops of the corner ground posts After the site is prepared, lay out the building site.

  • Page 8: Rafter Assembly

    GROWSPAN ECONOMY COLD FRAMES ™ ASSEMBLING THE FRAME COMPONENTS 3. With the main rafter pipes seated at each joint and the rafter positioned on a flat surface, secure each joint NOTE: Assistance is required to assemble the frame. using a single self-tapping Tek screw. Position Tek RAFTER ASSEMBLY screws approximately 1"...

  • Page 9: Frame Assembly

    GROWSPAN ECONOMY COLD FRAMES ™ INTERIOR RAFTER ASSEMBLY FRAME ASSEMBLY Gather the parts: 1. Select the three (3) pipes needed to assemble an interior rafter and arrange these on a flat surface for • All rafter assemblies assembly. • 1.05" purlin pipes 2.
  • Page 10 GROWSPAN ECONOMY COLD FRAMES ™ FRAME ASSEMBLY (CONTINUED) 8. Move to the second rafter and verify that the rafter spacing is 5' on-center. 3. Carefully position the first interior rafter in place and secure the leg pipes to the ground posts as previously NOTE: Verify that the rafter is plumb front-to-back and described.
  • Page 11 GROWSPAN ECONOMY COLD FRAMES ™ INSTALLING THE COVER FILM (Sku numbers ending in FINISH ROUGH EDGES FF include the cover film. Additional purchase is required Gather the parts: for all other skus.) • Duct tape (supplied by customer) NOTE: Assistance is required to install the cover.
  • Page 12 GROWSPAN ECONOMY COLD FRAMES ™ COVER FILM INSTALLATION 3. Repeat these steps for the remaining end rafter. After the frame is assembled and the baseboards are 4. After attaching the poly latch U-channel to the tops of attached to the frame, the cover is installed.
  • Page 13 GROWSPAN ECONOMY COLD FRAMES ™ COVER FILM INSTALLATION (CONTINUED) 4. Once the main cover is in place and centered on the frame, begin at the peak of one end rafter and install Install the Cover Film the wire spring into the U-channel to secure the cover.
  • Page 14 GROWSPAN ECONOMY COLD FRAMES ™ COVER INSTALLATION (CONTINUED) SHELTER CARE AND MAINTENANCE Proper care and maintenance of the shelter is important. NOTE: Maintain an even length along the side. The Check the following items periodically to properly maintain final stretching of the cover takes place when the last the shelter: side is secured.
  • Page 15 GROWSPAN ECONOMY COLD FRAMES ™ 8' Wide Cold Frames 105163F (8' x 10') 105164F (8' x 15') 105165F (8' x 20') 105166F (8' x 25') 105167F (8' x 30') Revision date: 01.01.16...
  • Page 16 GROWSPAN ECONOMY COLD FRAMES ™ 8' Wide Cold Frames with covers (FF skus only) 105163FF (8' x 10') 105164FF (8' x 15') 105165FF (8' x 20') 105166FF (8' x 25') 105167FF (8' x 30') Revision date: 01.01.16...
  • Page 17 GROWSPAN ECONOMY COLD FRAMES ™ This page is reserved for customer notes. Revision date: 01.01.16...
