sauder.com
Media Console with Fireplace
Carson Forge Collection | 418135
Need help? Visit Sauder.com to view video assembly tips or chat with a live rep.
Prefer the phone? Call 1-800-523-3987.
Share your journey!
Your center of
attention.
NOTE: THIS INSTRUCTION
BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION.
PLEASE READ AND KEEP FOR
FUTURE REFERENCE.
English pg 1-22
Français pg 23-25
Español pg 26-28
Lot # 364573
09/12/14
Purchased: __________________
Be sure to give us a ring before
making any returns. 1-800-523-3987
Advertisement
Related Manuals for Sauder Carson Forge 418135
Summary of Contents for Sauder Carson Forge 418135
- Page 1 Carson Forge Collection | 418135 NOTE: THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. Need help? Visit Sauder.com to view video assembly tips or chat with a live rep. PLEASE READ AND KEEP FOR FUTURE REFERENCE. Prefer the phone? Call 1-800-523-3987.
- Page 2 • Check the size and weight of your TV. Compare it to the diagram below – before you begin assembly! • This Sauder unit is designed for use with televisions weighing less than 95 pounds. Never use with a TV that weighs more.
- Page 3 SKIRT BRACE (2) TOP RIGHT MOLDING (1) BOTTOM (1) LONG BRACE (1) SHELF MOLDING (1) SHELF (1) SHORT BRACE (1) UPRIGHT MOLDING (1) HEARTH (1) SKIRT (1) 69M FIREPLACE INSERT (1) LARGE BACK (1) BOWED SKIRT (1) www.sauder.com/services 418135 Page 3...
- Page 4 BLACK 1-7/8" FLAT HEAD SCREW - 14 BLACK 1/2" FLAT HEAD SCREW - 8 102S SILVER 1" LARGE HEAD SCREW - 4 BLACK 2-1/4" FLAT HEAD SCREW - 17 SILVER 1-1/4" PAN HEAD SCREW - 4 Page 4 418135 www.sauder.com/services...
- Page 5 Look for this icon. It means a Step 1 video assembly tip is available at www.sauder.com/services/tips Assemble your unit on a carpeted fl oor or on the empty å carton to avoid scratching your unit or the fl oor. Push nineteen HIDDEN CAMS (1F) into the ENDS (A and B) å...
- Page 6 NOTE: Be sure the BRACKETS are even with the edges of å the ENDS, SMALL UPRIGHT, BOTTOM, and LONG BRACE. BLACK 9/16" LARGE HEAD SCREW (8 used in this step) Page 6 418135 www.sauder.com/services...
- Page 7 H I D i t h f a c S u r The METAL BRACKET should be here. Finished edge I D D u t H i t h o f a c S u r www.sauder.com/services 418135 Page 7...
- Page 8 Fasten the SMALL UPRIGHT (E) to the TOP (F). Tighten å two HIDDEN CAMS. Angled edge i t h Angled edge f a c S u r D E N H I D 102S SILVER 1" LARGE HEAD SCREW (4 used in this step) Page 8 418135 www.sauder.com/services...
- Page 9 SMALL UPRIGHT (E). Use three BLACK 9/16" LARGE HEAD SCREWS (1S). Fasten the UPRIGHT MOLDING (BB) to the SMALL å UPRIGHT (E). Tighten two HIDDEN CAMS. BLACK 9/16" LARGE HEAD SCREW (3 used for the METAL BRACKETS) www.sauder.com/services 418135 Page 9...
- Page 10 Finished surface Finished edge I D D u t H i t h o f a c S u r D E N H I D i t h f a c S u r Finished edge Page 10 418135 www.sauder.com/services...
- Page 11 4, while you pull MOLDINGS (X and Z) together at the corners. The METAL BRACKETS should be here. fi n i s h r f a BLACK 1-7/8" FLAT HEAD SCREW (10 used in this step) www.sauder.com/services 418135 Page 11...
- Page 12 METAL PINS (1R). Fasten the SKIRT (S) to the BOTTOM (G). Use two BLACK å 9/16" LARGE HEAD SCREWS (1S). Groove These edges must be even. BLACK 9/16" LARGE HEAD SCREW (2 used in this step) Groove Page 12 418135 www.sauder.com/services...
- Page 13 Fasten the HEARTH (I) to the BRACES (P and R) Use fi ve å BLACK 2-1/4" FLAT HEAD SCREWS (26S). These holes must be here. BLACK 2-1/4" FLAT HEAD SCREW (5 used in this step) BLACK 1-7/8" FLAT HEAD SCREW (2 used in this step) Curved edge www.sauder.com/services 418135 Page 13...
- Page 14 Fasten the HEARTH (I) to the ENDS (A and B), å UPRIGHTS (C and D), and PANELS (N). Use twelve BLACK 2-1/4" FLAT HEAD SCREWS (26S). BLACK 2-1/4" FLAT HEAD SCREW (12 used in this step) Page 14 418135 www.sauder.com/services...
- Page 15 Fasten the CORNER BRACES (31G) to the HEARTH (I) å and LONG BRACE (Q). Use twelve BLACK 9/16" LARGE HEAD SCREWS (1S). BLACK 9/16" LARGE HEAD SCREW (15 used in this step) BLACK 1-7/8" FLAT HEAD SCREW (2 used in this step) www.sauder.com/services 418135 Page 15...
