Using this Manual Chapter 1 Welcome to the Thermo Scientific iCE 3000 Series AA spectrometers! Contents • About this Manual page 1-1 • Typographical Conventions page 1-2 • Reference Documentation page 1-4 • Contacting Us page 1-5 About this Manual... -
Page 8: Typographical Conventions
Using this Manual Typographical Conventions Typographical Conventions This section describes typographical conventions that have been established for Thermo Scientific manuals. Signal Words Make sure that you follow the precautionary statements presented in this manual. The special notices appear different from the main flow of text: NOTICE Points out possible material damage, data loss, impaired data quality... -
Page 9: Data Input
Using this Manual Typographical Conventions Data Input Throughout this manual, the following conventions indicate data input and output via the computer: • Messages displayed on the screen are represented by capitalizing the initial letter of each word and by italicizing each word. •... -
Page 10: Reference Documentation
Using this Manual Reference Documentation Reference Documentation In addition to this guide, Thermo Fisher Scientific provides other documents for the iCE 3000 Series AA spectrometers. Reference documentation for the iCE 3000 Series spectrometers includes the following: • iCE 3000 Series Operating Manual This manual is provided on the software CD. -
Page 11: Contacting Us
Using this Manual Contacting Us Contacting Us There are several ways to contact Thermo Fisher Scientific. You can use your smartphone to scan a QR Code, which opens your email application or browser. Contact Link / Remarks QR Code Brochures and Ordering www.thermofisher.com/AAS Information Service Contact... - Page 12 Using this Manual Contacting Us iCE 3000 Series Pre-Installation Requirements Guide (P/N 9499 500 30031, Version 1.6) Thermo Scientific...
-
Page 13: Chapter 2 Introduction
Introduction Chapter 2 This manual is designed to help ensure that your iCE 3000 Series AA spectrometer will be installed efficiently and will be able to meet your requirements quickly and completely. It will minimize installation time if the services and facilities detailed here are available before the equipment is delivered. - Page 14 Introduction iCE 3000 Series Pre-Installation Requirements Guide (P/N 9499 500 30031, Version 1.6) Thermo Scientific...
-
Page 15: Chapter 3 System Accessories
System Accessories Chapter 3 Required Accessories • Data Station. See Chapter 6, “Communications Interface”. Optional Accessories • Thermo Scientific™ GFS33 Graphite Furnace and Autosampler for iCE™ 3300 AA spectrometer • Thermo Scientific™ SOLAAR Validator Package • Thermo Scientific™ SOLAARSecurity Software •... - Page 16 System Accessories Optional Accessories iCE 3000 Series Pre-Installation Requirements Guide (P/N 9499 500 30031, Version 1.6) Thermo Scientific...
-
Page 17: Transportation
Transportation Chapter 4 Contents • Package Size page 4-2 • Short Term Storage page 4-3 • Transit Damage page 4-3 • Warranty page 4-3 The spectrometer is supplied with all compatible accessories that have been purchased to meet the customer's system requirements. Items may be shipped in separate packages. -
Page 18: Package Size
Transportation Package Size Package Size The instrument and accessories will be supplied inside especially designed packaging. Table 4-1 Table 4-2 list the dimensions and weights of the packages. Table 4-1. Dimensions and weights of packed spectrometers Spectrometer Width Depth Height Weight iCE 3500 1070 mm... -
Page 19: Short Term Storage
Transportation Short Term Storage Short Term Storage To maintain the instrument in serviceable condition and to comply with the conditions of warranty, ensure that storage of each item is maintained within the stated parameters detailed in Chapter 5, “Working Area Requirements.” Make sure that the packages are stored the correct way up. - Page 20 Transportation Warranty iCE 3000 Series Pre-Installation Requirements Guide (P/N 9499 500 30031, Version 1.6) Thermo Scientific...
