Powered Wheelchair
USER MANUAL
EN
Puma 40
9006403I

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Quickie Puma 40 and is the answer not in the manual?

Questions and answers

Related Manuals for Sunrise Medical Quickie Puma 40

Summary of Contents for Sunrise Medical Quickie Puma 40

  • Page 1 Powered Wheelchair USER MANUAL Puma 40 9006403I...
  • Page 2 Puma 40...
  • Page 3 The information provided is valid for the product in its standard version. Sunrise Medical can therefore not be held liable for any damage resulting from specifi cations of the product deviating from the standard confi...

  • Page 4: Table Of Contents

    Puma 40 Table of contents Introduction..........................7 This user manual For further information Symbols used in this manual Safety ............................8 Temperature Electromagnetic radiation Moving parts General description ........................10 Main components Confi gurations Intended use Area of application User environment Use of the wheelchair .......................13 Adjustment options Checking the wheelchair before use Getting in and out of the wheelchair (transfer)
  • Page 5 Puma 40 Technical specifi cations ......................30 CE declaration and requirements Technical information Labelling ...........................32 10.1 Markings on the wheelchair Accessories ..........................33 Warranty ...........................34...
  • Page 6 Puma 40...

  • Page 7: Introduction

    Medical dealer if you have any questions regarding the use, maintenance or safety of your wheelchair. In case there is no authorised dealer in your area or you have any questions, contact Sunrise Medical either in writing or by telephone.

  • Page 8: Safety

    Puma 40 Safety 2.2 Electromagnetic radiation The standard version of your electric Warning! wheelchair has been tested for compliance Always follow the instructions given next to with the applicable requirements regarding the warning symbols! Not following these electromagnetic radiation (EMC requirements). instructions may result in physical injury, damage to the wheelchair or damage to the environment.

  • Page 9: Moving Parts

    Puma 40 2.3 Moving parts Warning! Contact with the moving parts of the wheelchair should be avoided. A wheelchair has moving and rotating parts. Contact with moving parts may result in serious physical injury or damage to the wheelchair. Moving/rotating parts (fi gure 1): 1.

  • Page 10: General Description

    Puma 40 General description Comfort is of paramount importance to many people who make use of a wheelchair. And this is exactly what this electrical driven wheelchair off ers: an unknown degree of driving comfort. A distinctive feature is the unique independent suspension system, which absorbs not only shocks, but also vibrations.

  • Page 11: Area Of Application

    Please DO NOT use or fi t any 3rd party to operate the chair and its functions in a safe components to the wheelchair unless they are way. offi cially approved by Sunrise Medical. When considering provision, please also note the body size, weight including the distribution Warning! of body weight, the user’s physical and...
  • Page 12 Prevent the wheelchair from coming into contact with sand: sand can permeate into Sunrise Medical is ISO 9001 certifi ed, which the moving parts of the wheelchair, causing ensures quality at all stages of the development unnecessary fast wear of these parts.

  • Page 13: Use Of The Wheelchair

    Puma 40 Use of the wheelchair 4.1 Adjustment options The wheelchair can be supplied with the following mechanical and/or electrical adjustment options which can be made by the user without the use of tools: Mechanical adjustment options  Seating system) 1.

  • Page 14: Getting In And Out Of The Wheelchair (Transfer)

    Puma 40 (see 4.6 Pushing the wheelchair). Note! Before use, always check to see whether clothing or accessories could come into contact with wheels or other moving and/ or rotating parts in which they could become entangled. The capacity of batteries is reduced in winter. During a period of light frost, the capacity is roughly 75% of the normal capacity.

  • Page 15: Driving The Wheelchair

    Puma 40 Sideways transfer Removing the armrest assembly (fi gure 8) 1. Tip (A) downwards. 2. Remove (B). Folding back the armrest assembly (fi gure 9) 1. Press (A). 2. Fold (B) to the rear. Caution! Remove the tray before folding back the armrest.
  • Page 16 Puma 40 back to make an emergency stop. Warning! Stopping distance: When driving on a slope, always drive • 6 km/h: 1 meter carefully and with the utmost concentration. • 10 km/h: 2 meter • 12.5 km/h: 3.1 meter Avoid sudden, jerky movements. Avoid making emergency stops on a slope.

  • Page 17: Obstacles

    Puma 40 4.5 Obstacles Driving up a kerb 1. Choose the place where the kerb is at its lowest. 2. Drive straight up to the kerb at a right angle to it (20 cm in front of the kerb). 3. Move the joystick forwards. Drive up the kerb without changing direction.

  • Page 18: Storage After Use

    Puma 40 Warning! 4.7 Storage after use The freewheel switch should only be operated by the attendant and never by the When the wheelchair is not in use, it must user. be stored in a dry place where it will not be exposed to weather conditions.

  • Page 19: Settings

    The average wheelchair user does not exist. Depending on the specifi c circumstances of the This is why Sunrise Medical wheelchairs can user of the wheelchair the seat height can be be adjusted according to the specifi c needs of set.