- Page 16 Fasten the FRONT BASES (U and V) to the LARGE å METAL BRACKETS (19G). Use two BLACK 9/16" LARGE HEAD SCREWS (1S). BLACK 9/16" LARGE HEAD SCREW (19 used in this step) These edges must be even. Groove Groove These edges must be even. Page 16 418135 www.sauder.com/services...
- Page 17 Bend the BOWED SKIRT (T) and slide it into the grooves of the SKIRTS (U and V). NOTE: The BOWED SKIRT is not attached so be sure it does not fall out when standing your unit upright in Step 15. www.sauder.com/services 418135 Page 17...
- Page 18 Step 14 Fasten four HINGES (13H) to the DOOR (L). Use eight å BLACK 1/2" FLAT HEAD SCREWS (11S). BLACK 1/2” FLAT HEAD SCREW (8 used in this step) Page 18 418135 www.sauder.com/services...
- Page 19 Repeat this step for the other DOOR (L). å screw See the next step for DOOR adjustments. å Hinge NOTE: The BOWED SKIRT is not attached so be sure it does not fall out when standing your unit upright. www.sauder.com/services 418135 Page 19...
- Page 20 Adjusting screw (horizontal) To adjust the DOORS in or out (depth), loosen the å mounting screw one turn and move the DOORS in or out, as needed. Tighten the mounting screw after making adjustments. (vertical adjustment) Page 20 418135 www.sauder.com/services...
- Page 21 When installing or removing the FIREPLACE SCREWS (1S). INSERT, move it in or out from the back, to keep from scratching the top surface of the bottom. BLACK 9/16" LARGE HEAD SCREW (3 used in this step) www.sauder.com/services 418135 Page 21...
- Page 22 - The TV must weigh less than 95 lbs. - The base of the TV must be able to sit completely on this shelf. 95 lbs. 25 lbs. 20 lbs. (4 used) To cover HIDDEN CAMS 20 lbs. 30 lbs. (8 used) Page 22 418135 www.sauder.com/services...
- Page 23 élément et conserver le livret pour future référence. EXTRÉMITÉ DROITE ..........1 MOULURE DE MONTANT ........1 Pour contacter Sauder EXTRÉMITÉ GAUCHE ..........1 69M INSERT DE CHEMINÉE ..........1 en ce qui concerne cet MONTANT DROIT ............1 EXCENTRIQUE ESCAMOTABLE ....19 élément, faire référence...
- Page 24 • Vérifi er la taille et le poids du téléviseur. Le comparer au diagramme deux EXCENTRIQUES ESCAMOTABLES. ci-dessous avant de commencer l'assemblage ! • Cette unité Sauder est conçue pour les téléviseurs pesant moins de 43 ÉTAPE 6 kg. Ne jamais utiliser avec des téléviseurs plus lourds.
- Page 25 Séparer un TAMPON EN FEUTRE de la FICHE AVEC TAMPONS EN FEUTRE (1M) et le coller sur le coin de la PORTE (L). Répéter cette étape pour l'autre PORTE (L). Voir l'étape suivante pour réglages des PORTES. www.sauder.com/services 418135 Page 25...
- Page 26 MOLDURA DE PARAL ..........1 et conserver le livret pour future référence. EXTREMO IZQUIERDO ............1 69M CHIMENEA PARA INSERTAR ......1 Pour contacter Sauder PARAL DERECHO ..............1 EXCÉNTRICO ESCONDIDO ......19 en ce qui concerne cet PARAL IZQUIERDO ..............1 BIELA DE EXCÉNTRICO ........
- Page 27 • Verifi que el tamaño y peso del televisor. ¡Compárelo al diagrama abajo - EXCÉNTRICOS ESCONDIDOS. antes de comenzar el ensamblaje! • Esta unidad Sauder está diseñada para ser usada con televisores cuyo PASO 6 peso sea inferior a 43 Kg. Nunca la use para un televisor de mayor peso.
- Page 28 Separe un TOPE DE FIELTRO de la TARJETA CON TOPES DE FIELTRO (1M) y aplique este tope a la esquina de la PUERTA (L). Repita este paso para la otra PUERTA (L). Consulte el próximo paso para ajustar la PUERTA. Page 28 418135 www.sauder.com/services...
- Page 29 équipé. • Blessure physique. Le mobilier peut être très lourd. • Ne pas pousser le mobilier, surtout sur la moquette. Se faire aider par une autre personne pour soulever l’élément et le mettre en place. www.sauder.com/services 418135 Page 29...
- Page 30 • Lesión física. El mobiliario puede ser • No empuje la unidad, especialmente muy pesado. sobre un piso alfombrado. Pide la ayuda de otra persona en levantar la unidad y colocarla en lugar. Page 30 418135 www.sauder.com/services...
- Page 31 GARANTIE LIMITÉE DE 1 AN 1. Sauder Woodworking Co. (Sauder®) off re une couverture de garantie limitée à l’ a cheteur 4. La présente garantie ne s’ a pplique qu’ a ux défauts garantis qui se produisent pour initial du présent produit pendant une période un an à...
- Page 32 Dear Valued Customer: So, how did it go? Thanks so much for choosing Sauder® furniture. I hope the Set a world record for speed? purchase and assembly process was a positive experience Feeling good about yourself? and you feel good about the furniture you just built. If you Nice.
