  • Page 1 WARNING AND INSTALLATION MANUAL...

  • Page 2: Warranty And Warnings

    1. Warranty and warnings AvMap Srl warrants every unit to be free from defects in material and workmanship under normal use and service for a period of 24 months from original retail purchase. During the warranty period, AvMap Srl will repair or replace any component which fails in normal use without charges for parts or labour.

  • Page 3: Installation

    2. Installation 2.1 Bracket Mount 20 mm 4 holes [0.8”] Ø 5 mm [0.2”] 20 mm [0.8”] 260 mm 2.2 Panel Mount [10.2”] 136 mm [5.3”] 141 mm [5.5”] 265 mm [10.4”] 4 holes Ø 5 mm [0.2”] 2.3 How to insert the MicroSD...
  • Page 4 3. Keyboard The joystick can move the cursor around the map or through menu items. Press [UP], [DOWN], [LEFT] or [RIGHT]. Each button – except for MOB – can perform two functions: a short press performs the function labeled on the button; a long press (hold) executes the second function labeled on the unit face (for Power key is the opposite).

  • Page 5: Connections Scheme

    4. Connections scheme NMEA 2000 Connector FUNCTION NOT CONNECT FF Transducer* POWER + FUNCTION POWER - XDR POSITIVE SIGNAL H XDR SHIELD TEMP SIGNAL L GPS Connector (Port C) FUNCTION POWER OUTPUT + (10-35 Vdc) XDR NEGATIVE OUTPUT C SPEED INPUT C * SWx 900cw NOT CONNECT...
  • Page 6 4.2 Autopilot Connections Autopilot on Port A POWER & I/O CABLE Wire Color Function Black PWR-/GND POWER INPUT + (10-35 Vdc) COMMON AUTOPILOT Green COMMON Yellow OUTPUT A Autopilot on Port B POWER & I/O CABLE Wire Color Function Black PWR-/GND POWER INPUT + (10-35 Vdc) COMMON...
  • Page 7 4.4 NMEA0183 Connections External NMEA on Port A POWER & I/O CABLE Wire Color Function Black PWR-/GND POWER INPUT + (10-35 Vdc) White INPUT A EXTERNAL COMMON NMEA Green COMMON DEVICE Yellow OUTPUT A External NMEA on Port B POWER & I/O CABLE Wire Color Function Black...

  • Page 8: Fcc Compliant

    6. Product conformity information 6.1 FCC compliant This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
