Pyle PDWM92 User Manual

PDWM92
Professional VHF Headset Microphone
Pro Audio Wireless Beltpack Mic Transmitter System with Adapter Receiver

INSTRUCTIONS

RECEIVER

Battery Cover
OFF
ON
LED
ANT
Belt-Pack Transmitter

HOW TO USE?

1. Open the battery cover of the receiver, put 1AA battery inside the battery compartment. Make sure the "+ -"
polar is correct.
2. Turn ON/OFF switch to ON, the LED indicator is lit. Then insert the 1/4"(6.3mm) Input Jack into audio input
socket, the LED indicator is become brighter after receiving RF signals.
3. Turn ON the transmitter switch, the LED indicator is lit. Now the system is ready to use
Notice:
1. If there is any noise, distortion, dead points when using the this system, it may be caused from low battery,
please replace with new battery.
2. After using it, please turn the switch to "OFF".
3. If you will not use this system for a long time, please take out the batteries.
www.PyleUSA.com
1/4"(6.3mm) input Jack
Headset Mic input
Headset Microphone
