WATERS CORPORATION 2432 Overview And Maintenance Manual

Conductivity (cond) detector
Hide thumbs
Table of Contents

Advertisement

Quick Links

2432 Conductivity
(Cond) Detector
Overview and Maintenance Guide
715004730 / Revision A
Copyright © Waters Corporation 2015
All rights reserved

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 2432 and is the answer not in the manual?

Questions and answers

Related Manuals for WATERS CORPORATION 2432

Summary of Contents for WATERS CORPORATION 2432

  • Page 1 2432 Conductivity (Cond) Detector Overview and Maintenance Guide 715004730 / Revision A Copyright © Waters Corporation 2015 All rights reserved...

  • Page 2: Trademarks

    General information Copyright notice © 2015 WATERS CORPORATION. PRINTED IN THE UNITED STATES OF AMERICA AND IN IRELAND. ALL RIGHTS RESERVED. THIS DOCUMENT OR PARTS THEREOF MAY NOT BE REPRODUCED IN ANY FORM WITHOUT THE WRITTEN PERMISSION OF THE PUBLISHER.

  • Page 3: Contacting Waters

    From the USA or Canada, phone 800-252-4752, or fax 508-872-1990. For other locations worldwide, phone and fax numbers appear in the Waters Web site. Conventional mail Waters Corporation Global Support Services 34 Maple Street Milford, MA 01757 Safety considerations Some reagents and samples used with Waters instruments and devices can pose chemical, biological, or radiological hazards (or any combination thereof).

  • Page 4: Considerations Specific To The Waters 2432 Conductivity Detector

    Considerations specific to the Waters 2432 Conductivity Detector Warning: To avoid electric shock, do not remove protective panels from system modules. The components within are not user-serviceable. Warning: To avoid injury from electrical shock or fire, and damage to the equipment, do not place vessels containing liquid atop the workstation or ancillary equipment or otherwise expose those units to dripping or splashing liquids.

  • Page 5: Operating This Device

    Operating this device When operating this device, follow standard quality-control (QC) procedures and the guidelines presented in this section. Applicable symbols Symbol Definition Manufacturer Date of manufacture Authorized representative of the European Community Confirms that a manufactured product complies with all applicable European Community directives Australia EMC compliant Confirms that a manufactured product complies with all...

  • Page 6: Audience And Purpose

    The resulting chromatograms measure concentrations of anions and cations. Typical applications are in water chemistry, sugar and salt content in food, and water analysis for pollution. The Waters 2432 Conductivity Detector is not intended for clinical applications, but rather for use as a general laboratory module.

  • Page 7: Ism Classification: Ism Group 1 Class B

    Class B products are suitable for use in both commercial and residential locations and can be directly connected to a low voltage, power-supply network. EC authorized representative Address Waters Corporation Stamford Avenue Altrincham Road Wilmslow SK9 4AX UK Telephone...

  • Page 8: Table Of Contents

    Customer comments ..................ii Contacting Waters ..................iii Safety considerations ................... iii Safety hazard symbol notice ...............iii Considerations specific to the Waters 2432 Conductivity Detector ....iv FCC radiation emissions notice ............iv Electrical power safety notice ..............iv Equipment misuse notice ..............iv Safety advisories ................iv...
  • Page 9 2 Preparing and operating the detector..........18 Stacking system modules ................18 Connecting the tubing ................. 19 Installing the multi-detector drip tray ............21 Making the USB connection................21 Connecting signal cables ................21 Input/output signal connectors ..............23 Connecting to the electricity source............... 23 Adding the detector to the system ..............
  • Page 10 Warnings that apply to all Waters instruments and devices ......35 Warnings that address the replacing of fuses..........39 Electrical symbols ..................41 Handling symbols ..................42 B Specifications ................43 Physical specifications ................. 43 Environmental specifications ................ 43 Electrical specifications................44 Operational specifications ................

