Frigidaire PLHS237ZA Factory Parts Catalog

Frigidaire PLHS237ZA Factory Parts Catalog

Side-by-side refrigerator
Hide thumbs

Advertisement

Table of Contents

PRODUCT NO.
BASE MODEL NO.
PLHS237ZAB0
PLHS237ZA
PLHS237ZAB1
PLHS237ZA
PLHS237ZAB2
PLHS237ZA
PLHS237ZAB3
PLHS237ZA
MARKET
North America
WIRING DIAGRAM - 0, 1, 2 = 240443001 & 3 = 240527601
OWNER'S GUIDE - 0 = 240389302 & 1, 2, 3 = 240389303
SERVICE DATA SHEET - 0, 1, 2 = 240389604 & 3 = 240389606
ELECTROLUX HOME PRODUCTS, INC
P.O. BOX 212378, Augusta, GA 30917
SERIES
COLOR
R134a Gallery
black
R134a Gallery
black
R134a Gallery
black
R134a Gallery
black
Publication No.
5995364352
020123
-EN/SERVICE/KHB
357
PARTS CATALO
VOLTS
115
115
115
115
SIDE BY SIDE
REFRIGERATOR
Model No.
PLHS237ZA
©2002 Electrolux Home Products, Inc.
All rights reserved
FACTORY
G

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PLHS237ZA and is the answer not in the manual?

Questions and answers

Related Manuals for Frigidaire PLHS237ZA

Summary of Contents for Frigidaire PLHS237ZA

  • Page 1 PRODUCT NO. BASE MODEL NO. PLHS237ZAB0 PLHS237ZA PLHS237ZAB1 PLHS237ZA PLHS237ZAB2 PLHS237ZA PLHS237ZAB3 PLHS237ZA MARKET North America WIRING DIAGRAM - 0, 1, 2 = 240443001 & 3 = 240527601 OWNER’S GUIDE - 0 = 240389302 & 1, 2, 3 = 240389303 SERVICE DATA SHEET - 0, 1, 2 = 240389604 &...

  • Page 2: Freezer Door

    Publication No. PLHS237ZA 5995364352 FREEZER DOOR 01/02...
  • Page 3 A = PLHS237ZA (PLHS237ZAB0) B = PLHS237ZA (PLHS237ZAB1) C = PLHS237ZA (PLHS237ZAB2) D = PLHS237ZA (PLHS237ZAB3) POS. NO # = Fast-moving Parts * = Non-Illustrated Parts PLHS237ZA FREEZER DOOR PART NO DESCRIPTION 240390608 A B C D Gasket-frzr door,black ,magnetic...
