LCD Television Users Guide
LT-32E479
LT-32EM49
Important Note:
In the spaces below, enter the model and serial number of your television (located at the
rear of the television cabinet). Staple your sales receipt or invoice to the inside cover of this
guide. Keep this user's guide in a convenient place for future reference. Keep the carton
and original packaging for future use.
Serial Number:
Model Number:
32" class (31.5" Diagonal)
32" class (31.5" Diagonal)
LCT2389-001B-A
0608TSH-II-IM

Advertisement

   Related Manuals for JVC 0608TSH-II-IM

   Summary of Contents for JVC 0608TSH-II-IM

  • Page 1

    Staple your sales receipt or invoice to the inside cover of this guide. Keep this user’s guide in a convenient place for future reference. Keep the carton and original packaging for future use. Serial Number: Model Number: 32" class (31.5" Diagonal) 32" class (31.5" Diagonal) LCT2389-001B-A 0608TSH-II-IM...

  • Page 2: Table Of Contents

    Table of Contents Warnings ....3 Precautions ....6 Remote Control .

  • Page 3: Warnings

    5. In the event of trouble, unplug the unit and call a service technician. Do not attempt to repair it yourself or remove the rear cover. Changes or modifications not approved by JVC could void the warranty. * When you don’t use this TV set for a long period of time, be sure to disconnect both the power plug from the AC outlet and antenna for your safety.

  • Page 4

    Warnings IMPORTANT RECYCLING INFORMATION This product has a fluorescent lamp that contains mercury. Disposal of these materials may be regulated in your community due to environmental considerations. For disposal or recycling information, please contact your local authorities or for USA, the Electronic Industries IMPORTANT SAFETY INSTRUCTIONS Read these instructions.

  • Page 5

    It's possible your clothing, (such as a belt buckle or button) may scratch the front of the TV. Do the same when moving the TV to another location. 21) When attaching to a wall, use the optional JVC wall mounting unit. For LT-32E479 / LT-32EM49: JVC-XUF-2637 LCD FLAT WALL MOUNT Caution —...

  • Page 6: Precautions

    We have an important note for customers who subscribe to basic cable services (do not have a separate cable box) and plan to use their JVC TV remote control to select channels. Once you run the Auto Tuner Setup (which detects and programs all the channels your TV is receiving through the RF input), every channel number available from your cable company will appear in your television’s Channel Summary and they will all be marked as available for...

  • Page 7

    Caring for the Cabinet Normally, light dusting with a soft, non-scratching duster will keep your TV clean. If you wish to wipe down the television, first unplug it. Then wipe gently with a soft cloth, slightly moistened with water. You can add a few drops of mild liquid detergent to the water to help remove spots of oily dirt.

  • Page 8

    Precautions Disconnecting the stand 1) Place the TV face down on a soft cloth on a table. 2) Remove the five screws from the back of the TV. 3) Pull out the stand from the TV. Notes: • To re-install the stand, reverse the procedure from 3) to 1). •...

  • Page 9

    Package Contents Make sure you have the following. Television x 1 TV Stand Insert the batteries Use two “AAA” batteries (included). Place the "–" end in the unit first, making sure the "+" and "–" markings are correct. Place the "–" end in the unit first.

  • Page 10: Remote Control

    Remote Control The following pages gives you a brief description of each button’s function. For more detailed information on the remote control buttons, see pages 19 - 21. Change the aspect ratio of the image on your Turns the TV on or off. For V4 (Video-4) and V5 (Video-5) you must select the signal input type fi...

  • Page 11

    Remote Control Used to navigate through the TV’s onscreen menus. View current channel information. Used to select the mode of closed caption Used to access the TV’s onscreen menus. See page 22. Go back to a previous onscreen menu or to correct a mistake.

  • Page 12: Tv Basic Controls

    TV Basic Controls Before you connect your television to another device, please refer to the proper diagrams for your specific TV and remote. These will help assist you in understanding how to connect your television to another device, as well as use the remote to set up your television. Some of the connection terminals are color coded for easy connection with the proper cables.