  • Page 11: 2432 Conductivity Detector

    2432 Conductivity Detector The 2432 Conductivity Detector detects and measures anions and cations present in column eluent. 1.1 Location of the detector within the system The detector is configured as part of the following systems: • ACQUITY Arc system • ACQUITY UPLC H-Class or ACQUITY UPLC Bio H-Class system •...
  • Page 12 Figure 1–1: Location of a detector in an example ACQUITY Arc system 2432 Conductivity Detector 30-cm Column heater Quaternary solvent manager-R Sample manager - Flow through needle-R Bottle tray December 7, 2015, 715004730 Rev. A Page 12...
  • Page 13 Figure 1–2: Location of a detector in an example ACQUITY UPLC H-Class system 2432 Conductivity Detector 30-cm Column heater Quaternary solvent manager Sample manager - Flow through needle Column heater Bottle tray December 7, 2015, 715004730 Rev. A Page 13...

  • Page 14: Major Components

    Figure 1–3: Location of a detector in an example Alliance HPLC system 2432 Conductivity Detector 30-cm Column heater e2695 separations module Solvent bottle tray 1.2 Major components When you open the detector's door, the only visible components are two fittings where tubing is attached and routed in and out of the detector.
  • Page 15 Figure 1–4: Detector with door open Eluent flow out Eluent flow in Figure 1–5: Detector rear December 7, 2015, 715004730 Rev. A Page 15...

  • Page 16: Theory Of Operation

    Signal cable USB port Power inlet 1.3 Theory of operation 1.3.1 Flow cell design The flow cell has an internal volume of 0.8 µL, and the microprocessor controls conductivity measurement. The cell constant is typically 16/cm, and you can adjust it from 13/cm through 21/cm.

  • Page 17: Autozero

    1.3.4 Autozero You can eliminate the eluent’s contribution to conductivity using the Autozero function. When you select Autozero, the detector measures the eluent conductivity and assigns it a value of zero. Thus, any sample ions appear as positive or negative measurements, relative to a zero baseline.

  • Page 18: Preparing And Operating The Detector

    Preparing and operating the detector Install the detector as described in this section. 2.1 Stacking system modules This procedure applies to system modules equipped with interlocking features. Important: For the order in which to stack modules, contact your field service engineer.

  • Page 19: Connecting The Tubing

    To stack the modules: Place the rear feet of the module that you are adding atop the previously added module in the system stack, and slide it backward until its rear alignment pin rests in the rear alignment slot on the previously added module. Figure 2–1: Aligning pins with slots Alignment pin (2) Alignment slot (2)
  • Page 20 Tubing from the column manager Direct the tubing from the fixture labeled "OUT" to a waste container. Requirement: Connect the longer tube with the larger ID to "OUT". Requirement: Ensure that the waste container is placed lower than, or at the same level as, the detector.

  • Page 21: Installing The Multi-Detector Drip Tray

    2.3 Installing the multi-detector drip tray Requirement: If your system has more than one detector, you must install the multi-detector drip tray. See also: For information on how to install the multi-detector drip tray, refer to the instructions included in the multi-detector drip tray kit. 2.4 Making the USB connection Connect one end of the USB cable to the detector, and then connect its other end to the system's PC workstation or LAC/E.
  • Page 22 To connect the cables: Insert the connector into the connector port on the module's rear panel. Figure 2–2: Inserting connector into connector port Connector port Connector Using the flat-blade screwdriver, attach the positive and negative leads of the signal cable to the connector. Figure 2–3: Positive and negative lead connections Screw Connector...

  • Page 23: Input/Output Signal Connectors

    Note: Use the 9/32-inch nut driver to tighten the locking nut until the terminal does not move. Figure 2–4: Grounding cable fork terminal on grounding stud Fork terminal Locking nut Grounding stud 2.6 Input/output signal connectors Refer to the cable-connection label affixed to the rear panel of the module. Table 2–1: Detector analog-out/event-in connections Signal connection Description Inject start...

  • Page 24: Adding The Detector To The System

    2.8 Adding the detector to the system The 2432 Conductivity Detector is controlled through a USB cable. Because other modules use an Ethernet connection, when you add a 2432 Conductivity Detector to a system, you must reconfigure the system in Empower software.
  • Page 25 System Properties. Result: The Chromatographic System dialog box appears. 11. On the Configuration tab, drag the 2432 conductivity detector name from the Available Components pane to the System Configuration pane. Tip: The devices in the System Configuration pane can appear in any order.

  • Page 26: Measuring The Cell Constant

    Enter the resulting cell constant on the General tab of all 2432 Conductivity Detector instrument methods.