  • Page 20: Centre Of Gravity Setting

    Changing the wheelchair’s centre of gravity may negatively infl uence the wheelchair’s driving characteristics and/or its dynamic stability. In case of doubt, contact the technical support department at Sunrise Medical. 5.4 Controller height and depth  Seating system) 5.5 Control system programme...

  • Page 21: Transport

    Puma 40 Transport 6.1 Transport without occupant Parts of the wheelchair that can easily be detached should be removed when transporting the wheelchair (fi gure 12)  Seating system). A. Remove the seat B. Remove the legrests C. Remove the armrests D.

  • Page 22: The Wheelchair As A Passenger Seat In A Car With Straps

    Puma 40 • 4.6 Så här skjuts rullstolen framåt • How to lock/unlock the controller (if  applicable, see Controller chapter "7 Locking the controller"). • How to remove the fuse (see fi gure 13). 1. Remove the cover between the castor wheels 2.
  • Page 23 Puma 40 Warning! Transfer to a regular car seat if possible. Always ask the transporter for confi rmation that the vehicle is suitably designed, insured and equipped for transporting a person in a wheelchair. Set the wheelchair in the standard position (see 4.1 Adjustment options) and use the headrest if the wheelchair is fi...
  • Page 24 Puma 40 Warning! A. The wheelchair should be in a forward facing direction and secured in accordance with the instructions from the manufacturer of the fastening system. B. This wheelchair is approved for use in cars and meets the requirements for forward facing transport and head on collisions.
  • Page 25 Puma 40 Fastening the seat belt Warning! Use the three-point seat belt in order to reduce the risk of head and chest injuries in the event of the wheelchair colliding with parts of the car. Care should be taken when applying the occupant restraint.

  • Page 26: Maintenance Plan

    Puma 40 Maintenance 7.2 Batteries The wheelchair’s lifespan is dependent on it The wheelchair uses two 12V non-spillable ‘dry’ being well maintained. gel batteries in series. These batteries are fully For information concerning specifi c settings, sealed and require no maintenance. maintenance or repair work, please contact Note! your dealer.

  • Page 27: Tyres

    Puma 40 7.3 Tyres Maintaining the batteries Note! To ensure that your wheelchair functions Ensure that the batteries are always fully properly, it essential that the tyres are kept at charged. Not using the batteries for an the correct pressure. The correct pressure is extended period of time can damage them.

  • Page 28: Cleaning And Desinfection

    Puma 40 7.4 Cleaning and desinfection 7.5 Used products and the environment Please consult the user manual for the seating system for information about cleaning the Under normal use and with prescribed  seating system ( Seating system). maintenance, the wheelchair’s expected lifespan is approximately 5 years.

  • Page 29: Troubleshooting

    Puma 40 Troubleshooting If the wheelchair is not working as it should, check the following points. • Check whether the batteries are charged. • Turn the wheelchair off and then back on again. • Check whether the battery plugs are all securely in place.

  • Page 30: Technical Specifi Cations

    The Puma 40 meets the crash test requirements as 102 kg (16.1 st.) (2008) described in ISO 7176-19 (2008) Sunrise Medical declares that this product fulfi ls the performance requirements for a “Crash Test” to ISO 7176- 9.2 Technical information ...
  • Page 31 Puma 40 Model Puma 40 Sedeo Pro Class Maximum user weight kg (st.) 160 (25.2) 160 (25.2) Total length including legrests mm (inch) 1190 (46.9) 1115 (43.9) Total width 12.5” drive wheels mm (inch) 610 (24) Total width 14” drive wheels mm (inch) 655 (25.8) kg (st.)

  • Page 32: Labelling

    Puma 40 10 Labelling 10.1 Markings on the wheelchair Note! Never remove or cover up the markings, symbols and instructions affi xed to the wheelchair. These safety features must remain present and clearly legible throughout the entire lifespan of the wheelchair. Replace or repair any markings, symbols or instructions that have become illegible or damaged immediately.

  • Page 33: Accessories

    Puma 40 11 Accessories Diff erent colour options (only for Puma 40) • Aluminium silver • Lime green • Sky blue • Fresh orange Accessories A. Lap strap (short or long) B. Mirror C. Cane/crutch holder for 2 walking canes D.

  • Page 34: Warranty

    * Means the Sunrise Medical facility from which the product was purchased. Additional Notes For Australia Only: i. For goods provided by Sunrise medical Pty Ltd in Australia, our goods come with a guarantee by Sunrise Medical that cannot be excluded under Australian Consumer Law.
  • Page 35 Puma 40...
  • Page 36 Sunrise Medical HCM B.V. Vossenbeemd 104 5705 CL Helmond The Netherlands T: +31 (0)492 593 888 E: customerservice@sunrisemedical.nl www.SunriseMedical.nl www.SunriseMedical.eu (International) Sunrise Medical Thorns Road Brierley Hill West Midlands DY5 2LD United Kingdom T: +44 (0) 845 605 66 88 E: enquiries@sunmed.co.uk...
