Sminn BOX M GSM DOMO Instruction Manual

OPERATION

When a call or SMS is received from a registered number, as long as it is not blocked, it will
activate the corresponding relay. It can operate in three modes:
-IMPULSIVE: on the K4 relay with a missed call.
-IMPULSIVE / BISTABLE: on K1, K2, K3 or K4 relays via SMS.
-CONFIGURATION: also via SMS.

USER STORAGE

Each device allows storing up to 35 phone numbers as described:
-MANUALLY: Calling from the phone number you want to register while you hold the PROG
button(see Fig. 2-5).
-SMS: Sending an SMS with a specific format from the Manager/MASTER phone. The first
number to be manually stored will be the system manager.
The manager can send SMS to REGISTER, UNREGISTER, BLOCK, UNBLOCK and REPLACE
users' numbers, as well as send configuration messages.

IMPULSIVE OPERATION MODE

When receiving a call from a registered phone which is not blocked, the receiver activates the
K4 relay for 1 sec. and hangs up the call.
This mode is useful for garage gates, electronic locks, etc.

SMS OPERATION MODE

When receiving an SMS with a specific format from a non blocked registered phone in the
memory the receiver does the requested operation and gives a missed call.
The receiver understands the following commands:
Requesting state.
With the order #STATUS#, the system sends an SMS where it tells the state of all relays
(and inputs for the DOMO +).
Relay bistable activation (stays activated until a switch off order)
#RELAY_n#ON#B# - Activate relay 'n' in bistable mode.
#RELAY_n#ON#0# - Activate relay 'n' in bistable mode.
Relay impulsive activation (stays activated the number of seconds indicated by 'y',
between 1 and 99 sec).
#RELAY_n#ON#y# - Activate relay 'n' for 'y' seconds.
Relay deactivation.
#RELAY_n#OFF# - Deactivate relay 'n'.
Note: replace 'n' by the relay number you want to activate/deactivate.
For instance: #RELAY_2#ON#10# : Activate relay 2 for 10 seconds.

CONFIGURATION

Sending configuration messages from Manager/MASTER's phone it is possible to:
-Customize RELAY_n and INP_n names
-Register and unregister users
-Block and unblock users
-Modify the password
The default system password is 0000.
The receiver will send an SMS with the result of the configuration order.
Considering 0000 the system password and XXXXXXXXX the phone number, we can carry out
the following orders:
Register a user: #0000#NEWU#XXXXXXXXX#
If we send an already registered user that is blocked, this order will unblock it.
Replace a user: #0000#REPL#XXXXXXXXX#YYYYYYYYY#
Where XXXXXXXXX is the phone number to be replaced.
Where YYYYYYYYY is the new phone number.
Unregister a user: #0000#DELU#XXXXXXXXX# (Only in HOME version)
Block a user: #0000#BLCK#XXXXXXXXX#
Unblock a user: #0000#UBCK#XXXXXXXXX#
Password modification: #0000#MODP#1234#
Where '0000' is the current password of the installation and '1234' the new one.
Change manager: #0000#NEWM#XXXXXXXXX#YYYYYYYYY#
Where 'XXXXXXXXX' is the manager/MASTER's current phone number.
Where 'YYYYYYYYY' is the manager/MASTER's new phone number.
In this case, to keep the installation working given the case the current MASTER has been
lost or stolen, an SMS sent from any current, non-blocked user is permitted.
Change relay name: #0000#CNFG#RELAY_n#XXXXX#
Where "RELAY_n" is the text we want to change and where XXXXX is the text that replaces
the previous one. Note: the maximum length of the text is 13 characters.
Change input name: #0000#CNFG#INP_n#XXXXX#
Where "INP_n" is the text we want to change and where XXXXX is the text that replaces
the previous one. Note: the maximum length of the text is 13 characters.
Only when the Manager/MASTER sends a configuration SMS, the system answers that the
order has been executed with another SMS. If the format of the SMS is not correct, the
system will indicate so.

ERROR INDICATION

The receiver has visual and acoustic signs to indicate if there is any error.
ERROR Led RUN
SIM card not inserted. ON
Modem does not respond OFF
ON
No MASTER
PASWORD 0000 Slow blinking
Memory error Fast blinking

INSTALLATION

This SMINN device is designed to be easily fixed on a wall using the provided screws and wall
plugs.
Before connecting the device to a power supply make sure the power supply is powered off.
Installation shall be done by specialized personnel using adequate wiring taking into
consideration that devices that are always powered on must have a power off override near
them (like a Miniature Circuit Breaker).
Internal connections shall be done following the indications depicted in the silk screen printing
of the board.
Once the device is programmed and verified, close it using the supplied lid and screws.
SMINN RECEIVERS HAVE AN EXTERNAL LIGHT TO INDICATE WHETHER THE DEVICE IS POWERED ON OR OFF
Note: Reinforced concrete, metallic parts and other radiofrequency devices can substantially
C
BUZZ
Led GSM ON
OFF OFF
OFF
ON
ON Beep when booting up
ON Beep when booting up
Beep when booting up
ON
BOX M GSM DOMO / DOMO+

GSM RECEIVER

INSTRUCTION MANUAL

DESCRIPTION

The SMINN GSM receivers are designed with next generation
electronic components. They support up to 35 users.
User addition is easy and simple whether it is done via GSM
or via the receiver's push button.
They allow activation and deactivation of home automation
and control devices like:
Heating, Air conditioning
Irrigation
Alarms, security and surveillance systems
Pools, spas and tanks
Blinds, awnings, doors and access
Each device is built with high quality components and materials
and the latest technology, complying with current regulations
for use in residential, commercial and light industry installations.
innovative in electronics