  • Page 13: Dvd Player

    AUDIO OUT INPUT 1 HDMI ANALOG AUDIO AUDIO VIDEO COMPONENT INPUT 5 AUDIO S-VIDEO VIDEO COMPONENT INPUT 4 DIGITAL AUDIO OPTICAL OUT LC34324-001A INPUT 1 INPUT 2 INPUT 3 75 Ω (VHF/UHF) * For more detailed information, see pages 42 - 46. AUDIO OUT INPUT 1 HDMI ANALOG...

  • Page 14

    TV Basic Controls Device Side HDMI DVI + Audio Component Video + Audio S-Video + Audio Composite Video + Audio Antenna / Cable (VHF / UHF) OPTICAL INPUT AUDIO INPUT (L / R) With Cables HDMI Cable DVI – HDMI Cable, Audio Cable HDMI ANALOG AUDIO Component...

  • Page 15

    Compatible Signal Input • HDMI (Digital) SD: 480i, 480p HD: 1080i, 1080p/60Hz, 720p Audio L/R Input • DVI (Digital) SD: 480i, 480p HD: 1080i, 1080p/60Hz, 720p • Audio L/R (Analog) Input • Component (Analog) SD: 480i, 480p HD: 1080i, 720p •...

  • Page 16: Setup

    Setup Initial setup When you turn on your TV for the first time, the Initial Setup menu appears automatically. These menus will help you setup your TV with basic information for Language, Time and Tuner Setup. You can also set this setting in the “Plug in Menu”. 1) Turn on the TV 2) Set the language Set Language/Langue/Idioma...

  • Page 17

    Initial setup (Continued) “Thank you! Setup is now complete” Note: • If you want to turn off the Auto Demo, press the MENU button. 4) Set TV attribute Set TV Attribute Tuner Mode Start Scan Exit Tuner Mode Choose Air (antenna) or Cable * If you use a set top box (satellite or cable box), press “Exit”...

  • Page 18: Key Features

    Key Features Your JVC TV is equipped with many features. Here are some key features highlighted in detail. Dynamic Gamma and Color Management give further fi ne tuned picture reproduction. Smart Picture adjusts the best possible picture quality automatically scene by scene based...

  • Page 19: Remote Control Functions

    Remote Control Functions Sleep Allows you to choose how long the TV will stay on before turning off. Notes: • When you press the SLEEP button several times, you can set the interval at Off, 15, 30, 45, 60, 90, 120, 150 and 180 minutes. •...

  • Page 20: Aspect

    Remote Control Functions Aspect Allows you to adjust the way the image appears on your TV based on the format that is being received. Panorama / Cinema / Full / Panorama Zoom / Cinema Zoom / Regular / Slim See page 28. Notes: •...

  • Page 21: Guide

    Guide You can view program information for Digital Channels. Note: • When the program information is not being broadcast, the correct information will not be displayed. • The GUIDE will not show the correct time and date depending on the Time Zone and D.S.T. settings.

  • Page 22: Customizing Your Tv

    Customizing your TV Note: • Depending on the situation (analog channels, digital channels, video signal format, external inputs, etc.), some items will be displayed in gray and can not be selected. 1) Display the menu bar 2) Display the desired menu Picture Display Sound...

  • Page 23: Picture

    Picture Picture Display Video Status Game Tint 0 – – 100 Color 0 – – 100 Picture 0 – – 100 Bright 0 – – 100 Detail 0 – – 100 Backlight 0 – – 100 Color Temp Cool Color Management Dynamic Gamma Smart Picture Digital VNR...

  • Page 24: Color Temp

    Customizing your TV Picture (Continued) ■ Allows you to change and adjust the way the picture appears on your television. Tint Allows you to adjust the levels of red and green on your TV. Color Allows you to make all the colors on your TV appear more vivid or subtle. Picture Allows you to adjust the level of black and white on your TV giving you a darker or brighter picture overall.

