SHRED 'N' VAC
Operator's Manual
MODEL
Read rules for safe operation and all instructions carefully. ECHO provides this
Operator's Manual which must be read and understood for proper and safe
operation.
X7501138801
®
ES-231
Serial Number 02001001 - 02999999
WARNING
DANGER
X750001241
03/01

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 02001001 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Echo 02001001

Summary of Contents for Echo 02001001

  • Page 1 SHRED 'N' VAC Operator's Manual MODEL ES-231 Serial Number 02001001 - 02999999 WARNING DANGER Read rules for safe operation and all instructions carefully. ECHO provides this Operator's Manual which must be read and understood for proper and safe operation. X7501138801 X750001241 03/01...

  • Page 2: Table Of Contents

    NTRODUCTION Welcome to the ECHO family. This ECHO product was designed and manufactured to provide long life and on-the-job- dependability. Read and understand this manual. You will find it easy to use and full of helpful operating tips and SAFETY messages.

  • Page 3: Manual Safety Symbols And Important Information

    If a decal cannot be read, a new one can be ordered from your ECHO dealer. See PARTS ORDERING instructions for specific information. P/N 89016006361...

  • Page 4: International Symbols

    Parts • Do not use blower if any part is missing or damaged. • Have repairs done only by an authorized ECHO Service dealer. ATTACHMENTS • Do not use any attachment, accessory or replacement part unless it is recommended in this Operator's Manual.

  • Page 5: Fuel

    IMPORTANT Spilled fuel is a leading cause of hydrocarbon emissions. Some states may require the use of automatic fuel shut-off containers to reduce fuel spillage. Contact your ECHO dealer for ordering information. After Refueling; • Wipe any spilled fuel from the unit.
  • Page 6 Breathing Protection -- Wear a face mask to protect against dust. Hearing Protection -- ECHO recommends wearing hearing protection whenever unit is used. Proper Clothing -- Wear snug fitting, durable clothing; • Pants should have long legs, shirts with long sleeves.

  • Page 7: Safe Operation

    ® 'N' V HRED PERATOR ANUAL SAFE OPERATION Determine Operation Area -- • Do not operate this product indoors or in inadequately ventilated areas. • Review area to be cleared. Look for potential hazards such as stones or metal objects. •...

  • Page 8: Extended Operation/Extreme Conditions

    EXTENDED OPERATION EXTREME CONDITIONS Vibration and Cold -- It is believed that a condition called Raynaud’s Phenomenon, which affects the fingers of certain individuals may be brought about by exposure to vibration and cold. Exposure to vibration and cold may cause tingling and burning sensations followed by loss of color and numbness in the fingers.

  • Page 9: Description

    1 - SHRED 'N' VAC Suction Tube 1 - Elbow Pipe 1 - Debris Bag 1 - Operator's Manual 1 - Warranty Registration Card 1 - ECHO Emissions and Warranty Statement 1 - T-Wrench 1 - Bottle ECHO 2-Stroke Oil Mix...
  • Page 10 1. STOP SWITCH - "SLIDE SWITCH" mounted on top of handle. Push forward to start and run. Slide back to stop. 2. THROTTLE TRIGGER - Spring loaded to return to idle when released. During acceleration, press trigger gradually for best operating technique. 3.

  • Page 11: Specifications

    ® 'N' V HRED PERATOR ANUAL PECIFICATIONS . n i . n i n i l n i l t i n t i c t i n l f f n i l ) l i n i l y t i .

  • Page 12: Assembly

    SSEMBLY WARNING DANGER Never perform maintenance or assembly procedures with engine running or serious personal injury may result. BLOWER APPLICATION Install Blower Pipes 1. Align grooves in straight pipe with pegs on blower housing and slide pipe onto housing. 2. Turn straight pipe clockwise to lock into place. 3.
  • Page 13 ® 'N' V HRED PERATOR ANUAL 4. Remove blower pipe assembly from unit. 5. Align grooves in vacuum elbow with pegs on blower housing and install vacuum elbow. 6. Turn vacuum elbow counter-clockwise to lock it into place. 7. Place debris bag opening over end of vacuum elbow and secure with velcro strap (D).

  • Page 14: Pre-Operation

    50:1 oil meets these standards. Engine problems due to inadequate lubrication caused by failure to use an ISO-L-EGD and J.A.S.O. FC certified oil, such as Echo Premium 50:1 Two-stroke Oil, will void the two-stroke engine warranty. (Emission related parts only are covered for two years, regardless of two-stroke oil used, per the statement listed in the California Emission Defect Warranty Explanation.)

