  • Page 1 TAIPAN THERMAL IMAGING MONOCULAR USER MANUAL...
  • Page 2 AGM Global Vision. If you have questions that are not covered in this manual, or need service, contact AGM Global Vision customer support for additional information prior to returning a product. AGM Global Vision...
  • Page 3 (Cd), lead (Pb), or mercury (Hg). For proper recycling, return the battery to your supplier or to a designated collection point. For more information see: www.recyclethis.info INDUSTRY CANADA ICES-003 COMPLIANCE This device meets the CAN ICES-3 (B)/NMB-3(B) standards requirements. TAIPAN USER MANUAL...

  • Page 4: Table Of Contents

    1.2 Key Features 1.3 Standard Components 2. OPERATING INSTRUCTIONS 2.1. Basic Operations 2.2 Main Function 2.3 Client Software Introduction 3. MAINTENANCE 3.1 Maintenance 3.2 Troubleshooting 4. WARRANTY INFORMATION 4.1 Warranty Information and Registration 5. SPECIFICATIONS 5.1 Specifications AGM Global Vision...

  • Page 5: Safety Summary

    EMERGENCY: If smoke, odor, or noise arises from the device, immediately turn off the power, unplug the power cable, and contact the service center. TAIPAN USER MANUAL...

  • Page 6: General Information

    1 GENERAL INFORMATION SYSTEM DESCRIPTION The Taipan handheld observational thermal monocular is equipped with a 384×288 infrared detector and a 1280×960 LCOS display. It supports functions of observation, highest temperature target tracking, distance measurement, Wi-Fi hotspot, and so on. The high-sensitivity built-in thermal detector provides you with clear view even in total darkness.

  • Page 7: Key Features

    The ITEM NO. column indicates the number used to identify items in Figure 1-2. FIGURE 1-2. STANDARD COMPONENTS TABLE 1-2. STANDARD COMPONENTS ITEM NO. DESCRIPTION QUANTITY Monocular USB Cable Lanyard AC Power Adapter/Charger Lens Cloth Operation Manual TAIPAN USER MANUAL...

  • Page 8: Operating Instructions

    When you see the Low Battery status, charge the monocular and ensure it’s working properly. NOTE: Please charge the monocular with the delivered USB cable and power adapter. The charging temperature should be 0°C to 45°C (32°F to 113°F). BATTERY STATUS INTERFACE INDICATOR FIGURE 2-1. TAIPAN CHARGING AGM Global Vision...
  • Page 9 2.1.3 CONTROL BUTTONS The Taipan controls are shown in Figures 2-2 and are defined in Tables 2-2. Each button is responsible for some functions selected by short press or long press the button. Pushing a button for 2+ second is considered “long press/ hold.”...
  • Page 10 RING DIOPTER ADJUSTMENT KNOB FIGURE 2-4. DIOPTER AND FOCUS ADJUSTMENT 4. Point the monocular towards the target of the view. Bring the object into focus by rotate the objective focus ring (only for 19mm and 25mm lens). AGM Global Vision...
  • Page 11 8× digital zoom (8× option is available only for TM384 model). 2.1.9 RECORD/CAPTURE Video Recording In the main live view, hold button and start recording. In the upper left corner, the recording time displays. Hold button again to stop recording. FIGURE 2-5. VIDEO RECORDING TAIPAN USER MANUAL...

  • Page 12: Main Function

    4 seconds to display the menu. Press buttons to move between menu items. The active element is highlighted in orange. Press button to select menu item or change an option. FIGURE 2-6. THE MAIN MENU AGM Global Vision...
  • Page 13 CVBS CVBS Output function. CVBS Press to select the language LANGUAGE Languages of interface. Press to view the firmware VERSION version number and serial number. Press to restore the device to RESTORE defaults. TAIPAN USER MANUAL...
  • Page 14 4. Search the client software on App Store (iOS System) or Google Play (Android System) to download and install the app. T-Vision APP is recommend. 5. Open the APP and connect your phone with the device. You can view the interface of monocular on your phone. AGM Global Vision...
  • Page 15 The cursor blinks on the top edge of the target. 5. Align the center of bottom mark with the edge of target bottom. Press The left top of the image displays the distance measurement result and the height of the target. FIGURE 2-7. DISTANCE MEASUREMENT TAIPAN USER MANUAL...
  • Page 16 CVBS Output function doesn’t support hot plug, so please connect the cable before power on. 2. Hold button to show the menu. 3. Select CVBS menu item and press button to turn on or turn off the CVBS video output. AGM Global Vision...

  • Page 17: Client Software Introduction

    OSD menu. 2. Move the cursor to menu item and press the button to restore all parameters to default settings. 1. Open the APP and connect the phone or pad with the device. Taipan TM160 TAIPAN USER MANUAL...
  • Page 18 3. When the device is added, the live view can be seen. You can view the interface of the monocular on the software. User can change such image parameters as brightness, contrast, zoom, palettes directly via phone or pad as well as record video on phone/pad memory. AGM Global Vision...

  • Page 19: Maintenance

    1. Connect the device to your PC with USB cable. 2. Open the detected disk, copy the upgrade file and paste it to the root directory of the device. 3. Disconnect the device from your PC. 4. Reboot the device. TAIPAN USER MANUAL...

  • Page 20: Troubleshooting

    2. If you use other USB cables, make sure the cable monocular. length is no longer than 1 m. 3. Whether the Wi-Fi function is turned on. If so, go to OSD menu and turn off Wi-Fi. AGM Global Vision...

  • Page 21: Warranty Information

    Customer or by any party other than AGM Global Vision without prior written consent of AGM Global Vision; (d) is the result of a special order or categorized as “close-out” merchandise or merchandise sold “as-is” by either AGM Global Vision or the AGM Global Vision dealer;...
  • Page 22 AGM Global Vision by the customer or customer’s dealer. AGM Global Vision shall not, in any event, be liable for special, indirect, incidental, or consequential...

  • Page 23: Specifications

    5 SPECIFICATIONS 5.1 SPECIFICATIONS TAIPAN TM15-384 TAIPAN TM19-384 TAIPAN TM25-384 Detector Type 12 μm Vanadium Oxide Uncooled Focal Plane Arrays Resolution 384×288 Refresh Rate 50 Hz Response Waveband 8 μm to 14 μm Lens (Focal Length) 15 mm 19 mm...
