Steinbach PSS1011 Instruction

1.Child Lock(1pcs)
2.Switch Valve(1pcs)
3.Gasket(4pcs)
4.Shower Head(1pcs)
5.Gasket(1pcs)
6.Nut(1pcs)
7.Shower Gasket(1pcs)
8.Shower Head Connector(1pcs)
9.Hose Connector(1pcs)
10.Pole w/Small Screw(2pcs)
11.Pole w/Large Screw(1pcs)
Fig. 1
Put the gasket into
Hose Connector
and Switch Valve
and turn right to
2
tighten them.
3
9
Fig. 2
Put the gasket into two
poles(10) and turn right
to tighten them.
10 3
Fig. 4 Fig. 4
4
6
8
5
Fig. 6
a.Insert the Child lock into the fixer.
b.Turn the Child lock right and tighten it.
Fig. 8
Turn clockwise to open it and turn anticlockwise to close it. Note: When close Switch Valve , please
check if it is in the right location, or the seal performance will be impacted.
1
2
3
4
5
A
10
Fig. 3
11
3
Fig. 5
7
Clip the fixer to the
ladder pole, and
Choose an angle
and direction you
want, then press
down the handle on
the fixer to lock the
direction.
11
Fig. 7
1
LADDER TUBE
Close location point
6
7
10
8
9
Put the gasket into
Pole (10) and Switch
Valve and turn right
to tighten them.
3
Put the gasket into
pole(10) and pole(11)
and turn right to
tighten them.
10
LOCK
UNLOCK
LADDER TUBE
11
11
10
10
Fig. 9