  • Page 27: Maintenance Procedures

    Maintenance procedures This section provides the maintenance guidelines and procedures necessary to maintain the device's performance. Keep to a maintenance schedule, and perform maintenance as required and described in this section. 3.1 Maintenance schedule The following table lists periodic maintenance schedules that ensure optimum instrument performance.

  • Page 28: Safety And Handling

    To prevent flow cell failure: • Do not attempt to disassemble or rebuild the flow cell. • The pressure through the 2432 Conductivity Detector flow cell must not exceed 5000 kPa (50 bar, 725 psi). Adjust flow rates accordingly. • Do not connect any tubing or device that can create backpressure exceeding the flow cell's maximum pressure rating.
  • Page 29 Note: The module contains two fuses, one you can replace using the procedure below and one you cannot access. If changing the assessable fuse does not restore power, contact Waters Technical Service. Notice: To avoid damaging system modules, before replacing an opened fuse, determine the cause of the fuse's failure.

  • Page 30: Cleaning The Exterior Of The Equipment

    Remove and discard the old fuse. Insert a new, properly rated fuse into the fuse holder. Insert the fuse holder into the receptacle, and gently push until it locks into position. Connect the power cord to the rear panel power-entry module. Power on the module.
  • Page 31 To clean the exterior of the equipment: Clean surfaces of the equipment using only a clean, soft, lint-free paper or clean cloth dampened with water. Make sure you clean the air exhaust vent on the rear of the unit. Figure 3–2: Caption Air exhaust fan December 7, 2015, 715004730 Rev.

  • Page 32: A Safety Advisories

    Safety advisories Waters instruments and devices display hazard symbols that alert you to the hidden dangers associated with a product’s operation and maintenance. The symbols also appear in product manuals where they accompany statements describing the hazards and advising how to avoid them. This appendix presents the safety symbols and statements that apply to all of Waters’...

  • Page 33: Specific Warnings

    Warning: (Risk of injury caused by moving machinery.) Warning: (Risk of exposure to ultraviolet radiation.) Warning: (Risk of contacting corrosive substances.) Warning: (Risk of exposure to a toxic substance.) Warning: (Risk of personal exposure to laser radiation.) Warning: (Risk of exposure to biological agents that can pose a serious health threat.) Warning: (Risk of tipping.)

  • Page 34: Notices

    A.1.1.2 Biohazard warning The following warning applies to Waters instruments and devices that can process material containing biohazards, which are substances that contain biological agents capable of producing harmful effects in humans. Warning: To avoid infection with potentially infectious, human-sourced products, inactivated microorganisms, and other biological materials, assume that all biological fluids that you handle are infectious.

  • Page 35: Bottles Prohibited Symbol

    A.3 Bottles Prohibited symbol The Bottles Prohibited symbol alerts you to the risk of equipment damage caused by solvent spills. Prohibited: To avoid equipment damage caused by spilled solvent, do not place reservoir bottles directly atop an instrument or device or on its front ledge.
  • Page 36 Advertencia: cualquier cambio o modificación efectuado en esta unidad que no haya sido expresamente aprobado por la parte responsable del cumplimiento puede anular la autorización del usuario para utilizar el equipo. 警告： 未經有關法規認證部門允許對本設備進行的改變或修改,可能會使使用者喪失操作 該設備的權利。 警告： 未经有关法规认证部门明确允许对本设备进行的改变或改装，可能会使使用者丧 失操作该设备的合法性。 경고: 규정 준수를 책임지는 당사자의 명백한 승인 없이 이 장치를 개조 또는 변경할 경우, 이...
  • Page 37 Warnung: Bei der Arbeit mit Polymerschläuchen unter Druck ist besondere Vorsicht angebracht: • In der Nähe von unter Druck stehenden Polymerschläuchen stets Schutzbrille tragen. • Alle offenen Flammen in der Nähe löschen. • Keine Schläuche verwenden, die stark geknickt oder überbeansprucht sind.
  • Page 38 警告： 當在有壓力的情況下使用聚合物管線時，小心注意以下幾點。 • 當接近有壓力的聚合物管線時一定要戴防護眼鏡。 • 熄滅附近所有的火焰。 • 不要使用已經被壓癟或嚴重彎曲管線。 • 不要在非金屬管線中使用四氫呋喃或濃硝酸或濃硫酸。 • 要了解使用二氯甲烷及二甲基亞楓會導致非金屬管線膨脹，大大降低管線的耐壓能 力。 警告： 当有压力的情况下使用管线时，小心注意以下几点： • 当接近有压力的聚合物管线时一定要戴防护眼镜。 • 熄灭附近所有的火焰。 • 不要使用已经被压瘪或严重弯曲的管线。 • 不要在非金属管线中使用四氢呋喃或浓硝酸或浓硫酸。 • 要了解使用二氯甲烷及二甲基亚枫会导致非金属管线膨胀，大大降低管线的耐压能 力。 경고: 가압 폴리머 튜브로 작업할 경우에는 주의하십시오. • 가압 폴리머 튜브 근처에서는 항상 보호 안경을 착용하십시오. •...

