OmniCure® SC0750/SC1000
Applicable for the following System Controller models:
Installation/Reference Guide
Excelitas Canada Inc.
2260 Argentia Road
Mississauga (ON)
L5N 6H7 Canada
+1 905.821.2600
www.excelitas.com
UV Curing Solutions
Model
Part Numbers
SC0750
019-00199R
SC1000
019-00186R
035-00539R rev.2
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Excelitas Technologies OmniCure SC0750
Summary of Contents for Excelitas Technologies OmniCure SC0750
- Page 1 OmniCure® SC0750/SC1000 UV Curing Solutions Applicable for the following System Controller models: Model Part Numbers SC0750 019-00199R SC1000 019-00186R Installation/Reference Guide Excelitas Canada Inc. 2260 Argentia Road Mississauga (ON) L5N 6H7 Canada +1 905.821.2600 www.excelitas.com 035-00539R rev.2...
- Page 2 OmniCure® SC- Series UV Curing Solutions Installation/Reference Guide 035-00539R Excelitas Canada Inc. 2014 All rights reserved No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system or translated into any language in and form by any means without the prior written consent of Excelitas Canada Inc.
- Page 3 OmniCure® SC- Series UV Curing Solutions Revision History Revision # Comments Rev 1.0 Initial release Rev 2.0 Updated corporate logo, minor edits/corrections www.excelitas.com/omnicure Excelitas Canada Inc. 2014 All rights reserved 035-xxxxxR, rev.1 035-00539R rev 2...
-
Page 4: Table Of Contents
Regulatory Compliance ......................... 10 China RoHS ............................11 WEEE Directive (2012/19/EU) ........................ 12 Warranty ..........................13 Returning your System Controller to Excelitas Technologies for Service ..........13 Contact Information ......................14 Figures Figure 1 SC0750/SC1000 Unit ............................ 4 Figure 2 Mechanical Dimensions ..........................7 Figure 3 Power Connector (looking at System Controller) .................. -
Page 5: Introduction
This manual covers the following models: SC0750 019-00199R SC1000 019-00186R Excelitas Technologies recommends reading this guide to discover all features of the OmniCure® SC0750/SC1000 System Controllers, and how to use them. www.excelitas.com/omnicure Excelitas Canada Inc. 2014 All rights reserved 035-xxxxxR, rev.1... -
Page 6: Safety Precautions/ User Warnings
OmniCure® SC- Series UV Curing Solutions Safety Precautions/ User Warnings Glossary of Symbols: Caution risk of danger – consult accompanying documents. Protective Conductor Terminal Earth (Ground) Terminal CAUTION, Risk of Electrical Shock www.excelitas.com/omnicure Excelitas Canada Inc. 2014 All rights reserved 035-xxxxxR, rev.1 035-00539R rev 2... -
Page 7: Getting Started
OmniCure® SC- Series UV Curing Solutions Getting Started Packaging Contents The package contains: One of the following System Controllers: • SC0750 019-00199R • SC1000 019-00186R • AC power cable, selected for mains power receptacles in the destination country • A small polythene bag containing mounting brackets (x2) •... -
Page 8: Connecting The System Controller
OmniCure® SC- Series UV Curing Solutions Connecting the System Controller Front View Status Indicator Power Switch DC Power Connectors Rear View Breaker Switch AC Inlet Receptacle Figure 1 SC0750/SC1000 Unit Before any electrical connections are made, ensure that the electrical circuit breaker is tripped. This can be done by pushing the breaker switch away from the AC-inlet receptacle. - Page 9 OmniCure® SC- Series UV Curing Solutions **WARNING** The System Controller should only be connected to a mains outlet using the style and rating of cable provided. This regional cable is of the 3-pin variety and carries a protective earth connection. For user safety, do not substitute this cable with any 2-pin variety. www.excelitas.com/omnicure Excelitas Canada Inc.
-
Page 10: Mounting The System Controller
They are not designed to support any additional weight placed onto the top of the unit. Placing additional mechanical loading onto the unit may damage the mounting brackets, the racking or the mounting screws themselves. Excelitas Technologies considers evidence of such cases as outside of warranty. -
Page 11: Mechanical Dimensions
OmniCure® SC- Series UV Curing Solutions Mechanical Dimensions Figure 2 Mechanical Dimensions Electrical Connectivity DC Power Connectors (x2) Figure 3 Power Connector (looking at System Controller) Name Description 48V DC power feed. – No connection 48V DC power return. – No connection Chassis Chassis ground connection... -
Page 12: Troubleshooting
OmniCure® SC- Series UV Curing Solutions Troubleshooting Service to be completed by qualified Excelitas Technologies personnel only! If the green LED indicator fails to illuminate: Validate that mains voltage is reaching the receptacle intended for use by powering an independent •... -
Page 13: Care And Maintenance
OmniCure® SC- Series UV Curing Solutions Care and Maintenance The System Controllers are designed to provide years of trouble-free operation with little maintenance activity. Here are some guidelines for ensuring long-life from the System Controller. Do not locate the System Controller directly in an environment with air-borne contamination. If the •... -
Page 14: Technical Specifications
OmniCure® SC- Series UV Curing Solutions Technical Specifications 8.1 Environmental and Unit Specifications SC0750 SC1000 Operating Temperature Range (degrees 10-40C Relative Humidity 10-80% (non-condensing) Dimensions (mm) Length (not including mounting Depth brackets) Height Weight (kg) 3.9kg (8.61 lbs) Input Voltage 100-240V AC 50/60Hz Maximum AC input current (A) 9-4.3... -
Page 15: China Rohs
OmniCure® SC- Series UV Curing Solutions Electromagnetic Compatibility (SC0750): EN55011:2009+A2:2010 (Group 1, Class A) Industrial, scientific and medical (ISM) radio-frequency equipment - Electromagnetic disturbance characteristics – Limits and methods of Measurement EN 55022: 2010+A1: 2007 (Class A) Information technology equipment-Radio disturbance characteristics - Limits and methods of measurement EN 61000-6-3:2007, -3-2:2006, -3-3:2008 Electromagnetic compatibility (EMC) –... -
Page 16: Weee Directive (2012/19/Eu)
OmniCure® SC- Series UV Curing Solutions materials used for this part is above the limit requirement in SJ/T11363-2006 (Enterprises may further provide in this box technical explanation for marking “X” based on their actual conditions.) Table 3 China RoHS WEEE Directive (2012/19/EU) The symbol above indicates that this product should not be disposed of along with municipal waste, that the product should be collected separately, and that a separate collection system exists for all products that contain this symbol within member states of the European Union. -
Page 17: Warranty
UV Curing Solutions Warranty Excelitas Technologies warrants the original purchaser for a period of one (1) full year, calculated from the date of purchase, that the equipment sold is free from defects in material and workmanship. In the event of a claim under this warranty, the equipment is to be sent postage and carriage paid to the Excelitas Technologies Service Centre. -
Page 18: Contact Information
OmniCure® SC- Series UV Curing Solutions 10 Contact Information Excelitas Technologies 2260 Argentia Road Mississauga, Ontario L5N 6H7 CANADA Tel.: +1 905 821-2600 Toll: +1 800 668-8752 (USA and Canada) Fax: +1 905 821-2055 http://www.excelitas.com/Pages/Contact/Contact_OX.aspx www.excelitas.com/omnicure Technical Assistance: Techsupport@excelitas.com http://www.excelitas.com/Pages/Contact/Service-Request-Form.aspx For a complete listing of Authorized OmniCure Distributors and Service Centres please go to http://www.excelitas.com/Pages/Support/Service-Centers.aspx...
