HR92
Radiator Controller
1. Scope of delivery
The radiator controller packaging contains:
1
1 Radiator controller with valve baseplate M30 x 1.5;
batteries included
2 Display support
3 Valve adapter type Danfoss RA
4 Screws for securing radiator controller and battery
compartment
Danger of suffocation!
f Keep packaging materials away from
children.
WARNING
Wireless
2
4
3
re 2. Brief description
The HR92UK radiator controller is certified
by eu.bac.
214431
HR92 is an electronic radiator controller with a modern
design. Because of the wireless communication with
a frequency of 868 MHz the controller can be easily
integrated in heating systems such as evohome to
control the room temperature.
User-friendly
• Large adjustable display with backlight.
• Display of information in the display using symbols
and text.
• Parameters can be set individually.
• Manual temperature modification (effective until the
next switching point) possible at any time.
Mounting
• The radiator controller fits on the most common
radiator valves of the type M30x1.5.
• Further adapters are available as accessories.
• An external window contact can be connected
optionally.
Energy saving features
• With the window function, the radiator valve is closed
when ventilating the room.
• If an external window contact is used, the radiator
valve is closed when a window is open.
f Use the radiator controller only in
accordance with these operating
instructions.
CAUTION f Do not let children play with the radiator
controller.
UK
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HR92 and is the answer not in the manual?

Questions and answers

Related Manuals for Honeywell Home HR92

Summary of Contents for Honeywell Home HR92

  • Page 1 The HR92UK radiator controller is certified by eu.bac. 214431 HR92 is an electronic radiator controller with a modern design. Because of the wireless communication with a frequency of 868 MHz the controller can be easily integrated in heating systems such as evohome to control the room temperature.

  • Page 2: Device Overview

    Radio signal display 3. Device overview Display Meaning Operating elements and display Field strength excellent Field strength good Field strength weak 4. Mounting Ready to operate in three steps: • Insert batteries and set language • Establish radio connection 1 Adjustment dial •...
  • Page 3 Binding must first be activated at the HR92 so that the radio signal can be received. Subsequently binding has to be activated at the central operating device. Please read the operating instructions of your central 1.

  • Page 4: Radio Test

    (flashing) in the display. device. HR92 receives the data from the central operating device. Synchronization can take up to 4 minutes until the current room setpoint temperature is displayed at the checking HR92.
  • Page 5 Braukmann, during radio communication. MNG, Heimeier, Oventrop valves • The room setpoint temperature of the HR92 radiator M30 x 1.5 controller is changed automatically to 20 °C. fRestore radio communication to the central operating Danfoss RA Supplied device, see Section 7.

  • Page 6: Mounting The Radiator Controller

    Mounting the valve baseplate 3. Lock the radiator controller in the end position. To do so, push the slide towards cycl After approx. 1 minute (self-test) is displayed. Afterwards the radiator controller changes to normal operation. °C 1. Separate the valve baseplate from the radiator The radiator controller only operates if it is locked correctly in the end position.

  • Page 7: Cable Connection

    Connecting an external window contact The floating external window contacts HCA30 can be The radiator controller and the batteries can be connected to the HR92 radiator controller. secured against removal by using the supplied screws. The cable ACS90 is required to connect the external window contact.

  • Page 8: Changing Parameters

    5. Basic settings Set- Par. Meaning ting Battery type Overview Alkaline Lithium If required, the 12 basic settings (parameters) can be NiMH (rechargeable batteries) adjusted. Display of the valve position * Factory settings have a grey background. No display of the valve position Parameters marked with an * are described in more Momentary display of the valve position detail below.

  • Page 9: Further Functions

    Description of the parameters Parameter 10 – Display of the valve position When this parameter is activated (setting "1"), the calculated valve position (0 ... 100% opened) is Parameter 2 – Backlight displayed momentarily. The display has a backlight for reading the information. The main display is shown again after approx.

  • Page 10: Window Function

    You can also open the radiator valve beforehand by are flashing HR92 and the central turning the adjustment dial. operating device (radio The sensitivity of the radiator controller to a temperature test). drop or temperature rise can be set, see Section 5, Repeat the binding Parameters 3 to 5.

  • Page 11: Emergency Operation When Batteries Are Flat

    The binding is retained. HR92UK 10. Declaration of Conformity Type IP30 Protection class Hereby Honeywell Home es that this HR92UK is in Radio communication SRD (868.0 ... 870.0 MHz) ntial requirements and other compliance with the ess RX Class 2 relevant provisions of Di ective 1999/5/EC.
  • Page 12 * Only at operating devices with 2-way communication, e.g. evotouch. Ademco 1 GmbH @2020 Resideo Technologies, Inc. All Hardhofweg 40 rights reserved. The Honeywell Home 74821 Mosbach trademark is used under license from Phone: +49 1801 466 388 Honeywell International Inc. This info.de@resideo.com...