  • Page 39: Warnings That Address The Replacing Of Fuses

    Warning: The user shall be made aware that if the equipment is used in a manner not specified by the manufacturer, the protection provided by the equipment may be impaired. Avertissement : L’utilisateur doit être informé que si le matériel est utilisé d’une façon non spécifiée par le fabricant, la protection assurée par le matériel risque d’être défectueuses.
  • Page 40 Avertissement : pour éviter tout risque d'incendie, remplacez toujours les fusibles par d'autres du type et de la puissance indiqués sur le panneau à proximité du couvercle de la boite à fusible de l'instrument. Warnung: Zum Schutz gegen Feuer die Sicherungen nur mit Sicherungen ersetzen, deren Typ und Nennwert auf den Tafeln neben den Sicherungsabdeckungen des Geräts gedruckt sind.

  • Page 41: Electrical Symbols

    Advertencia: Para evitar incendios, sustituir los fusibles por aquellos del tipo y características indicados en la sección "Sustituir fusibles". 警告： 為了避免火災，更換保險絲時，應使用「維護步驟」章節中「更換保險絲」所指 定之相同類型與規格的保險絲。 警告： 为了避免火灾，应更换“维护步骤”一章的“更换保险丝”一节中介绍的相同类 型和规格的保险丝。 경고: 화재의 위험을 막으려면 유지관리 절차 단원의 “퓨즈 교체” 절에 설명된 것과 동 일한 타입 및 정격의 제품으로 퓨즈를 교체하십시오. 警告: 火災予防のために、ヒューズ交換ではメンテナンス項目の「ヒューズの交換」に記載されているタ...

  • Page 42: Handling Symbols

    A.8 Handling symbols The following handling symbols and their associated statements can appear on labels affixed to the packaging in which instruments, devices, and component parts are shipped. Symbol Description Keep upright! Keep dry! Fragile! Use no hooks! Upper limit of temperature Lower limit of temperature Temperature limitation December 7, 2015, 715004730 Rev.

  • Page 43: B Specifications

    Specifications This appendix lists individual operating specifications for the detector. Note: All 2432 Conductivity Detector performance specifications are measured following a warm-up period of 30 min. B.1 Physical specifications The following table lists the physical specifications for the detector. Table B–1: Physical specifications...

  • Page 44: Electrical Specifications

    B.3 Electrical specifications The following table lists the electrical specifications for the detector. Attribute Specification Class I Protection class Overvoltage category Pollution degree Normal (IPXO) Moisture protection Line voltages, nominal Grounded ac Power requirements 100 to 240 Vac Line frequency 50 to 60 Hz Power consumption 160 VA (nominal)

  • Page 45: Flow Cell Specifications

    Table B–3: Operational specifications: Attribute Specification Measurement range 0 to 10,000 µS/cm, without range switching <0.5%/hr, 1 mM KCl at 1 mL/min, cell temperature 35 °C Drift Noise ≤0.005 µS/cm, 1 mM KCl at 1 mL/min, cell temperature 35 °C 20.0 to 50.0 °C in steps of 5 °C and Off Temperature control Temperature stability...

  • Page 46: Wetted Materials Of Construction

    Parameter Specification +0.8 V Minimum pulse width (start, stop, quit) 100 ms B.7 Wetted materials of construction The wetted path in the detector is constructed from 316 stainless steel, polychlorotrifluoroethylene (PCTFE), and PEEK. December 7, 2015, 715004730 Rev. A Page 46...
