USER'S MANUAL (1/2)
(Specification and Part Names)
63"/50" WIDE PLASMA DISPLAY
P63XCA30W/P63XCA30E/P63XCA30A/
P50XCA30W/P50XCA30E/P50XCA30A
• Accessories ······················································ E-2
• Part Names and Functions ······················ E-3–E-5
• Installation ······················································· E-6
• Options ····························································· E-7
• Main Supported Signals ································· E-8
• Specification ··········································· E-9–E-10
Before using the display, read the User's manual (1/2) and the User's manual (2/2) carefully so that you know how
to use the display correctly.
Refer to these manuals whenever questions or problems about operation arise. Be sure to read and observe the
safety precautions.
Keep these manuals where the user can access them readily.
* Installation and removal require special expertise. Consult your product dealer for details.
Contents
Page
Before Use
• Safety Precautions ··············· User's manual (2/2)
Usage
• Handy Tips ···························· User's manual (2/2)
• Connecting the Display to External
Equipment ···························· User's manual (2/2)
• Using the Remote Control ··· User's manual (2/2)
• Basic Operations ·················· User's manual (2/2)
• Watching Pictures on the Wide Screen
··············································· User's manual (2/2)
Adjustments
• Adjusting Pictures (PICTURE Menu)
··············································· User's manual (2/2)
• Adjusting Screen Position and Size
(POSITION/SIZE Menu) ········ User's manual (2/2)
• Other Adjustments
(FEATURES Menu) ··············· User's manual (2/2)
• Initialization of User Adjustment Value
(FACTORY DEFAULT) ··········· User's manual (2/2)
• Cleaning and Maintenance ·· User's manual (2/2)
Advertisement
Table of Contents
Related Manuals for Fujitsu Plasmavision P50XCA30WH
Summary of Contents for Fujitsu Plasmavision P50XCA30WH
- Page 1 USER’S MANUAL (1/2) (Specification and Part Names) 63”/50” WIDE PLASMA DISPLAY P63XCA30W/P63XCA30E/P63XCA30A/ P50XCA30W/P50XCA30E/P50XCA30A • Accessories ······················································ E-2 • Part Names and Functions ······················ E-3–E-5 • Installation ······················································· E-6 • Options ····························································· E-7 • Main Supported Signals ································· E-8 • Specification ··········································· E-9–E-10 Before using the display, read the User’s manual (1/2) and the User’s manual (2/2) carefully so that you know how to use the display correctly.
-
Page 2: Checking Accessories
ACCESSORIES CHECKING ACCESSORIES One remote control Two AA batteries Two user’s manuals One power cable CONNECTING THE DISPLAY TO EXTERNAL EQUIPMENT Carefully check the terminals for position and type before making any connections. Loose connectors can result in picture or color problems. Make sure that all connectors are securely inserted into their terminals. Ferrite cores These ferrite cores are used to attenuate undesired signals. -
Page 3: Part Names And Functions
PART NAMES AND FUNCTIONS Front ① ② Warning If the power indicator lamp flashes red or green, this signifies that the display has developed a problem. When this happens, be sure to remove the power plug from the receptacle and contact your dealer. Leaving the display power ON can result in fire or electric shock. 1 Power indicator lamp This lamp shows the state of the power supply. - Page 4 PART NAMES AND FUNCTIONS (Continued) Bottom 1 OFF/STD-BY switch :The power indicator lamp goes off, and the power can’t be turned on by the power button. The power is partly supplied. STD-BY :The power indicator lamp lights red, and the power can be turned on or off by the power button. 2 RS-232C terminal (RS-232C) This terminal is provided for you to control the display from the PC.
- Page 5 Description of Input Terminals RGB1 terminal (RGB1 INPUT/mD-sub) RS-232C terminal (RS-232C) * Terminal layout may differ and functions may not be available with some models and some device options. Pin No. Input signal Pin No. — Green Ground Blue — —...
- Page 6 INSTALLATION To prevent the display’s internal components from overheating, make sure that the display is installed in a well-ventilated location. Be sure to use the optional desktop stand, ceiling-mounting unit, wall-mounting unit and other unit when installing this display. Also, be sure that your dealer performs the installation.
