Page 2
2004 Panasonic Home Appliances Microwave Oven (Shanghai) Co., Ltd. / All rights reserved. Unauthorized copying and distribution is a violation of law.
2. CAUTIONS TO BE OBSERVED WHEN TROUBLESHOOTING Unlike many other appliances, the microwave oven is a high voltage, high current device. It is free from danger in ordinary use, though extreme care should be taken during repair. Caution Servicemen should remove their watches whenever working close to or replacing the magnetron.
Page 8
Do not operate on a two wire extension cord. The microwave oven is designed to be grounded when used. It is imperative, therefore, to ensure the appliance is properly grounded before beginning repair work. 2.2. Inverter warnings DANGER, HIGH VOLTAGE AND HIGH TEMPERATURE (HOT/LINE) OF THE INVERTER POWER SUPPLY (U) This high voltage inverter power supply handles very high voltage and current for the magnetron tube.
Page 9
Grounding of the inverter circuit board WARNING! DISCHARGE THE HIGH VOLATGE CAPACITORS For about 30 seconds after the oven is turned off, an electric charge remains in the high voltage capacitors in the inverter power supply circuit board. When replacing or checking parts, remove the power plug from the outlet and short the inverter output terminal of the magnetron filament terminals to the chassis ground with an insulated handle screwdriver to discharge.
Page 10
WARNING Never touch any circuit wiring with your hand or with an insulated tool during operation. 2.3. Part replacement. When any part or component is to be replaced, always ensure that the power cord is removed from the wall outlet. 2.4.
MICROWAVE ENERGY IMPORTANT NOTICE The following components have potentials above 2000V while the appliance is operated. - Magnetron - High voltage transformer (Located on inverter (U)) - High voltage diodes (Located on inverter (U)) - High voltage capacitors (Located on inverter (U)) Pay special attention to these areas.
Page 12
monitor circuit and all latch switches again by following the component test procedures. 3.2. Measurement of microwave output The output power of the magnetron can be determined by performing IEC standard test procedures. However,due to the complexity of IEC test procedures, it is recommended to test the magnetron using the simple method outlined below.
4. The normal temperature rise at High power level for each model, is as shown in table. TABLE (1L-1min.test) RATED OUTPUT TEMPERATURE RISE 1000W Min.8.6°C 4. EXPLODED VIEW AND PARTS LIST 4.1. EXPLODED VIEW 4.2. PARTS LIST NOTE: 1. When ordering replacement part(s), please use part number(s) shown in this part list.
Page 14
- “A“ parts are supplied by CSD (Japan) - “F“ parts are supplied by PHAMOS (China) Ref. No. Part No. Part Name & Description Pcs/Set Remarks F01506W50XP NO TOUCHING LABEL F00066V00HP CAUTION LABEL EXCEPT ZPE F00066W10ZP CAUTION LABEL F00076V50SHP NAME PLATE C784MF HPE F00076V50SMP NAME PLATE C784MF MPQ...
Page 15
Ref. No. Part No. Part Name & Description Pcs/Set Remarks A61785180AP MICRO SWITCH (L-2C2-2)(SHORT SWITCH) A62304210BP FUSE 10A,250V F63265U00XN TURNTABLE MOTOR F64504J00XN SENSOR COVER B F65434X80MN SENSOR COVER C F65854Y60XN INVERTER BRACKET F67634X80MN INVERTER BRACKET B F66624X80MN GROUNDING PLATE A62314000AP FUSE HOLDER EXCEPT STM , ZPE F900C5E60YK...
