- Page 1 LCD TV LT-24G20 LT-32G3 LT-32G30 LT-42G20 LT-46G20 INSTRUCTIONS LT-24G20 LT-32G30 LT-42G20 LT-46G20...
-
Page 2: Safety Precautions
Safety precautions Thank you for buying this JVC LCD panel television. To make sure you understand how to use your new TV, please read this manual thoroughly before you begin. • Follow this manual regarding setup! • Hold the TV so as not to scratch the screen! - Connect only to a 110-240 V, 50/60Hz AC outlet. -
Page 3: Table Of Contents
Safety precautions Contents Safety precautions ..........2 • If a television is not positioned in a sufficiently stable location, it can be potentially hazardous due Contents ..............3 to falling. Many injuries, particularly to children, can How to attach the stand .........4 be avoided by taking simple precautions such as: Location of controls ..........5 - Using cabinets or stands recommended by the... -
Page 4: How To Attach The Stand
How to attach the stand NOTE: • Unplug the AC cord from the AC INPUT terminal. • Before beginning this process, assure that TV is laid on a clean, safe, and cushioned space to avoid any damage to the unit. •... -
Page 5: Location Of Controls
Location of controls LT-32... 1 (LT-24...) Description of Indicators and Controls 1. Remote sensor 2. VOL+/–/◀/▶ buttons: To control volume / In Menu: Setting. 3. CH / /▲/▼ buttons: Press to change to a higher numbered channel set into memory. Press to change to a lower numbered channel set into memory. -
Page 6: Remote Control
Remote Control Function Page Enter standby mode or turn on the power Display program position number Select an input source Select picture format Select channel Select Teletext page Enter password Select between the available broadcast audio To enter Media Browser Activate the menu In menu, return 1 step / exit menu 12, 19... - Page 7 Remote Control Install the batteries Use batteries type UM4 (AAA-Size). Do not use old or weak batteries. The remote control may not work properly with a weak voltage from such batteries. Replace exhausted batteries with new ones. Never try to recharge normal batteries - this could cause an explosion.
-
Page 8: Connections
Connections Note: Before you connect other appliances: • To avoid potentially damaging your set, make sure all items are switched off and disconnected from the mains power when you make the connections. • Arrange the desired connection. • When you have finished making the connections, reconnect the mains power to the unit and switch it back on. Connect your antenna as shown below (A). -
Page 9: Auto Setup
Auto setup Quick guide for Menu operation Call Menu and for example: Select “Auto Your television has an Automatic Tuning Search”. System which makes tuning in your television easy. This Automatic tuning System scans Press INPUT SELECT. Select TV, then press the entire reception range in your area and ENTER. -
Page 10: On-Screen Language Selection
4 Press to start auto search. On-screen Language Selection Channel - Auto Search Press MENU (unless you have already selected when the set was first switched on) Then press to select “Feature”, then Channels found: Picture press . Sound Frequency : Feature 89.50 MHz Channel... -
Page 11: Basic Operation
Fastext/TOPtext Basic Operation The Fastext/TOPtext is teletext with a special directory. Channel selection On the lower part of the screen there are four different coloured fields (red, green, yellow and blue). These fields With the Numbered buttons (0-9). lead directly to the pages shown within. The coloured Example: buttons on the remote control correspond to the coloured •... -
Page 12: Stereo Reception In Analogue Cable Tv Channel Mode
Stereo reception in analogue cable Picture Format TV channel mode Picture Size The required picture format can be set by pressing You can see the each signal type you selected on the PICTURE SIZE button. Press PICTURE SIZE the TV-screen when you press . until the required format is displayed. -
Page 13: Other Convenience Functions
Other convenience functions You can change the default settings to convenience use. Selected Items Setup hint Picture Picture Mode Standard Standard picture quality (factory-set) Dynamic Enhanced picture contrast and sharpness (factory-set) Natural Intended for bad-quality signals (factory-set) Favorite Your personal preferences Brightness / Contrast / Sharpness / Color / Tint You can adjust the picture to your preference. - Page 14 Other convenience functions Selected Items Setup hint PC Setup See page 19. Feature Language See page 10. Lock See page 12. Blue Back On: You can set the TV to automatically change to a blue screen and mute the sound if the signal is weak or On / Off absent.
-
Page 15: Media Operation
Media Operation Current Folder/Total Folders - shows the current folder/total folders. You can enjoy viewing pictures, playing music and Current File/Total Files - shows the current movie files from your USB storage device. supported file/total supported files. Connect the USB storage device into the Media Operation Guide Panel - shows the corresponding Input terminal. -
Page 16: Picture Playback (Slideshow)
Pictures Playback (Slideshow) You can view the picture files with the following remote control buttons. To playback picture files Button Action Press / to the select PHOTO at Media Selection and press or ENTER. Press to display Control Bar. Press 2 times to display File Info. Press to select the desired folder in Folder List and press . -
Page 17: Music Or Movie Playback
Music or Movie Playback You can playback the music or movie files with the following remote control buttons. To playback music or movie files Button Action Press / to the select MUSIC or VIDEO at Press to display Control Bar. Media Selection and press or ENTER. -
Page 18: Playable File Types
Playable File Types Movie File Type Extension Name Support Version Video Codec Audio Codec MPEG .mpg Video Coding Audio Coding .mpeg MPEG1 (SD Format Only) MPEG2 (SD Format Only) Video BitRate Audio BitRate up to15 Mbps 128kbps Note: • All movie support resolution up to 720 x 576 (50Hz) and 720 x 480 (60Hz). Photo File Type Extension Name... -
Page 19: Pc Connection
PC connection Follow these steps: On your PC monitor choose a resolution of 1920 × 1080 (LT-32G3 : 1360 x 768) at 60Hz and save this configuration. Shut down your PC and connect the shut off LCD TV. Use a screensaver to avoid burning-in of static picture content. -
Page 20: Connecting An Hdmi Or A Dvi Device To The Hdmi Input
Connecting an HDMI or a DVI device to the HDMI input The HDMI input receives digital audio and uncompressed video from a HDMI equipped device or uncompressed digital video from a DVI equipped device. When you connect to a DVI device with a HDMI-to-DVI adapter cable, it only transfers the video signal, so it is necessary to use separate analogue leads to transfer the audio signals. -
Page 21: Connection To Other Equipment
Connection to other equipment Attention: Preparation: • Disconnect all equipment from the AC-supply, to prevent any possible damage. • Make the necessary connections. • Make sure all connections are safe & secure before reconnecting your equipment the AC-supply. Note: • Select a appropriate external input mode. - Page 22 Connection to other equipment 4. Connecting to a DVD player or other AV device with Component Video outputs If your DVD player (or other device) has Component Video output jacks, use a suitable set of leads (RCA/ Phono) to connect these to the Component Video inputs on this TV as shown - it can greatly enhance the picture quality and performance.
-
Page 23: Troubleshooting Table
Troubleshooting table Please check the following list before requesting service. Symptom Possible solution Page No picture, no sound Switch on the set. Check that the mains power outlet is properly connected. Select appropriate input mode. Unplug unit for 1 minute, then plug it back in. No reception with built-in Connect the antenna. -
Page 24: Specifications
60 cm visible 80 cm visible 107 cm visible 117 cm visible TFT Active Matrix Colour LCD, 1920 x 1080 (LT-32G3 : 1366 x 768) Pixel HDMI input: HDMI compliant (type A connector), HDCP compliant Supported scan rates: PAL: 576i/576p/720p/1080i/1080p NTSC: 480i/480p/720p/1080i/1080p HDMI Audio: 2-channel PCM, 32/44.1/48 kHz sampling frequency...