  • Page 25: Smart Picture

    Picture (Continued) Smart Picture Allows the TV to adjust the brightness level automatically to a level suitable for what you are watching. On / Off Digital VNR AThis function can be selected to change the effect of Digital VNR (Video Noise Reduction). High –...

  • Page 26: Display

    Customizing your TV Display Picture Display Video Input Label AIR TV Photo Viewer Aspect Ratio Cinema Zoom BACK :Select :Operate :Back Video Input Label Allows you to label all the devices you have connected to the TV that use the VIDEO-1, 2, 3, 4 and 5 inputs.

  • Page 27

    • All your stored data should be backed up fi rst as a precaution before connecting to the TV. • Depending on your stored fi le size, it can take extra time to display “Photo Viewer” page. • You can not display photos using the SD card from the JVC Everio Camera. Customizing your TV button, and a folder list will be displayed.

  • Page 28: Aspect

    Customizing your TV Display (continued) Aspect Allows you to adjust the way the image appears on your TV based on the format that is being received. Panorama - When watching a 4:3 aspect picture it is stretched to fit the dimensions of the 16:9 aspect screen.

  • Page 29: Closed Caption

    Picture Display Closed Caption CC Setting Tuner Mode Autoscan Add Channel Edit Channel V-Chip Guide BACK :Select :Operate :Back Closed Caption Allows you to select the mode of the closed caption. First you must set the MODE to either TV, STB or VCR on your remote.

  • Page 30: Tuner Mode

    Customizing your TV TV (continued) Analog CC Choose the CC feature that you like for analog Closed Captioning. Digital CC Choose the CC feature that you like for digital Closed Captioning. Font Choose the font that you like for Closed Captioning. Font Size Choose how big the text appears in Closed Captioning.

  • Page 31: Add Channel

    TV (continued) Add Channel Allows you to add analog channels. Regarding digital channels, the only channels that will appear are the ones that are being broadcast. Please insert scan number or range Start Edit Channel Allows you to skip channels when using the + CH – button. “✔” means don’t skip, “ “ means to skip.

  • Page 32: Tv (v-chip)

    Customizing your TV TV (V-Chip) Allows you to block channels or content that you deem inappropriate for children. Picture Display Closed Caption CC Setting Tuner Mode Autoscan Add Channel Edit Channel V-Chip Guide BACK :Select :Operate :Back Notes: • V-CHIP will not work with video signals from VCRs, DVD players, Blu-ray or camcorders connected to the TV.

  • Page 33: Password

    TV (V-Chip) (continued) Password Picture Display Sound Power Closed Caption CC Setting Tuner Mode Autoscan Password New Password Add Channel MPAA Confirm Password Edit Channel Can. Eng. Clear V-Chip Can Fre. Please set password first to act Guide TVPG :Operate BACK :Back MENU...

  • Page 34: Can. Eng

    Customizing your TV TV (V-Chip) (continued) MPAA (continued) NR – Not Rated. Any type of programming that does not contain a rating. G – General Audience. Suitable for all ages. PG – Parental Guidance Suggested. Suitable for all ages with parental guidance. PG 13 –...

  • Page 35: Can. Fre

    TV (V-Chip) (continued) E – Exempt. Any type of programming that does not contain a rating. C – Intended for children. Suitable for all ages. C8+ – Intended for children over 8 years old. Suitable for all ages over 8 years. G –...

  • Page 36: Tvpg

    Customizing your TV TV (V-Chip) (continued) TVPG Picture Display Sound Power Closed Caption CC Setting Tuner Mode Autoscan Password ALL FV V TV-Y Add Channel MPAA TV-Y7 Edit Channel Can. Eng. TV-G TV-PG V-Chip Can Fre. TV-14 Guide TVPG TV-MA BACK MENU :Select...