- Page 7 To prevent injury, fire, and electric shock, arrange for options to be initially installed (or installed at a different location) by your dealer. CAUTION: This display (P63XCA30) is for use only with Fujitsu General Limited’s option (P-WB6300, P- CT6300, P-TT6300).
-
Page 8: Main Supported Signals
MAIN SUPPORTED SIGNALS This display can store the latest four types of signals for RGB adjustment value. The fifth input signal will delete the adjustment value of the first input signal. To do this, select a desired signal and follow the instructions in “Adjusting Screen Position and Size” on the User’s Manual (2/2) to adjust the parameters. - Page 9 • Viewing the screen constantly for extended periods can strain your eyes. Be sure to stay at a proper distance (at least 2.4 m or 7.9 feet for 63”) from the screen and to look occasionally away while working. • is a worldwide trademark of Fujitsu General Limited and is a registered trademark in Japan, the U.S.A. and other countries or areas. P63XCA30W/P63XCA30E/P63XCA30A (does not include outer projections)
- Page 10 • Viewing the screen constantly for extended periods can strain your eyes. Be sure to stay at a proper distance (at least 1.9 m or 6.2 feet for 50”) from the screen and to look occasionally away while working. • is a worldwide trademark of Fujitsu General Limited and is a registered trademark in Japan, the U.S.A. and other countries or areas. E-10 P50XCA30W/P50XCA30E/P50XCA30A...
-
Page 11: Table Of Contents
USER’S MANUAL (2/2) (Precautions and Adjustment Methods) WIDE PLASMA DISPLAY Before Use • Safety Precautions ···························································································· E-2–E-3 Usage • Handy Tips ················································································································· E-4 • Connecting the Display to External Equipment ······················································ E-5 • Using the Remote Control ················································································ E-6–E-7 • Basic Operations ······································································································· E-8 •... -
Page 12: Safety Precautions
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. – Consult the dealer or an experienced radio/TV technician for help. IMPORTANT SAFETY INSTRUCTIONS Electrical energy can perform many useful functions. This unit has been engineered and manufactured to assure your personal safety. But IMPROPER USE CAN RESULT IN POTENTIAL ELECTRICAL SHOCK OR FIRE HAZARD. - Page 13 14) Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power- supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, dose not operate normally, or has been dropped.
-
Page 14: Handy Tips
HANDY TIPS RECEPTACLE Make sure that the power cable’s grounding wire is grounded. The display comes with a 3-prong power plug; one prong is connected to the grounding wire. If you have only a 2-hole receptacle, you will need to have it replaced. Contact your dealer for more information. •... -
Page 15: Connecting The Display To External Equipment
CONNECTING THE DISPLAY TO EXTERNAL EQUIPMENT Be sure to turn OFF the power to the display and external equipment before making any connections. No cables are supplied with the display for connection to external equipment. The type of cable to be used varies depending on the PC model. -
Page 16: Using The Remote Control
USING THE REMOTE CONTROL Remote Control PUTTING BATTERIES IN THE REMOTE CONTROL 1 To remove the cover, slide it outwards while pressing it down. CAUTION: Be sure to use replacement batteries of the same type as the original ones. When disposing of used batteries, please comply with governmental regulations or environmental public institution’s rules that apply in your country/area. -
Page 17: Effective Range For The Remote Control
PRECAUTIONS To prevent malfunction, be sure not to apply any form of severe shock to the remote control. To prevent malfunction or deformation, be sure not to allow the remote control to become wet; also, keep it away from hot locations or heating equipment. -
Page 18: Basic Operations
• A variety of picture modes are available with this display. Remember that if you select a mode with an aspect ratio (ratio of frame width to frame height) different from that of the TV program or video media, the pictures will appear differently than if you had selected a mode having the same aspect ratio. -
Page 19: Watching Pictures On The Wide Screen
WATCHING PICTURES ON THE WIDE SCREEN SWITCHING BETWEEN SCREEN SIZES Press The currently selected mode will appear. Press picture mode. Each time you press appears. The sequences used are as follows: When you are in an RGB input mode * Depending on the type of signal, some aspects SCREEN SIZE Normal Displays pictures of normal size (i.e., a 4:3 aspect ratio). -
Page 20: Adjusting Pictures (Picture Menu)
ADJUSTING PICTURES (PICTURE MENU) BASIC OPERATIONS [EX.: ADJUSTING TINT (Tint)] You can make changes to all picture adjustment options in the PICTURE Menu. The changes you make will be stored for a selected input mode. Therefore, you need to select a desired input mode before making any changes. - Page 21 • Contrast, brightness, color darkness, tint, and picture sharpness are adjusted as shown in the following chart. Select the item with , and then adjust with Adjustment Item Contrast Brightness Color Tint Sharpness • Setting Picture Mode (Picture Mode) Can set up the picture mode. Each time you press , one of the available choices appears in the following sequence: Dynamic: Suitable for watching a normal motion picture.(Standard)
-
Page 22: Adjusting Screen Position And Size (Position/Size Menu)
ADJUSTING SCREEN POSITION AND SIZE (POSITION/SIZE MENU) BASIC OPERATION [EX.: ADJUSTING HORIZONTAL DIRECTION OF SCREEN POSITION] You can make changes to all screen adjustment options in the POSITION/SIZE Menu. The changes you make will be stored for the selected input mode. Therefore, you need to select a desired input mode before making any changes. - Page 23 Adjusting Screen Position (Position) Horizontal position (Horizontal) : Moves screen to the right. : Moves screen to the left. Vertical position (Vertical) : Moves screen up. : Moves screen down. Press to store. Adjusting Screen Size (Size) Screen width (Width) : Increases width.
