SC0750/SC1000/SC2000/SC3000
Installation/Reference Guide
Excelitas Canada Inc.
2260 Argentia Road
Mississauga (ON)
L5N 6H7 Canada
+1 905.821.2600
www.excelitas.com
OmniCure®
UV Curing Solutions
Applicable for the following System Controller models:
Model
SC0750
SC1000
SC2000
SC3000
Part Numbers
019-00199R
019-00186R
019-00211R
019-00213R
035-00539R rev.5
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Excelitas Technologies OmniCure SC Series
Summary of Contents for Excelitas Technologies OmniCure SC Series
- Page 1 OmniCure® SC0750/SC1000/SC2000/SC3000 UV Curing Solutions Applicable for the following System Controller models: Model Part Numbers SC0750 019-00199R SC1000 019-00186R SC2000 019-00211R SC3000 019-00213R Installation/Reference Guide Excelitas Canada Inc. 2260 Argentia Road Mississauga (ON) L5N 6H7 Canada +1 905.821.2600 www.excelitas.com 035-00539R rev.5...
- Page 2 OmniCure® SC- Series UV Curing Solutions Installation/Reference Guide 035-00539R Excelitas Canada Inc. 2021 All rights reserved No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system or translated into any language in and form by any means without the prior written consent of Excelitas Canada Inc.
- Page 3 OmniCure® SC- Series UV Curing Solutions Revision History Revision # Comments Rev 1.0 Initial release Rev 2.0 Updated corporate logo, minor edits/corrections Rev 3.0 Added SC2000 and SC3000 Rev 4.0 Streamlined regulatory section Rev 5.0 Update to regulatory section and website links www.excelitas.com/omnicure Excelitas Canada Inc.
-
Page 4: Table Of Contents
Regulatory Compliance ......................... 12 China RoHS ............................13 WEEE Directive (2012/19/EU) ........................ 13 Warranty ..........................15 Returning your System Controller to Excelitas Technologies for Service ..........15 Contact Information ......................16 Figures Figure 1 SC0750/SC1000/SC2000 Unit ........................4 Figure 2 SC3000 Unit ..............................4 Figure 3 SC0750/SC1000/SC2000 Mechanical Dimensions .................. -
Page 5: Introduction
SC1000 019-00186R SC2000 019-00211R SC3000 019-00213R Excelitas Technologies recommends reading this guide to discover all features of the OmniCure® SC0750/SC1000/SC2000/SC3000 System Controllers, and how to use them. www.excelitas.com/omnicure Excelitas Canada Inc. 2021 All rights reserved 035-xxxxxR, rev.1 035-00539R rev 5 035-xxxxxR, rev.1... -
Page 6: Safety Precautions/ User Warnings
OmniCure® SC- Series UV Curing Solutions Safety Precautions/ User Warnings NOTE: The SC Series PSU have been designed for safe use, however, if the equipment is used in a manner not specified by the manufacturer, the protection systems provided by the equipment may be impaired. The safety of any system incorporating an SC Series PSU is the responsibility of the assembler of the system Glossary of Symbols: Caution risk of danger –... -
Page 7: Getting Started
OmniCure® SC- Series UV Curing Solutions Getting Started Packaging Contents The package contains: One of the following System Controllers: SC0750 019-00199R SC1000 019-00186R SC2000 019-00211R SC3000 019-00213R AC power cable, selected for mains power receptacles in the destination country ... -
Page 8: Connecting The System Controller
OmniCure® SC- Series UV Curing Solutions Connecting the System Controller Front View Status Indicator Power Switch DC Power Connectors Rear View Breaker Switch AC Inlet Receptacle Figure 1 SC0750/SC1000/SC2000 Unit DC Power Connectors Rear View Breaker Switch AC Inlet Receptacle Figure 2 SC3000 Unit Before any electrical connections are made, ensure that the electrical circuit breaker is tripped. - Page 9 OmniCure® SC- Series UV Curing Solutions If the System Controller is intended to power more than one UV LED head, repeat steps 5and 6 for each unit to be connected. Plug the trailing end of the AC power cord into an AC mains outlet at the wall capable of supplying voltage and current as per the specifications in this manual.
