Frigidaire PLHS237ZC Factory Parts Catalog

Frigidaire PLHS237ZC Factory Parts Catalog

Side-by-side refrigerator
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
PRODUCT NO.
BASE MODEL NO.
PLHS237ZCB0
PLRS237ZC
MARKET
North America
WIRING DIAGRAM -
240389610
OWNER'S GUIDE - 240389311
SERVICE DATA SHEET - 240389610
ELECTROLUX HOME PRODUCTS, INC
P.O. BOX 212378, Augusta, GA 30917
SERIES
COLOR
R134a Gallery
white
Publication No.
5995391223
030528
-EN/SERVICE /DCS
357
PARTS CATALO
VOLTS
115
SIDE BY SIDE
REFRIGERATOR
Model No.
PLHS237ZC
©2003 Electrolux Home Products, Inc.
All rights reserved
FACTORY
G

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PLHS237ZC and is the answer not in the manual?

Questions and answers

Related Manuals for Frigidaire PLHS237ZC

Summary of Contents for Frigidaire PLHS237ZC

  • Page 1 ELECTROLUX HOME PRODUCTS, INC P.O. BOX 212378, Augusta, GA 30917 SERIES COLOR R134a Gallery white SIDE BY SIDE REFRIGERATOR Publication No. 5995391223 030528 -EN/SERVICE /DCS ©2003 Electrolux Home Products, Inc. All rights reserved FACTORY PARTS CATALO VOLTS Model No. PLHS237ZC...

  • Page 2: Freezer Door

    Publication No. PLHS237ZCB0 5995391223 FREEZER DOOR 05/03...
  • Page 3 POS. NO # = Fast-moving Parts * = Non-Illustrated Parts PLHS237ZCB0 FREEZER DOOR PART NO DESCRIPTION 240390608 Gasket-frzr door,black ,magnetic 240367301 Bin-door,frzr-upper 240359001 Bin-door 240358401 Bin-door,frzr-dispenser 240554226 Door-frzr,stainless steel ,complete assy 240581906 Door Stop,black ,frzr 240536801 Handle-door,stainless steel ,with insert 5308016566 Screw,hex washer head ,8-15A x 0.625 ,low profile 240328202...

  • Page 4: Refrigerator Door

    Publication No. PLHS237ZCB0 5995391223 REFRIGERATOR DOOR 05/03...
  • Page 5 POS. NO # = Fast-moving Parts * = Non-Illustrated Parts PLHS237ZCB0 REFRIGERATOR DOOR PART NO DESCRIPTION 240390607 Gasket-refr door,black ,magnetic 240363702 Bin-door,2-liter 240338303 Door,dairy ,clear 240558801 Nameplate,aluminum 240581905 Door Stop,black ,ref 240451979 Door-refr,stainless steel ,complete assy 240536801 Handle-door,stainless steel ,with insert 5308016566 Screw,hex washer head ,8-15A x 0.625 ,low profile...
  • Page 6 Publication No. PLHS237ZCB0 5995391223 CABINET 05/03...
  • Page 7 POS. NO 14 # 14A# 66B* 100* # = Fast-moving Parts * = Non-Illustrated Parts PLHS237ZCB0 CABINET PART NO DESCRIPTION 240435901 Cover-air duct 240475901 Cover-evap coil,lower 5303208309 Plug-hole,factory test 240505801 Switch,light/lamp 215486600 Switch-light/lamp 218252200 Screw,#8 truss hd ,10-32CA x 0.500 240457701 Plate-door closer 240402701...
  • Page 8 Publication No. PLHS237ZCB0 5995391223 SHELVES 05/03...
  • Page 9 POS. NO 16A* 42A* 42A* # = Fast-moving Parts * = Non-Illustrated Parts PLHS237ZCB0 SHELVES PART NO DESCRIPTION 240434603 Trim-basket 240350648 Shelf-freezer,glass ,lower 240350647 Shelf-freezer,glass ,upper 240436702 Light Bulb/Lamp,A-15 ,clear ,40 W ,120 V,miniature 218906801 Socket-light/lamp 240323102 Harness-wiring 240355201 Shelf-"Spill-Safe",fixed ,(1) 240350103 Shelf-"Spill-Safe",sliding ,(2) 240354502...
  • Page 10 Publication No. PLHS237ZCB0 5995391223 CONTROLS 05/03...
  • Page 11 POS. NO 13 # 21 # 139* 199* # = Fast-moving Parts * = Non-Illustrated Parts PLHS237ZCB0 CONTROLS PART NO DESCRIPTION 5308000010 Fan Blade,red ,evaporator fan 5300157666 Bushing-motor mtg,(2) 5303292396 Bracket-motor mtg,front 240315802 Motor-evap fan 215474201 Washer,"slinger" ,nylon ,evap fan shaft 5303292397 Bracket-motor mtg,rear 240436702...
  • Page 12 Publication No. PLHS237ZCB0 5995391223 SYSTEM 05/03...
  • Page 13 POS. NO 14 # 15 # 29 # 30 # 55 # 60 # 61 # # = Fast-moving Parts * = Non-Illustrated Parts PLHS237ZCB0 SYSTEM PART NO DESCRIPTION 240333602 Condenser 218679606 Block-evap coil,styrofoam ,(2) 218944001 Drier-filter,R134a System 240346402 Harness-wiring,machine compt 240439901 Wiring Harness,controls 240449601...
  • Page 14 Publication No. PLHS237ZCB0 5995391223 DISPENSER 05/03...
  • Page 15 POS. NO 38A# 38C* # = Fast-moving Parts * = Non-Illustrated Parts PLHS237ZCB0 DISPENSER PART NO DESCRIPTION 218976409 Tube-water 218976901 Tube-water inlet,inlet valve ,to ice maker 218976903 Tube-water inlet,inlet valve ,to filter 218976907 Tube-water inlet,valve to door 5304422012 Cover-module,black 5304422013 Module-dispenser 5304426649 Spring-torsion...

  • Page 16: Ice Container

    Publication No. PLHS237ZCB0 5995391223 ICE CONTAINER 05/03...
  • Page 17 POS. NO 18 # 45 # # = Fast-moving Parts * = Non-Illustrated Parts PLHS237ZCB0 ICE CONTAINER PART NO DESCRIPTION 5304428402 Auger-ice 5304404343 Cam-drive 218815300 Container-ice,bucket only 5304404346 Drum-ice disp 5304422805 Front-ice container 5304404337 Bar-drive 5304404359 Gate 5303001179 Light Bulb/Lamp,40 W 5303289050 Socket-light/lamp 5304404345...

  • Page 18: Ice Maker

    Publication No. PLHS237ZCB0 5995391223 ICE MAKER 05/03...
  • Page 19 POS. NO 11 # 12 # 13 # 15 # 17 # 55 # # = Fast-moving Parts * = Non-Illustrated Parts PLHS237ZCB0 ICE MAKER PART NO DESCRIPTION 218976409 Tube-water 218976901 Tube-water inlet,inlet valve ,to ice maker 218976903 Tube-water inlet,inlet valve ,to filter 218976907 Tube-water inlet,valve to door 240561701...

  • Page 20: Wiring Schematic

    Publication No. PLHS237ZCB0 5995391223 WIRING SCHEMATIC 05/03...

  • Page 21: Wiring Diagram

    PLHS237ZCB0 Publication No. 5995391223 WIRING DIAGRAM # = Fast-moving Parts 05/03 * = Non-Illustrated Parts...
