PRODUCT NO.
BASE MODEL NO.
PLHS238ZCB0
PLHS238ZC
MARKET
North America
WIRING DIAGRAM - 240389608
OWNER'S GUIDE - 240389309
SERVICE DATA SHEET - 240389608
ELECTROLUX HOME PRODUCTS, INC
P.O. BOX 212378, Augusta, GA 30917
SERIES
COLOR
R134a Gallery
black
Publication No.
5995380648
021101
-EN/SERVICE/KHB
357
PARTS CATALO
VOLTS
115
SIDE BY SIDE
REFRIGERATOR
Model No.
PLHS238ZC
©2002 Electrolux Home Products, Inc.
All rights reserved
FACTORY
G

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PLHS238ZC and is the answer not in the manual?

Questions and answers

Related Manuals for Frigidaire PLHS238ZC

Summary of Contents for Frigidaire PLHS238ZC

  • Page 1 PRODUCT NO. BASE MODEL NO. PLHS238ZCB0 PLHS238ZC MARKET North America WIRING DIAGRAM - 240389608 OWNER’S GUIDE - 240389309 SERVICE DATA SHEET - 240389608 ELECTROLUX HOME PRODUCTS, INC P.O. BOX 212378, Augusta, GA 30917 SERIES COLOR R134a Gallery black SIDE BY SIDE REFRIGERATOR Publication No.

  • Page 2: Freezer Door

    Publication No. PLHS238ZCB0 5995380648 FREEZER DOOR 11/02...
  • Page 3 POS. NO # = Fast-moving Parts * = Non-Illustrated Parts PLHS238ZCB0 FREEZER DOOR PART NO DESCRIPTION 240390608 Gasket-frzr door, black, magnetic 240367306 Bin-door, frzr-upper 240359006 Bin-door 240358405 Bin-door, frzr-dispenser 240451871 Door-frzr, stainless steel, complete assy 240537106 Door Stop, black, frzr 240536801 Handle-door, stainless steel, with insert 5308016566...

  • Page 4: Refrigerator Door

    Publication No. PLHS238ZCB0 5995380648 REFRIGERATOR DOOR 11/02...
  • Page 5 POS. NO # = Fast-moving Parts * = Non-Illustrated Parts PLHS238ZCB0 REFRIGERATOR DOOR PART NO DESCRIPTION 240390607 Gasket-refr door,black ,magnetic 240363706 Bin-door,2-liter 240338311 Door-dairy 240558801 Nameplate,aluminum 240537105 Door Stop, black, ref 240451940 Door-refr, stainless steel, complete assy 240536801 Handle-door, stainless steel, with insert 5308016566 Screw, hex wshr hd, 8-15A x 0.625, low profile...
  • Page 6 Publication No. PLHS238ZCB0 5995380648 CABINET 11/02...
  • Page 7 POS. NO 14 # 14A# 66B* 100* # = Fast-moving Parts * = Non-Illustrated Parts PLHS238ZCB0 CABINET PART NO DESCRIPTION 240435901 Cover-air duct 240475901 Cover-evap coil,lower 5303208309 Plug-hole,factory test 240505801 Switch,light/lamp 215486600 Switch-light/lamp 218252200 Screw,#8 truss hd ,10-32CA x 0.500 240457701 Plate-door closer 240402701...
  • Page 8 Publication No. PLHS238ZCB0 5995380648 SHELVES 11/02...
  • Page 9 POS. NO 42A* 42A* # = Fast-moving Parts * = Non-Illustrated Parts PLHS238ZCB0 SHELVES PART NO DESCRIPTION 240434603 Trim-basket 240350648 Shelf-freezer,glass ,lower 240350647 Shelf-freezer,glass ,upper 240436702 Light Bulb/Lamp, A-15, clear, 40 W, 120 V, miniature 218906801 Socket-light/lamp 240323102 Harness-wiring 240355201 Shelf-"Spill-Safe", fixed, (1) 240350103 Shelf-"Spill-Safe", sliding, (2)
  • Page 10 Publication No. PLHS238ZCB0 5995380648 CONTROLS 11/02...
  • Page 11 POS. NO 13 # 137* 138* 199* # = Fast-moving Parts * = Non-Illustrated Parts PLHS238ZCB0 CONTROLS PART NO DESCRIPTION 5308000010 Fan Blade,red ,evaporator fan 5300157666 Bushing-motor mtg,(2) 5303292396 Bracket-motor mtg,front 240315802 Motor-evap fan 215474201 Washer,"slinger" ,nylon ,evap fan shaft 5303292397 Bracket-motor mtg,rear 240436702...
  • Page 12 Publication No. PLHS238ZCB0 5995380648 SYSTEM 11/02...
  • Page 13 POS. NO 14 # 15 # 21 # 29 # 30 # 55 # 60 # 61 # # = Fast-moving Parts * = Non-Illustrated Parts PLHS238ZCB0 SYSTEM PART NO DESCRIPTION 240333602 Condenser 218679606 Block-evap coil,styrofoam ,(2) 218944001 Drier-filter,R134a System 240346402 Harness-wiring,machine compt 240449601...
  • Page 14 Publication No. PLHS238ZCB0 5995380648 DISPENSER 11/02...
  • Page 15 POS. NO 38A# # = Fast-moving Parts * = Non-Illustrated Parts PLHS238ZCB0 DISPENSER PART NO DESCRIPTION 218976409 Tube-water 218976901 Tube-water inlet, inlet valve to ice maker 218976903 Tube-water inlet,inlet valve ,to filter 218976907 Tube-water inlet,valve to door 5304422012 Cover-module,black 5304422013 Module-dispenser 5304421626 Spring-torsion...

  • Page 16: Ice Container

    Publication No. PLHS238ZCB0 5995380648 ICE CONTAINER 11/02...
  • Page 17 POS. NO 18 # 45 # # = Fast-moving Parts * = Non-Illustrated Parts PLHS238ZCB0 ICE CONTAINER PART NO DESCRIPTION 5304428402 Auger-ice 5304404343 Cam-drive 218815300 Container-ice,bucket only 5304404346 Drum-ice disp 5304422805 Front-ice container 5304404337 Bar-drive 5304404359 Gate 5303001179 Light Bulb/Lamp,40 W 5303289050 Socket-light/lamp 5304404345...

  • Page 18: Ice Maker

    Publication No. PLHS238ZCB0 5995380648 ICE MAKER 11/02...
  • Page 19 POS. NO 11 # 12 # 13 # 15 # 17 # 55 # # = Fast-moving Parts * = Non-Illustrated Parts PLHS238ZCB0 ICE MAKER PART NO DESCRIPTION 218976409 Tube-water 218976901 Tube-water inlet, inlet valve to ice maker 218976903 Tube-water inlet, inlet valve to filter 218976907 Tube-water inlet, valve to door 5304420650...

  • Page 20: Wiring Schematic

    Publication No. PLHS238ZCB0 5995380648 WIRING SCHEMATIC 11/02...

  • Page 21: Wiring Diagram

    PLHS238ZCB0 Publication No. 5995380648 WIRING DIAGRAM # = Fast-moving Parts 11/02 * = Non-Illustrated Parts...