-
Page 10: Mounting The System Controller
They are not designed to support any additional weight placed onto the top of the unit. Placing additional mechanical loading onto the unit may damage the mounting brackets, the racking or the mounting screws themselves. Excelitas Technologies considers evidence of such cases as outside of warranty. -
Page 11: Mechanical Dimensions
OmniCure® SC- Series UV Curing Solutions Mechanical Dimensions Figure 3 SC0750/SC1000/SC2000 Mechanical Dimensions Figure 4 SC3000 Mechanical Dimensions www.excelitas.com/omnicure Excelitas Canada Inc. 2021 All rights reserved 035-xxxxxR, rev.1 035-00539R rev 5 035-xxxxxR, rev.1 035-00539R rev 2... -
Page 12: Electrical Connectivity
OmniCure® SC- Series UV Curing Solutions Electrical Connectivity DC Power Connectors (x2) Figure 5 Power Connector (looking at System Controller) Name Description 48V DC power feed. 48V DC power feed. (SC2000 & SC3000 only. Shared current through this pin) 48V DC power return. 48V DC power return. -
Page 13: Troubleshooting
In North America, request for Return Authorization number can be made online at https://www.excelitas.com/ox_service_request_form Enclose details of the problem with the unit and return both to the Excelitas Technologies Service Centre. The unit should be returned in its original packaging if possible. - Page 14 It is normal for electrical cables and connectors to warm up while in use. If a cable or connector is too hot to be comfortably handled, there may be an electrical problem associated with it. Contact Excelitas Technologies Service department for guidance. www.excelitas.com/omnicure Excelitas Canada Inc.
-
Page 15: Care And Maintenance
OmniCure® SC- Series UV Curing Solutions Care and Maintenance The System Controllers are designed to provide years of trouble-free operation with little maintenance activity. Here are some guidelines for ensuring long-life from the System Controller. Do not locate the System Controller directly in an environment with air-borne contamination. If the unit needs to be in such an environment, install inside a ventilated cabinet with fan-assisted air- filtration. -
Page 16: Technical Specifications
OmniCure® representative or visit www.excelitas.com/omnicure for more details. **WARNING** Changes or modifications not expressly approved by Excelitas Technologies could void the user’s authority to operate the equipment. Product Safety: General Requirements IEC Equipment Class: I Installation Category: II Pollution Degree: 2 Requirements for MAINS cords or cord sets are contained in ANSI/UL 817 and CSA C22.2 No. -
Page 17: China Rohs
**WARNING** Changes or modifications not expressly approved by Excelitas Technologies could void the user’s authority to operate the equipment. 8.3 China RoHS The symbol above indicates a product does not contain any restricted substances. - Page 18 OmniCure® SC- Series UV Curing Solutions The equipment that you bought has required the extraction and use of natural resources for its production. It may contain hazardous substances that could impact health and the environment. In order to avoid the dissemination of those substances in our environment and to diminish the pressure on the natural resources, we encourage you to use the appropriate take-back systems.
-
Page 19: Warranty
UV Curing Solutions Warranty Excelitas Technologies warrants the original purchaser for a period of one (1) full year, calculated from the date of purchase, that the equipment sold is free from defects in material and workmanship. In the event of a claim under this warranty, the equipment is to be sent postage and carriage paid to the Excelitas Technologies Service Centre. -
Page 20: Contact Information
OmniCure® SC- Series UV Curing Solutions 10 Contact Information Excelitas Canada Inc. 2260 Argentia Road Mississauga, Ontario L5N 6H7 CANADA Tel.: +1 905 821-2600 Toll: +1 800 668-8752 (USA and Canada) Fax: +1 905 821-2055 http://www.excelitas.com/Pages/Product/OmniCure.aspx www.excelitas.com/omnicure Technical Assistance: techsupport@excelitas.com https://www.excelitas.com/ox_service_request_form For a complete listing of Authorized OmniCure Distributors and Service Centres please go to https://www.excelitas.com/dealer-search...
