Frigidaire PLHS239ZC Factory Parts Catalog

Frigidaire PLHS239ZC Factory Parts Catalog

Side by side refrigerator
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
PRODUCT NO.
BASE MODEL NO.
PLHS239ZCB0
PLHS239ZC
MARKET
North America
ENERGY GUIDE - 240592241
OWNER'S GUIDE - # 240389311
SERVICE DATA SHEET - #240389610
ELECTROLUX HOME PRODUCTS, INC.
P.O. BOX 212378, Augusta, GA 30917
SERIES
COLOR
R134a Gallery
stain/blk
Publication No.
5995391421
030604
-EN/SERVICE /DCS
357
PARTS CATALO
VOLTS
115
SIDE BY SIDE
REFRIGERATOR
Model No.
PLHS239ZC
©2003 Electrolux Home Products, Inc.
All rights reserved
FACTORY
G

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PLHS239ZC and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Frigidaire PLHS239ZC

Summary of Contents for Frigidaire PLHS239ZC

  • Page 1 PRODUCT NO. BASE MODEL NO. PLHS239ZCB0 PLHS239ZC MARKET North America ENERGY GUIDE - 240592241 OWNER’S GUIDE - # 240389311 SERVICE DATA SHEET - #240389610 ELECTROLUX HOME PRODUCTS, INC. P.O. BOX 212378, Augusta, GA 30917 SERIES COLOR R134a Gallery stain/blk SIDE BY SIDE REFRIGERATOR Publication No.

  • Page 2: Freezer Door

    Publication No. PLHS239ZCB0 5995391421 FREEZER DOOR 06/03...
  • Page 3 POS. NO # = Fast-moving Parts * = Non-Illustrated Parts PLHS239ZCB0 FREEZER DOOR PART NO DESCRIPTION 240390608 Gasket-frzr door,black ,magnetic 240367302 Bin-door,frzr-upper 240359002 Bin-door 240358402 Bin-door,frzr-dispenser 240554226 Door-frzr,stainless steel ,complete assy 240581906 Door Stop,black ,frzr 240536801 Handle-door,stainless steel ,with insert 5308016566 Screw,hex washer head ,8-15A x 0.625 ,low profile 240328202...

  • Page 4: Refrigerator Door

    Publication No. PLHS239ZCB0 5995391421 REFRIGERATOR DOOR 06/03...
  • Page 5 POS. NO # = Fast-moving Parts * = Non-Illustrated Parts PLHS239ZCB0 REFRIGERATOR DOOR PART NO DESCRIPTION 240390607 Gasket-refr door,black ,magnetic 240363702 Bin-door,2-liter 240338303 Door,dairy ,clear 240558801 Nameplate,aluminum 240581905 Door Stop,black ,ref 240451979 Door-refr,stainless steel ,complete assy 240536801 Handle-door,stainless steel ,with insert 5308016566 Screw,hex washer head ,8-15A x 0.625 ,low profile...
  • Page 6 Publication No. PLHS239ZCB0 5995391421 CABINET 06/03...
  • Page 7 POS. NO 14 # 14A# 66B* 100* # = Fast-moving Parts * = Non-Illustrated Parts PLHS239ZCB0 CABINET PART NO DESCRIPTION 240435901 Cover-air duct 240475901 Cover-evap coil,lower 5303208309 Plug-hole,factory test 240505801 Switch,light/lamp 215486600 Switch-light/lamp 218252200 Screw,#8 truss hd ,10-32CA x 0.500 240457701 Plate-door closer 240402701...
  • Page 8 Publication No. PLHS239ZCB0 5995391421 SHELVES 06/03...
  • Page 9 POS. NO 16A* 42A* 42A* 140A # = Fast-moving Parts * = Non-Illustrated Parts PLHS239ZCB0 SHELVES PART NO DESCRIPTION 240434603 Trim-basket 240350648 Shelf-freezer,glass ,lower 240350647 Shelf-freezer,glass ,upper 240588001 Light Bulb 240436702 Light Bulb/Lamp,A-15 ,clear ,40 W ,120 V,miniature 240590401 Socket-light 218906801 Socket-light/lamp 240587702...
  • Page 10 Publication No. PLHS239ZCB0 5995391421 CONTROLS 06/03...
  • Page 11 POS. NO 13 # 139* 199* # = Fast-moving Parts * = Non-Illustrated Parts PLHS239ZCB0 CONTROLS PART NO DESCRIPTION 5308000010 Fan Blade,red ,evaporator fan 5300157666 Bushing-motor mtg,(2) 5303292396 Bracket-motor mtg,front 240315802 Motor-evap fan 215474201 Washer,"slinger" ,nylon ,evap fan shaft 5303292397 Bracket-motor mtg,rear 240436702 Light Bulb/Lamp,A-15 ,clear ,40 W ,120 V,miniature...
  • Page 12 Publication No. PLHS239ZCB0 5995391421 SYSTEM 06/03...
  • Page 13 POS. NO 14 # 15 # 29 # 30 # 55 # 60 # 61 # # = Fast-moving Parts * = Non-Illustrated Parts PLHS239ZCB0 SYSTEM PART NO DESCRIPTION 240333602 Condenser 218679606 Block-evap coil,styrofoam ,(2) 218944001 Drier-filter,R134a System 240346402 Harness-wiring,machine compt 240439901 Wiring Harness,controls 240449601...
  • Page 14 Publication No. PLHS239ZCB0 5995391421 DISPENSER 06/03...
  • Page 15 POS. NO 38A# 38C* # = Fast-moving Parts * = Non-Illustrated Parts PLHS239ZCB0 DISPENSER PART NO DESCRIPTION 218976409 Tube-water 218976901 Tube-water inlet,inlet valve ,to ice maker 218976903 Tube-water inlet,inlet valve ,to filter 218976907 Tube-water inlet,valve to door 5304422012 Cover-module,black 5304433616 Module-dispenser 5304426649 Spring-torsion...

  • Page 16: Ice Container

    Publication No. PLHS239ZCB0 5995391421 ICE CONTAINER 06/03...
  • Page 17 POS. NO 18 # 45 # # = Fast-moving Parts * = Non-Illustrated Parts PLHS239ZCB0 ICE CONTAINER PART NO DESCRIPTION 5304428402 Auger-ice 5304404343 Cam-drive 218815300 Container-ice,bucket only 5304404346 Drum-ice disp 5304422805 Front-ice container 5304404337 Bar-drive 5304404359 Gate 5303001179 Light Bulb/Lamp,40 W 5303289050 Socket-light/lamp 5304404345...

  • Page 18: Ice Maker

    Publication No. PLHS239ZCB0 5995391421 ICE MAKER 06/03...
  • Page 19 POS. NO 11 # 12 # 13 # 15 # 17 # 55 # # = Fast-moving Parts * = Non-Illustrated Parts PLHS239ZCB0 ICE MAKER PART NO DESCRIPTION 218976409 Tube-water 218976901 Tube-water inlet,inlet valve ,to ice maker 218976903 Tube-water inlet,inlet valve ,to filter 218976907 Tube-water inlet,valve to door 240561701...

  • Page 20: Wiring Schematic

    Publication No. PLHS239ZCB0 5995391421 WIRING SCHEMATIC 06/03...

  • Page 21: Wiring Diagram

    PLHS239ZCB0 Publication No. 5995391421 WIRING DIAGRAM # = Fast-moving Parts 06/03 * = Non-Illustrated Parts...
