Spacetronik DIO SPD-DS81 Series User Manual

Door station

Advertisement

Quick Links

Door Station
SPD-DS81x
User's Manual
Please read this manual carefully before using the product .

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DIO SPD-DS81 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Spacetronik DIO SPD-DS81 Series

  • Page 1 Door Station SPD-DS81x User’s Manual Please read this manual carefully before using the product .
  • Page 2 1. Parts and Functions ID Card Window Connection Port LOCK Speaker Name plate Call button Microphone 110mm (4.3in) 55mm (2.1in) Press down and move left to open the transparent nameplate cover. Then insert the name paper and put the cover back. A l e Light-sensing touch button: When any object blocks the button, the button can be triggered.
  • Page 3 2. Terminal Description LOCK COM GND GND OPEN SIP1 Connection Port BUS: (L1, L2) non-polarity bus line Ÿ CAM: Extra camera connection port. Ÿ LOCK: Electronic lock connection port. Ÿ VOL: Volume adjustor. Ÿ DIP : DIP switches for system configurations. Ÿ...
  • Page 4 Make a master card Set the DIP switch to 100, then long-press the switch for 2 seconds to hear the beep sound every second, which enter the recording management card mode, swipe a new IC card, and the master card will be successfully make after a long beep sound Delete a IC card or key tag Set the DIP switch to 010, then long-press the switch for 2 seconds...
  • Page 5 3. Mounting Drill a hole and attach the rainy Attach the unit to the rainy cover The last view for all mounting cover to it correctlly 4. System Connection Single door station Power supply Router UTP5E Power Supply N NC L Model: 206A-2S Input: 100-240V~ Output: 26V...
  • Page 6 Multi Monitor Connection ID=000 ID=100 ID=010 ID=110 1 1 1 2 2 2 3 3 3 4 4 4 5 5 5 6 6 6 1 1 1 2 2 2 3 3 3 4 4 4 5 5 5 6 6 6 1 1 1 2 2 2 3 3 3 4 4 4 5 5 5 6 6 6...
  • Page 7 5. DIP Switches Settings Total 6 bits in the DIP switches can be configured. The switches can be modified either before or after installation. ON (1) OFF (0) 1 2 3 4 5 6 Bit-1,Bit-2 and Bit-3 are used for door station ID Bit-1,Bit-2 and Bit-3 are used for door station ID setting(1=on,0=off).
  • Page 8 7. Electric Lock Connection 1. The external power supply must be used according to the lock. 2. The jumper must be taken off before connecting. 3. If different unlocking time is needed, change the unlock time on door station by modifying the BIT-4 and BIT-5. Power OFF to unlock type Power OFF to unlock type SIP1...

This manual is also suitable for:

Dio spd-ds811 nfcDio spd-ds812
