Barcode scanner
LBR100
User's and installation manual
- 1 -

Advertisement

Table of Contents
loading

Related Manuals for HCP LBR100

Summary of Contents for HCP LBR100

  • Page 1 All manuals and user guides at all-guides.com Barcode scanner LBR100 User’s and installation manual - 1 -...
  • Page 2 HCP reserves the right to make changes in specifications and other information contained in this document without prior notice, and the reader should in all cases, consult the HCP to determine whether any such changes made. HCP will not be liable for technical or editorial errors or omissions contained herein: nor for incidental or consequential damages incurred when using this manual.

  • Page 3: Table Of Contents

    All manuals and user guides at all-guides.com Content Device overview..........................- 4 - Cable installation i removal.........................- 5 - Technical specification........................- 6 - Scanning tips ............................- 6 - 1. Cable connection ..........................- 7 - 2. Scanner handling..........................- 7 - 3. Setup procedure ..........................- 8 - 3.

  • Page 4: Device Overview

    All manuals and user guides at all-guides.com Installation Device overview - 4 -...

  • Page 5: Cable Installation I Removal

    All manuals and user guides at all-guides.com Installation Cable installation i removal RS - 232C Serial COM Port USB Port - 5 -...

  • Page 6: Technical Specification

    All manuals and user guides at all-guides.com Technical specification Light Source: Visible Laser Diode 650nm Scan Precision: 0.10mm (4mil) Scan Speed: 100 times/second ∠ 45º Scan Depth of field : 25-250mm (0.33.PCS90%) ∠ 60º Scan Angle: Elevation Angle: Input Voltage: 5V DC Working electricity: 100mA...

  • Page 7: Cable Connection

    All manuals and user guides at all-guides.com 1. Cable connection *USB interface scanner installation Make sure that the scanner has the correct cable for your system. Connect the cable to the USB port of the PC or POS. *RS-232C interface scanner installation Make sure that there is a power supply to the scanner (If necessary).

  • Page 8: Setup Procedure

    All manuals and user guides at all-guides.com Right Wrong 3. Setup procedure The general procedure to program is as follows: Scan the command symbol “Program”, Scan one or more parameters, Scan the command symbol “End” to close procedure. Example 1. To set RS 232 parameters 9600,N,8,1 (Page 7 - 9) Scan the barcode “Program”, Scan “9600”...

  • Page 9: Default Setting

    All manuals and user guides at all-guides.com Programming Program 3. Default setting (*) denotes default setting Default 4. Interface selection USB * RS – 232C Wand Emulation Reserved1 Reserved2 Reserved3 Reserved4 - 9 -...

  • Page 10: Keyboard Interface

    All manuals and user guides at all-guides.com Programming 5. Keyboard interface 5 - 1. Device selection IBM PC/XT IBM PC/AT* IBM PC/PS2 LAPTOP 5 - 2. Function code selection Function key On* Function key Off Lower Case* Upper Case Num-Lock Off* Num-Lock On - 10 -...
  • Page 11 All manuals and user guides at all-guides.com Programming Program 5 - 3. Language German French Swiss Swedish Japanese Spanish Norwegian Italian Universal - 11 -...

  • Page 12: Rs-232 Setting

    All manuals and user guides at all-guides.com Programming 5 - 4. Scancode delay AT delay XT delay Example: If scanner needs 15 ms of delay, scan “Program” “AT Delay” “1” “5” “AT Delay” “End” Keycode Fast Transmission* Keycode Slow Transmission 6.
  • Page 13 All manuals and user guides at all-guides.com Programming Program 6 - 2. Parity Even None* 6 - 3. Data bits 7Bits 8Bits* 6 - 4. Stop bit 1Bit* 2Bits - 13 -...
  • Page 14 All manuals and user guides at all-guides.com Programming 6 - 5. Hand shaking ACK/NAK On ACK/NAK Off* RTS/CTS On RTS/CTS Off* Wait Timeout Example: If delay time of 30ms, is required, scan “Program” “Wait timeout” “3” “0” “Wait timeout” “End”. - 14 -...

