Frigidaire PLHS268ZC Factory Parts Catalog

Frigidaire PLHS268ZC Factory Parts Catalog

Side by side refrigerator
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
PRODUCT NO.
BASE MODEL NO.
PLHS268ZCB0
PLHS268ZC
MARKET
North America
WIRING DIAGRAM - 240389608
OWNER'S GUIDE - 240389309
SERVICE DATA SHEET - 240389608
ELECTROLUX HOME PRODUCTS, INC
P.O. BOX 212378, Augusta, GA 30917
SERIES
COLOR
R134a Professio
stainless/black
Publication No.
5995380614
021031
-EN/SERVICE/KHB
357
PARTS CATALO
VOLTS
115
SIDE BY SIDE
REFRIGERATOR
Model No.
PLHS268ZC
©2002 Electrolux Home Products, Inc.
All rights reserved
FACTORY
G

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PLHS268ZC and is the answer not in the manual?

Questions and answers

Related Manuals for Frigidaire PLHS268ZC

Summary of Contents for Frigidaire PLHS268ZC

  • Page 1 PRODUCT NO. BASE MODEL NO. PLHS268ZCB0 PLHS268ZC MARKET North America WIRING DIAGRAM - 240389608 OWNER’S GUIDE - 240389309 SERVICE DATA SHEET - 240389608 ELECTROLUX HOME PRODUCTS, INC P.O. BOX 212378, Augusta, GA 30917 SERIES COLOR R134a Professio stainless/black SIDE BY SIDE REFRIGERATOR Publication No.

  • Page 2: Freezer Door

    Publication No. PLHS268ZCB0 5995380614 FREEZER DOOR 10/02...
  • Page 3 POS. NO # = Fast-moving Parts * = Non-Illustrated Parts PLHS268ZCB0 FREEZER DOOR PART NO DESCRIPTION 240390606 Gasket-frzr door,black ,magnetic 240334206 Bin-door,frzr-upper 240351606 Bin-door 240351706 Bin-door,frzr-dispenser 240451873 Door-frzr,stainless steel, complete assy 240537106 Door Stop, black, frzr 240536801 Handle-door, stainless steel, with insert 5308016566 Screw, hex wshr hd ,8-15A x 0.625, low profile 240561602...

  • Page 4: Refrigerator Door

    Publication No. PLHS268ZCB0 5995380614 REFRIGERATOR DOOR 10/02...
  • Page 5 POS. NO # = Fast-moving Parts * = Non-Illustrated Parts PLHS268ZCB0 REFRIGERATOR DOOR PART NO DESCRIPTION 240390605 Gasket-refr door,black ,magnetic 240323006 Bin-door,2 ltr 240326209 Door-dairy,aeg aqua 240558801 Nameplate,aluminum 240537105 Door Stop,black ,ref 240451941 Door-refr, stainless steel, complete assy 240536801 Handle-door, stainless steel, with insert 5308016566 Screw, hex wshr hd, 8-15A x 0.625, low profile...
  • Page 6 Publication No. PLHS268ZCB0 5995380614 CABINET 10/02...
  • Page 7 POS. NO 14A# 100* # = Fast-moving Parts * = Non-Illustrated Parts PLHS268ZCB0 CABINET PART NO DESCRIPTION 240435902 Cover-air duct 240475902 Cover-evap coil,lower 5303208309 Plug-hole,factory test 240505801 Switch,light/lamp 215486600 Switch-light/lamp 218252200 Screw,#8 truss hd ,10-32CA x 0.500 240457701 Plate-door closer 240402701 Screw-#10-32 x 1/4 flat hd 240335501...
  • Page 8 Publication No. PLHS268ZCB0 5995380614 SHELVES 10/02...
  • Page 9 POS. NO 42A* 42A* 101* # = Fast-moving Parts * = Non-Illustrated Parts PLHS268ZCB0 SHELVES PART NO DESCRIPTION 240434604 Trim-basket 240350668 Shelf-freezer, glass, lower 240350667 Shelf-freezer, glass, upper 240324101 Shelf-pizza 240436702 Light Bulb/Lamp, A-15, clear, 40 W, 120 V, miniature 218906801 Socket-light/lamp 240323102...
  • Page 10 Publication No. PLHS268ZCB0 5995380614 CONTROLS 10/02...
  • Page 11 POS. NO 13 # 137* 139* 199* # = Fast-moving Parts * = Non-Illustrated Parts PLHS268ZCB0 CONTROLS PART NO DESCRIPTION 5308000010 Fan Blade,red ,evaporator fan 5300157666 Bushing-motor mtg,(2) 5303292396 Bracket-motor mtg,front 240315802 Motor-evap fan 215474201 Washer,"slinger" ,nylon ,evap fan shaft 5303292397 Bracket-motor mtg,rear 240436702...
  • Page 12 Publication No. PLHS268ZCB0 5995380614 SYSTEM 10/02...
  • Page 13 POS. NO 14 # 15 # 29 # 30 # 55 # 60 # 61 # # = Fast-moving Parts * = Non-Illustrated Parts PLHS268ZCB0 SYSTEM PART NO DESCRIPTION 240333603 Condenser 218679607 Block-evap coil,styrofoam ,(2) 218944001 Drier-filter,R134a System 240346402 Harness-wiring,machine compt 240449601 Harness-wiring 240439901...
  • Page 14 Publication No. PLHS268ZCB0 5995380614 DISPENSER 10/02...
  • Page 15 POS. NO 38A# # = Fast-moving Parts * = Non-Illustrated Parts PLHS268ZCB0 DISPENSER PART NO DESCRIPTION 218976409 Tube-water 218976901 Tube-water inlet, inlet valve to ice maker 218976903 Tube-water inlet, inlet valve to filter 218976907 Tube-water inlet, valve to door 5304422013 Module-dispenser 5304421626 Spring-torsion...

  • Page 16: Ice Container

    Publication No. PLHS268ZCB0 5995380614 ICE CONTAINER 10/02...
  • Page 17 POS. NO 18 # 45 # # = Fast-moving Parts * = Non-Illustrated Parts PLHS268ZCB0 ICE CONTAINER PART NO DESCRIPTION 5304428402 Auger-ice 5304404343 Cam-drive 218815300 Container-ice,bucket only 5304404346 Drum-ice disp 5304422805 Front-ice container 5304404337 Bar-drive 5304404359 Gate 5303001179 Light Bulb/Lamp,40 W 5303289050 Socket-light/lamp 5304404345...

  • Page 18: Ice Maker

    Publication No. PLHS268ZCB0 5995380614 ICE MAKER 10/02...
  • Page 19 POS. NO 11 # 12 # 13 # 15 # 17 # 55 # # = Fast-moving Parts * = Non-Illustrated Parts PLHS268ZCB0 ICE MAKER PART NO DESCRIPTION 218976409 Tube-water 218976901 Tube-water inlet, inlet valve to ice maker 218976903 Tube-water inlet, inlet valve ,to filter 218976907 Tube-water inlet, valve to door 5304420650...

  • Page 20: Wiring Schematic

    Publication No. PLHS268ZCB0 5995380614 WIRING SCHEMATIC 10/02...

  • Page 21: Wiring Diagram

    PLHS268ZCB0 Publication No. 5995380614 WIRING DIAGRAM # = Fast-moving Parts 10/02 * = Non-Illustrated Parts...