-
Page 24: Other Adjustments (Features Menu)
OTHER ADJUSTMENTS (FEATURES MENU) BASIC OPERATION [EX.: SELECTING LANGUAGE (Language)] You can make the following changes in the FEATURES Menu. Press The main menu screen will appear. Press Each time you press menus appears in the following sequence: PICTURE The FEATURES Menu screen will appear. Press Menu". - Page 25 • FEATURES setup screen has the following 4 options. Adjustment : Can make a fine adjustment of pictures such as Dot Clock, Clamp Position. On Screen Menu : Can make a display setting such as OSD, Language. (See P. E-16.) Input Terminal : Can make an input terminal setting such as D-SUB Input.
- Page 26 OTHER ADJUSTMENTS (FEATURES MENU)(Continued) ON SCREEN MENU • Setting Display Information (OSD) You can use this option to select whether to display information other than menus. (Error messages are displayed regardless of what choice you make for this option.) Each time you press , one of the available choices appears in the following sequence: On : Displays all information.
-
Page 27: Others Menu
OTHERS MENU • Selecting time before DPMS starts (DPMS) You can use this option to select the amount of time before the DPMS function starts. DPMS (which stands for “display power management signaling”) allows the display to maintain an automatic power saving function. This function causes on-screen information to disappear until the next input operation, if the power is ON and the display has not received any signals for the predetermined period of time. - Page 28 OTHER ADJUSTMENTS (FEATURES MENU)(Continued) • Minimizing phosphor burn-in (Screen Orbiter) You can use this option to move the screen position to minimize phosphor-induced “burn-in”. Follow the steps below. (1) Select “Screen Orbiter” and press The “Screen Orbiter” setting screen will appear. (2) Press to select “Mode/Time”.
- Page 29 • Assigning Numbers to Displays (Monitor No.) When you use two or more displays, you can use a single remote control to control individual displays by assigning a unique number to each of the displays. Each time you press , one of the available numbers appears in the following sequence: You can normally control displays.
- Page 30 OTHER ADJUSTMENTS (FEATURES MENU)(Continued) • Setting Exhibition Mode (Exhibition Mode) You can use this option to display the enhanced contrast, which is most suitable for the use by unspecified persons. Each time you press , one of the available choices appears in the following sequence: On: Sets up Exhibition mode.
-
Page 31: Initialization Of User Adjustment Value (Factory Default
INITIALIZATION OF USER ADJUSTMENT VALUE (FACTORY DEFAULT) You can restore the values of the adjustment/setting made in the MENU to factory settings. Press The main menu screen will appear. Press DEFAULT”. Each time you press menus appears in the following sequence: PICTURE The FACTORY DEFAULT Menu screen will appear. -
Page 32: Cleaning And Maintenance
CLEANING AND MAINTENANCE Precautions Be sure to remove the power plug from the receptacle before cleaning the display. Be sure not to clean the display using a cloth dampened with volatile solvents, such as benzene or thinner. Such solvents can harm the display’s cabinet, the filter at the screen front, and the remote control.