  • Page 15: Wand Emulation

    All manuals and user guides at all-guides.com Programming Program 7. Wand emulation 7 - 1. Output level Transmit Wand Emulation as Code 39* 7 - 2. Output polarity White High Black High* 7 - 3. Scan speed Low(2ms) Medium (1ms) Fast (0,5ms)* 7- 4.

  • Page 16: Data Format

    All manuals and user guides at all-guides.com Programming 8. Data Format 8 - 1. Terminator TAB(CR/LF) Enter(CR)* Return(LF) None 8 - 2. Code ID None* User defined Default Example: If barcode ID for code39 (standard) defined as “U”, scan “Program” ”User defined”...
  • Page 17 All manuals and user guides at all-guides.com Programming Program 8 – 3. Code ID Setting Define Code ID Code 39(M) (Full ASCII) Code 39(M) (Standard) EAN – 13(F) UPC – A(A) EAN – 8(F) UPC – E (E) Code 93(L) - 17 -...
  • Page 18 All manuals and user guides at all-guides.com Programming Codabar (N) Code 128 (K) I 2 of 5 (I) S 2 of 5 (H) D 2 of 5 (H) M 2 of 5 (H) China postage (C) Code 3 of 5 (P) MSI/Plessey (O) Code 11 (J) - 18 -...
  • Page 19 All manuals and user guides at all-guides.com Programming Program 8 - 4. Custom setting Single edit mode Select from left Select from right Custom mode Enable Example: If 5 digits from the left are required, scan “Program” “Single edit mode” “Select from left” “0” “5” “Select from left” “Single edit mode” “Custom mode enble”...
  • Page 20 All manuals and user guides at all-guides.com Programming 8 - 5. Data length Exclude* Include 8 - 6. Preamble/Postamble Preamble Postamble Example: If preamble “SN” before data is required, scan “Program” “Preamble” “S” “N” “Preamble” “End”. Reserved1 Reserved2 Reserved3 - 20 -...