  • Page 15: Operation

    ANUAL IMPORTANT Spilled fuel is a leading cause of hydrocarbon emissions. Some states may require the use of automatic fuel shut-off containers to reduce fuel spillage. Contact your ECHO dealer for ordering information. After Refueling - • Wipe any spilled fuel from the unit.

  • Page 16: Starting Cold Engine

    STARTING COLD ENGINE 1. Stop Switch - Start/Run. Move stop switch button (A) away from the STOP position. 2. Move throttle position lever (B) midway between idle and full throttle positions. 3. Close Choke - Cold Start. Move choke (C) to "Cold Start" Position. 4.

  • Page 17: Starting Warm Engine

    2. Move stop switch (A) to "STOP" position. WARNING DANGER If engine does not stop when stop switch is moved to STOP position, close choke - COLD START position - to stall engine. Have your ECHO dealer repair stop switch before using blower again.

  • Page 18: Operating Blower Shred Nvac

    ® OPERATING BLOWER SHRED WARNING DANGER Always wear safety glasses, hearing protection and a face filter mask or serious personal injury may result. . Do not point the blower pipe in the direction of people or pets. Never operate unit without either housing cover grill or vacuum tube installed on unit securely, otherwise bodily harm may result.

  • Page 19: Maintenance

    ECHO Service Dealer for maintenance. To help you decide whether you want to DO-IT-YOURSELF or have the ECHO Dealer do it, each maintenance task has been graded. If task is not listed, see your ECHO Dealer for repairs.

  • Page 20: Air Filter

    AIR FILTER Level 1. Tools required: 25-50 mm (1-2 in.) medium bristle brush. Parts required: 90030 REPOWER Air and Filter Kit NOTE Clean daily. 1. Close choke (Cold Start Position). This prevents dirt from entering the carburetor throat when the air filter is removed. Brush accumulated dirt from the air cleaner area.

  • Page 21: Spark Plug

    ® 'N' V HRED PERATOR ANUAL SPARK PLUG Level 2. Tools required: 3/4 in. Spark Plug deep socket, Feeler gauge (preferably a wire gauge), Parts Required: 90065 REPOWER Tune-Up Kit 1. Remove spark plug and check for fouling, worn and rounded center electrode.

  • Page 22: Exhaust System

    Cleaning Cylinder Fins 1. Remove four 3 mm hex screws, side handle and recoil starter. 2. Remove engine cover (four screws), pull cover away from engine. Clean cylinder fins to allow cooling air to pass freely. 3. Loosely reassemble engine cover then recoil starter and side handle.

  • Page 23: Shredder Blade

    The cylinder exhaust port must be inspected and cleaned of excess carbon every 3 months or 90 hours of operation in order to maintain this engine within the emissions durability period. ECHO strongly recommends that you return your unit to your ECHO dealer for this important maintenance service. SHREDDER BLADE Level 1.

  • Page 24: Debris Bag

    High Altitude Adjustment High altitude adjustment is not required for proper operation of this engine. Level 2. Tools required: Screwdriver, tachometer (Echo P/N 99051130017) Parts required: none. NOTE Every unit is run at the factory and the carburetor is set in compli- ance with California Emission Regulations.

  • Page 25: Troubleshooting

    ® 'N' V HRED PERATOR ANUAL ROUBLESHOOTING l f f t l i t l i t l i . l l WARNING DANGER Fuel vapors are extremely flammable and may cause fire and/or explosion. Never test for ignition spark by ground- ing spark plug against cylinder, otherwise serious personal injury may result.

  • Page 26: Storage

    7. Remove the spark plug and pour 7cc (1/4 oz., 1/2 tablespoon) of fresh, clean ECHO 2-stroke engine oil into the cylinder through the spark plug hole. A. Place a clean cloth over the spark plug hole.
  • Page 27 ® 'N' V HRED PERATOR ANUAL NOTES...

  • Page 28: Servicing Information

    • Sending a check or money order for $2.00 per Parts Catalog or $1.50 per Operator's Manual made payable to ECHO, INCORPORATED. State on a sheet of paper the model number and serial number of the ECHO unit you have, part number of the manual (if known), your name and address and mail to address below.
