Radar Integration
Transform your Seiwa chartplotter into an integrated radar display!
Easily connect WiFi radar antennas to Seiwa navigation systems for visual situational awareness, fully integrated with
electronic charts, AIS and other onboard features.
• Compatibility of select radar antennas with the Seiwa family of multi-function chartplotters, including the Explorer 23, as
well as the SWx 9" and 12" systems*
• Instant connectivity with compatible radar antennas via fast and easy WiFi link from your chartplotter
• Dedicated radar page for configuration, tuning and display of radar image onscreen
• Split screen mode with radar and chart screens side-by-side for clear viewing and quick comparison
• Radar overlay mode for viewing radar image draped over chart display
• Multiple orientation modes for flexible display (North Up, Heads Up, Course Up)
• Full radar antenna control and configuration, including Automatic and Manual tuning modes
• Anti-clutter modes help to compensate for sea and rain interference
• Echo stretch to magnify targets for easier viewing
• Overlay and full info for AIS and DSC targets, as well as user marks, events and routes
Onscreen radar tools:
1
2
3
4
* Radar implementation is available on chartplotters running software version 5.2.0 or greater.
www.seiwadirect.com
• Parallel Cursor
1
• Variable Range Marker (VRM)
2
5
• Range Rings
3
• Range Databox
4
6
• TX / Stand-by Icon
5
7
• Guard Zones
6
8
• Heading Line
7
• Electronic Bearing Line (EBL)
8