  • Page 21: Barcode Setting

    All manuals and user guides at all-guides.com Programming Program 9. Barcode setting 9 - 1. Code39 Code 39 Enable* Code 39 Disable Full ASCII Code 39* Standard Code 39 Code 32 Enable Code 32 Disable* Verify Check & Transmit Verify Check & Not Transmit Not Verify Check* - 21 -...
  • Page 22 All manuals and user guides at all-guides.com Programming 9 - 2. Interleaved 2 of 5 I 2 of 5 Enable* I 2 of 5 Disable Fix Length On Fix Length Off* 1st Dig. Suppress Last Dig. Suppress No Suppress* Example: If barcode length needs to be fix, scan “Program“ “Fix Length On“ “End“...
  • Page 23 All manuals and user guides at all-guides.com Programming Program I 2 of 5 Verify Check & Transmit I 2 of 5 Verify Check & Not Transmit I 2 of 5 Not Verify Check* Code 3 of 5 Enable Code 3 of 5 Disable* Code 3 of 5 Transmit Check Code 3 of 5 Not Transmit Check* - 23 -...
  • Page 24 All manuals and user guides at all-guides.com Programming 9 - 3. Standard 2 od 5 S 2 of 5 Enable S 2 of 5 Disable* Fix Length On Fix Length Off* Verify Check & Transmit Verify Check & Not Transmit Not Verify Check* - 24 -...
  • Page 25 All manuals and user guides at all-guides.com Programming Program 9 - 4. Industrial 2 od 5 D 2 of 5 Enable D 2 of 5 Disable* Fix Length On Fix Length Off* Verify Check & Transmit Verify Check & Not Transmit Not Verify Check* - 25 -...
  • Page 26 All manuals and user guides at all-guides.com Programming 9 - 5. Matrix 2 od 5 M 2 of 5 Enable M 2 of 5 Disable* Fix Length On Fix Length Off* Verify Check & Transmit Verify Check & Not Transmit Not Verify Check* - 26 -...
  • Page 27 All manuals and user guides at all-guides.com Programming Program 9-6. China postage China postage Enable China postage Disable* Fix Length On Fix Length Off* Verify Check & Transmit Verify Check & Not Transmit Not Verify Check* - 27 -...
  • Page 28 All manuals and user guides at all-guides.com Programming 9 - 7. Code 128 Code 128 Enable* Code 128 Disable EAN - 128 Enable EAN - 128 Disable* EAN - 128 Separator set Check digit Enable* Check digit Disable 9 - 8. Code 93 Code93 Enable* Code 93 Disable - 28 -...
  • Page 29 All manuals and user guides at all-guides.com Programming Program 9 - 9. UPC – A UPC – A Enable* UPC – A Disable Leading Digit On* Leading Digit Off Add Leading Zero On Add Leading Zero Off* Transmit Check Digit* Not Transmit Check Digit - 29 -...
  • Page 30 All manuals and user guides at all-guides.com Programming 9 - 10. UPC - E UPC - E Enable* UPC - E Disable Leading Digit On* Leading Digit Off Transmit Check Digit* Not Transmit Check Digit Zero Expansion On Zero Expansion Off* - 30 -...
  • Page 31 All manuals and user guides at all-guides.com Programming Program 9 - 11. EAN - 8 EAN – 8 Enable* EAN – 8 Disable Leading Digit On* Leading Digit Off Transmit Check Digit* Not Transmit Check Digit - 31 -...
  • Page 32 All manuals and user guides at all-guides.com Programming 9 - 12. EAN - 13 EAN - 13 Enable* EAN - 13 Disable Leading Digit On* Leading Digit Off Transmit Check Digit* Not Transmit Check Digit ISBN Enable ISBN Disable* - 32 -...
  • Page 33 All manuals and user guides at all-guides.com Programming Program 9 - 13. UPC / EAN Supplements Addenda 2 Digit Enable Addenda 2 Digit Disable* Addenda 5 Digit Enable Addenda 5 Digit Disable* ISBN Addenda Enable ISBN Addenda Disable* Space Separator Enable Space Separator Disable* Transmit if Present Must Present...
  • Page 34 All manuals and user guides at all-guides.com Programming 9 - 14. Codabar Codabar Enable* Codabar Disable Not Transmit Start & Stop Transmit Start & Stop ABCD* Transmit Start & Stop TN*E Verify check & Transmit Verify check & Not Transmit Not Verify check* - 34 -...
  • Page 35 All manuals and user guides at all-guides.com Programming Program 9 - 15. MSI / Plessesy Code MSI Enable* Code MSI Disable Code Plessey Enable* Code Plessey Disable Transmit Check Digit Not Transmit Check Digit* MSI Check Digit MOD 10* MSI Check Digit MOD 11 MSI Check Digit MOD 1010 MSI Check Digit MOD 1110 - 35 -...

  • Page 36: Reading Mode

    All manuals and user guides at all-guides.com Programming 10. Reading mode Trigger On/Off * Normal Auto-Trigger Light Toggle – Auto Trigger Object Detection Light flashing Twice checking Testing 11. Redundancy None* 2 Times 3 Times 4 Times - 36 -...

  • Page 37: Beep Tones

    All manuals and user guides at all-guides.com Programming Program 12. Beep tones None Medium High* Beep duration short Beep duration medium Beep duration long Beep tone adjust Example: If beep tone of 230us is required, scan “Program“ pa “ Beep tone adjust“...

  • Page 38: Intercharacter Delay

    All manuals and user guides at all-guides.com Programming 13. Intercharacter delay None* 1 ms 10ms 20ms 50ms 100ms - 38 -...

  • Page 39: Intermessage Delay

    All manuals and user guides at all-guides.com Programming Program 14. Intermessage delay None * 50ms 200ms 500ms 1sec 2sec - 39 -...

  • Page 40: Set Max. & Min. Length

    All manuals and user guides at all-guides.com Programming 15. Set max. & min. Length Set Max & Min Code 39 (1~64) Code 128 (4~64) Code 93 (4~64) Codabar (4~64) I 2 of 5 (4~64) S 2 of 5 (4~64) D 2 of 5 (4~64) Example: If max Length of code 39 isto be set 15 digits, scan “Program“...
  • Page 41 All manuals and user guides at all-guides.com Programming Program M 2 of 5 (4~64) Code 3 of 5 (6~7) MSI/Plessey (4~64) Code 11 (4~64) China postage (6~64) - 41 -...