-
Page 21: Working Area Requirements
Working Area Requirements Chapter 5 Contents • Introduction page 5-2 • Location page 5-3 • Environmental Requirements page 5-4 • Electrical Requirements page 5-4 • Spectrometer Size page 5-6 • Gas Requirements page 5-7 • Water Temperature Control page 5-10 •... -
Page 22: Introduction
Working Area Requirements Introduction Introduction The choice of site will be influenced by the dimensions and weights of the spectrometer and accessories. Other factors are the environment and the availability of electricity, water and gas supplies, as well as the need for a suitable ventilation system to dispose of the exhaust gases. -
Page 23: Location
Working Area Requirements Location Location The instruments are designed for use on a normal laboratory bench. See Figure 5-1. Furnace printer mouse pad 420 mm 480 mm 222 mm 780 mm 282 mm Figure 5-1. Typical location diagram for iCE 3000 Series AA spectrometers Ensure that the exhaust is correctly positioned above the LH compartment (flame, EC100, T-Cell or Mercury-Cell) and RH compartment (furnace). -
Page 24: Environmental Requirements
Working Area Requirements Environmental Requirements Ideally, the instrument should be placed on a movable bench with 50 cm of access behind the instrument. The mounting surface must be level and the instruments must not be placed on any type of cushioning as this could block ventilation. - Page 25 Working Area Requirements Electrical Requirements An additional 200/208/220-240 VAC, 1.5 kVA, 50/60 Hz is required for a Zeeman furnace power supply unit (see label near appliance inlet for individual voltage setting). Permanent Connection If the furnace is permanently connected to the mains (instead of a plug-and-socket connection), a disconnection device and suitable fusing must be provided by the building installation.
-
Page 26: Spectrometer Size
Working Area Requirements Spectrometer Size Multiple installations require separate mains supplies. Additional standard mains sockets are required for the Data Station and the printer, for an extended autosampler, for a chiller and for each additional accessory. Each electrical outlet must have an effective earth/ground connection. This protection must not be negated by using an extension cable without a protective earth conductor. -
Page 27: Gas Requirements
Working Area Requirements Gas Requirements Table 5-4. Accessory dimensions and weights, continued Accessory Width Depth Height Weight CETAC 330 mm 508 mm 610 mm 8.4 kg ASX-260 (13 in) (20 in) (24 in) (18.5 lbs) CETAC 520 mm 482 mm 610 mm 10.5 kg ASX-520... -
Page 28: Acetylene
Working Area Requirements Gas Requirements Acetylene A flame spectrometer requires acetylene at 0.62 bar (9 psi) with flow rates of between 0.8 and 5.1 L/min. The purity must be at least 98.5%, with impurities for sulfur and phosphorus of less than 15 ppm, and water of less than 100 ppm. -
Page 29: Air
Working Area Requirements Gas Requirements If pressures above 0.62 bar (9 psi) acetylene are used in the UK, the Health and Safety Executive of HM Factory Inspectorate must be informed and an Exemption Certificate obtained. Local and national regulations and guidelines must be followed at all installation sites. The spectrometer requires clean, dry compressed air at a steady pressure of 2.1 bar (30 psi), with a flow rate up to 10 L/min. -
Page 30: Water Temperature Control
Working Area Requirements Water Temperature Control A two stage regulator is required to provide good precision and stable flame conditions. It may be necessary to fit a heater to the regulator to prevent freezing, which would cause flow rate variations and an unstable flame. -
Page 31: Waste Storage
Working Area Requirements Waste Storage Waste Storage The analysis of a sample by flame atomic absorption usually involves production of a fine mist from a liquid sample. Waste is produced that could be corrosive or toxic, or an organic solvent. An appropriate container is required that is solvent proof, shatterproof and vented away from the instrument. -
Page 32: Spectrometer Fume Extraction
Working Area Requirements Spectrometer Fume Extraction Spectrometer Fume Extraction The spectrometer is designed to operate in clean air conditions. The laboratory must be free of all contaminants that could have a degrading effect on the components of the instrument. Dust, acid and organic vapors must be excluded from the work area. The warranty will be void, if the equipment is operated in substandard conditions. - Page 33 Working Area Requirements Spectrometer Fume Extraction • The hood and the first meters of the duct become hot, especially when working with a nitrous oxide flame. Thermo Fisher Scientific recommends marking the hood over the spectrometer with a hot surface marking. •...
- Page 34 Working Area Requirements Spectrometer Fume Extraction • Suitable extraction must also be used for the EC100 if used instead of a flame, and in particular for the Mercury-Cell (toxic fumes) used with no flame or EC100. For details, refer to the iCE 3000 Series Operating Manual.
-
Page 35: Sample Fume Extraction
Working Area Requirements Sample Fume Extraction Figure 5-2 shows the extraction positions of iCE 3000 Series instruments. Æ 150 Æ 80 Æ 110 Æ 250 360 mm 594 mm 788 mm 150 mm 250 mm 362 mm 588 mm 566 mm Figure 5-2. - Page 36 Working Area Requirements Sample Fume Extraction 5-16 iCE 3000 Series Pre-Installation Requirements Guide (P/N 9499 500 30031, Version 1.6) Thermo Scientific...
