Beghelli Cyclone Instructions page 2

DUAL UNIVERSAL AC SIGN
GREEN Ground
24 hours
Chassis GND
Unswitched Supply
BLACK 105 to 360VAC
WHITE Neutral
GREEN Ground
24 hours
Unswitched Supply
BLACK 120VAC
RED 347VAC or ORANGE 277VAC
WHITE Neutral
7
Beghelli U.S.A., 3250 Corporate Way, Miramar, Florida, Tel: (954) 442-6600 Fax: (954) 442-6677
926000190
From Generator OR
Emergency Supply
LED Board
BROWN 105 to 360VAC
BLUE Neutral
AC ONLY SIGN
Chassis GND
LED Board
NOTE: Cap unused AC Wire!
GREEN Ground
24 hours
Unswitched Supply
BLACK 120VAC
RED 347VAC or ORANGE 277VAC
WHITE Neutral
AC & UNIVERSAL DC SIGN
GREEN Ground
24 hours
Chassis GND
Unswitched Supply
BLACK 120VAC
RED 347VAC or ORANGE 277VAC
WHITE Neutral
NOTE: Cap unused AC Wire!
8
SELF-POWERED SIGN
Ni-Cd
Battery
Chassis GND
LED Board
NOTE: Cap unused AC Wire!
Emergency Supply
FROM Battery Pack
LED Board
YELLOW Positive 6 to 24VDC
PURPLE Negative
6
9
04/14/2010