  • Page 37: Sound

    Sound Picture Display BACK :Select :Operate :Back Allows you to listen to a program in stereo, mono sound or another language (SAP). (Depending if available in the program). First you must set the MODE to TV on your remote. Notes: •...

  • Page 38: Sound Status

    Customizing your TV Sound (continued) Sound Status You can choose several types of sound modes. Speech / Jazz / Classic / Rock / User Note: • If you select User, you can customize the various sound frequencies. Audio Reset Resets all sound adjustments at once to the default settings.

  • Page 39: Power

    Power Picture Display BACK :Select :Operate :Back Sleep Timer Allows you to choose how long the TV will stay on before turning off. First set the MODE to TV. Off / 15Min / 30Min / 45Min / 60Min / 90Min / 120Min / 150Min / 180Min Note: •...

  • Page 40: Setting

    Customizing your TV Setting Picture Display BACK :Operate :Back :Select Plug-In Menu When you turn on your TV for the first time, the Initial Setup menu appears. If you skip it, or your setup has changed, you can set it up in this menu anytime. Time Zone Choose the time zone you live in and the clock sets automatically.

  • Page 41: Front Panel Lock

    Setting (continued) Front Panel Lock This allows you to lock the buttons on the side of the TV. On / Off Transparency Change the transparency of the menu screens. 1 / 2 / 3 / 4 Auto Shut Off This function automatically shuts off your TV when there is no signal from the channel while the TV is on for 10 minutes.

  • Page 42: Connecting Your Devices

    Connecting Your Devices Notes: • The following connection diagrams are examples on connecting some of the most common devices to your TV. Please refer to your device’s instruction manual on other connection methods or for devices not shown here in this instruction book. •...

  • Page 43

    Connect a DVD Player AUDIO OUT INPUT 1 HDMI ANALOG AUDIO AUDIO VIDEO INPUT 5 COMPONENT AUDIO VIDEO S-VIDEO INPUT 4 COMPONENT DIGITAL AUDIO OPTICAL OUT LC34324-001A Notes: • Green, blue and red are the most common colors for Component Cables. Some models may vary in color.

  • Page 44

    Connecting Your Devices Connect an Amplifier or Home Theater System Home Theater System Speaker Notes: • Refer to your amplifier’s or Home Theater System’s manual for more information. • If you have a device connected to INPUT 1, INPUT 2 or INPUT 3, you will not be able to hear any audio from the AUDIO OUT on the back of the TV otherwise.

  • Page 45

    Connect a Digital Source Device TV Rear Panel INPUT 1 HDMI ANALOG AUDIO AUDIO OUT After the connections have been made, tighten the screw to secure the cables. Notes: • To watch your digital source device, make sure your TV is displaying INPUT 1 by pressing the V1 button on your remote control.

  • Page 46

    • This TV can accept 480i, 480p, 720p, 1080i and 1080p signals via HDMI. • This JVC television can accept a variety of HD signals, including 720/60p, 1080/60i and 1080/60p. It does not accept a 1080/24p signal. Please note that in some cases, a Blu-ray may only offer the choice of 1080/60i or 1080/24p.

  • Page 47: Troubleshooting

    Refer to the table below to check the condition. If you think that there is a problem, contact the JVC Service Center where you purchased the television. PROBLEMS There is no power • See if the power cord became unplugged.

  • Page 48

    My HDMI device • This JVC television can accept a variety of HD signals, including 720/60p, 1080/60i and doesn’t work or 1080/60p. It does not accept a 1080/24p signal. Please note that in some cases, a Blu-ray doesn’t work properly...

  • Page 49: Specifi Cations

    W X H X D Weight (lbs / kg) Specifications subject to change without notice. • The open source software is embedded in this product. For more information, please go to: http://software.jvc.com/opensource/lnx/DP/08_AtscQam_T/download.html LT-32E479 LT-32EM49 LCD Flat Television NTSC, BTSC System (Multi-Channel Sound) ATSC Terrestrial, Digital Cable...

  • Page 52: Digital Television Transition Notice