  • Page 42: Barcode Space Setting

    All manuals and user guides at all-guides.com Programming 16. Barcode space setting - 42 -...

  • Page 43: Minimum Bar Numbers

    All manuals and user guides at all-guides.com Programming Program 17. Minimum bar numbers - 43 -...

  • Page 44: Show Status

    All manuals and user guides at all-guides.com Programming 18. Show status Display the edition Information (If want to display the edition Information, please scan “Program“ “Display the edition Information“ “End“) Reserved1 Reserved2 Reserved3 Reserved4 Reserved5 Reserved6 Reserved7 - 44 -...

  • Page 45: Appendix

    All manuals and user guides at all-guides.com Appendix 19. Appendix 19 – 1. Pin assignment RJ45 connector RJ45 pins Function Barkod Tx (TTL) Barkod Rx (TTL) PC D+ (USB) PC D- (USB) +5V DC - 45 -...
  • Page 46 All manuals and user guides at all-guides.com Appendix Note: For LBR100 must only use specificated cabels for connecting which are inside the package. LBR100U – USB A tip to RJ45 LBR100R – SUB DB9 tip na RJ45 with dc connector...
  • Page 47 +5V DC Note: Power supply of Bacode Scanner LBR100, AC/DC adapter +5Vdc/300mA, plug on DC connector which is placed on SUB DB9 connector housing. Pin 9 on SUB DB9 connector give's +5V. Some Electronic cash registers provide +5V on pin 9 of the serial port connector, in that case the AC/DC is not needed.
  • Page 48 All manuals and user guides at all-guides.com Appendix 20 – 2. ASCII TABLE ASCII HEX DEC ASCII HEX DEC “ & ‘ < > - 48 -...
  • Page 49 All manuals and user guides at all-guides.com Appendix ASCII HEX DEC ASCII HEX DEC - 49 -...
  • Page 50 All manuals and user guides at all-guides.com Appendix 20 – 3. FULL ASCII TABLE “ & ‘ - 50 -...
  • Page 51 All manuals and user guides at all-guides.com Appendix < > - 51 -...
  • Page 52 All manuals and user guides at all-guides.com Appendix - 52 -...
  • Page 53 All manuals and user guides at all-guides.com Appendix - 53 -...
  • Page 54 All manuals and user guides at all-guides.com Appendix - 54 -...
  • Page 55 All manuals and user guides at all-guides.com Appendix - 55 -...
  • Page 56 All manuals and user guides at all-guides.com Appendix - 56 -...
  • Page 57 All manuals and user guides at all-guides.com Appendix - 57 -...
  • Page 58 All manuals and user guides at all-guides.com Appendix F8(@H) F1(@A) F9(@I) F2(@B) F10(@J) F3(@C) F11(@K) F4(@D) F12(@L) F5(@E) HOME(&A) F6(@F) END(&B) F7(@G) Cursor Right(&C) - 58 -...
  • Page 59 All manuals and user guides at all-guides.com Appendix Cursor Left(&D) Enter(&L) Cursor Up(&E) Return(&O) Cursor Down(&F) CTRL ON(&P) PgUp(&G) CTRL OFF(&Q) PgDn(&H) ALT ON(&R) TAB(&I) ALT OFF(&S) Back TAB(&J) SHIFT ON(&T) ESC(&K) SHIFT OFF(&U) - 59 -...

  • Page 60: Sample Bar Codes

    All manuals and user guides at all-guides.com Appendix Sample bar Codes Code 39 S N0 0 0 1 0 1 3 0 0 0 7 Codabar $- : +. / 1018009 Interleaved 2 of 5 99078006500123456789012345 MSI/Plessey 12345678901237 UPC – A with 5 8 0 1 2 3 4 5 6 7 8 EAN –...
