ASSEMBLY RATING
The Assembly Rating is a 5-point system that
shows the degree of effort needed in
assembling a specific product (with 1 being
easy and 5 being difficult). For some
products, two persons are recommended.
EASY
Assembly Instructions
FOA7893CK
DIFFICULT
Tools Required For Assembly:
Allen Wrench
Phillips Screwdriver
2 PERSONS RECOMMENDED
Page 1 of 6
(Included)
(Not Included)
Rev: 19-07-09
Advertisement
Table of Contents
Related Manuals for Furniture of America FOA7893CK
Summary of Contents for Furniture of America FOA7893CK
- Page 1 Assembly Instructions For more information contact our team: service.ec@foagroup.com FOA7893CK ASSEMBLY RATING Tools Required For Assembly: The Assembly Rating is a 5-point system that shows the degree of effort needed in Allen Wrench (Included) assembling a specific product (with 1 being easy and 5 being difficult).
- Page 2 LOOSEN OVER TIME AND MAY CAUSE THE FURNITURE TO BE WOBBLY AND UNABLE TO SUPPORT ITS INTENDED WEIGHT CAPACITY. THIS MAY LEAD TO COLLAPSE AND MAY CAUSE SERIOUS INJURY. FAILURE TO FOLLOW THE GUIDELINES ABOVE MAY RESULT IN INJURY AND/OR PROPERTY DAMAGE. FURNITURE OF AMERICA.ALL RIGHTS RESERVED. Page 2 of 6...
- Page 3 Before you begin, please read Page 2 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. #C x 14 Lock Washer Ø5/16" x 10mm D x 14 Flat Washer Ø5/16" x 13mm #F x 30mm # x 6pcs...
- Page 4 Exploded View Align HB legs (#2R/L) to headboard (#1), then secure by using bolts (#A) with washers (#C,D). #A x 12pcs #C x 12pcs #D x 12pcs Page 4 of 6...
- Page 5 #B x 2 pcs #C x 2 pcs #D x 2 pcs Attach support leg (#5) to footboard (#3). Align FB legs (#4) to footboard (#3), then secure by using bolts (#B) with washers (#C,D). Align side rails (#9) to headboard (#1) and footboard (#3), then secure by using bolts (#E).
- Page 6 Attach support legs (#8) to the center slat (#7). Adjust levelers of the support legs (#8) according to ground level. Align center slats (#7) to slats (#6), then secure by using screws (#F). Align slats (#6) to the side rails, then secure by using screws (#F).
