SECURITY DOOR CONTROLS
801 Avenida Acaso, Camarillo, Ca. 93012 • (805) 494-0622 • Fax: (805) 494-8861
www.sdcsecurity.com • E-mail: service@sdcsecurity.com
101-1AK
GRN - SECURE
YEL - ALARM
RED - UNLOCKED
OFF - BYPASS
101-1A
EXIT ALARM
GRN - SECURE
YEL - ALARM
RED - UNLOCKED
OFF - BYPASS
P:\INSTALLATION INST\Delayed Egress\INST-D.E. ANNUNCIATORS\INST-D.E. Annunciators.vsd
REMOTE CONTROLS AND ANNUNCIATORS WIRING
RESET
BYPASS
101 SERIES
CONTROL PANEL
ACCESS
BYPASS
OR
OPTION
REV C
101-4AM
GRN - SECURE
YEL - ALARM
AUDIBLE
RED - UNLOCKED
SHUNT
OFF - BYPASS
To
Power
Supply
+ -
B L K L E D C O M ( - )
G R N L E D ( + )
R E D L E D ( + )
Y E L
RESET
W H T
OPTION
Y E L
W H T
0210
Page 1
101-PAM
ON
OFF
GRN - SECURE
ACCESS
YEL - ALARM
RED - UNLOCKED
OFF - BYPASS
AUDIBLE
SHUNT
1511S DELAYED EGRESS LOCK
[RM TRIG]
[RESET]
[PWR]
[FP]
[LOCK]
[GRN RLY]
[RED RLY]
- +
C NC
-
+
NO C
NC NO
C NC
NO C
NOT
USED
[REX]
[ DPS ]
[
BAS
]
NO C NC NO C NC
NO C
NO C NO C
Advertisement
Table of Contents
Related Manuals for SDC 707RU
Summary of Contents for SDC 707RU
- Page 1 SECURITY DOOR CONTROLS 801 Avenida Acaso, Camarillo, Ca. 93012 • (805) 494-0622 • Fax: (805) 494-8861 www.sdcsecurity.com • E-mail: service@sdcsecurity.com REMOTE CONTROLS AND ANNUNCIATORS WIRING 101-1AK 101-4AM 101-PAM RESET BYPASS GRN - SECURE GRN - SECURE GRN - SECURE ACCESS YEL - ALARM YEL - ALARM YEL - ALARM...
-
Page 2: Code Compliance
Digital Countdown Display Application: ® Exit Check When unauthorized egress is initiated SDC delays egress through the door for 15 seconds (or 30 seconds). Meanwhile, the person exiting must wait while personnel or security responds. The door unlocks after 15 seconds have elapsed permitting egress. When powered by a fire control supervised power supply, the lock will release immediately in an emergency. - Page 3 101-DE/101-KDE Operational Description The door is closed and secured by latching hardware. The model 101-DE/101-KDE Exit Check controller sends power to the magnetic lock or Delayed Egress Panic Device to lock the door in the secured position. The integral digital display shows the unlock delay time.
- Page 4 Typical System Wiring – Single Door w/ Latching Hardware WARNING: APPLICATION OF VOLTAGE TO THE DRY CONTACT INPUTS OF THIS UNIT WILL CAUSE PERMANENT DAMAGE AND VOID THE WARRANTY 3 conductors AC Mains 2 conductors Power To Fire Panel – Dry, Closed Contact Supply To Smoke Detection 2 conductors...
- Page 5 KEY CYLINDER INSTALLATION (KDE Model Only) WITH KEY CYLINDER IN PROPER POSITION INSIDE SWITCH BLOCK, 1-1/4” KEY CYLINDER TIGHTEN THE SET SCREW TO REQUIRES COLLAR LOCK CYLINDER IN PLACE. 1-1/8” KEY CYLINDER 7185SC1-26D-KD RECESSED MOUNTING DRY WALL 1) Cut hole in dry wall to dimensions shown.
- Page 6 SURFACE MOUNT 3 GANG BOX 1) Attach optional 3 Gang Surface Mount Box to wall using TO WALL screws supplied. 1a) Knockouts are located on two surfaces of the box to allow wire conduit insertion. 2) Carefully insert unit and secure with screws supplied.
- Page 7 RECOMMENDED MOUNTING PROCEDURE USE 1-1/4” SCREWS SUPPLIED WITH WALL MOUNT FRAME TO HANG UNIT TEMPORARILY FOR WIRING PURPOSES SLIDE PACKING FOAM BETWEEN WALL AND UNIT TO PREVENT DAMAGE TO FACEPLATE WIRE UNIT AS SHOWN (SHOWN WITH NO OPTIONS). VIEW A-A P:\INSTALLATION INST\Delayed Egress\INST-101DE_KDE.vsd Rev E 07-15...
-
Page 8: Dip Switch Settings
MODEL 101-DE MODEL 101-KDE Trigger Switch 101-DE / 101-KDE SDC MODELS PWR LOCK RED RLY GRN RLY TRIG REX RESET 1511DE 1575DE 1571DE 1576DE NO C NC NO C NC C NO C NO C NO C NO 1581DE Note for 1581DE only:... -
Page 9: System Operation
System Operation POWER-UP UNLOCKED POWER-UP LOCKED The door is unlocked. To enter the The door is Armed Mode, turn the keyswitch to locked and Reset or enter the Reset Code secure “11 ” on the keypad DELAYED EGRESS MODE The door is still locked and secure. The display is counting down with audible alarm/voice instructions. - Page 10 Changing the Master Code User 1 is always used as the Master Code and is required to access keypad programming. The Factory Default Master Code is “1234 ”. It is strongly recommended that a new Master Code is assigned after installation.
-
Page 11: Specifications
Door Without Latch Assembly Activation By Sure Exit Push Bar MODELS TO FIRE COMMAND Power Supply CENTER 101-DE 115 VAC 101-KDE 1575DEU 1581DEV 1576DEU 1571DEV 1511DEV PUSH UNTIL ALARM SOUNDS. DOOR CAN BE PUSH UNTIL ALARM SOUNDS. DOOR CAN BE OPENED IN 15 SECONDS. - Page 12 Connecting to a Infant/Patient Monitoring System 1. Locate jumper [J6] (above the IBO input). Verify that it is NOT installed across both pins. 2. Close AND hold the REX input. The 101-DE will be in Bypass Mode and will be unlocked. 3.
- Page 13 Connecting Optional Accessories Door Without Latch Assembly Activation By Sure Exit Push Bar Power TO FIRE COMMAND Supply CENTER 115 VAC PUSH UNTIL ALARM SOUNDS. DOOR CAN BE PUSH UNTIL ALARM SOUNDS. DOOR CAN BE OPENED IN 15 SECONDS. OPENED IN 15 SECONDS. Power Transfer MSB550/PSB560 Hinge or Loop...
- Page 14 SECURITY DOOR CONTROLS 801 Avenida Acaso, Camarillo, Ca. 93012 • (805) 494-0622 • Fax: (805) 494-8861 www.sdcsecurity.com • E-mail: service@sdcsecurity.com REMOTE CONTROLS AND ANNUNCIATORS WIRING 101-1AK 101-4AM 101-PAM RESET BYPASS GRN - SECURE GRN - SECURE GRN - SECURE ACCESS YEL - ALARM YEL - ALARM YEL - ALARM...
