PRODUCT NO.
BASE MODEL NO.
GLHT186TAQ0
GLHT186TA
GLHT186TAQ2
GLHT186TA
GLHT186TAW0
GLHT186TA
GLHT186TAW2
GLHT186TA
MARKET
North America
WIRING DIAGRAM - #240398801
OWNER'S GUIDE - #240400105
SERVICE DATA SHEET - #240379007
ELECTROLUX HOME PRODUCTS NORTH AMERICA
P.O. Box 212378, Augusta, GA 30917
SERIES
COLOR
R134a Gallery
bisque
R134a Gallery
bisque
R134a Gallery
white
R134a Gallery
white
Publication No.
5995359774
011015
-EN/SERVICE/KHB
390
FACTORY
PARTS CATALO
VOLTS
115
115
115
115
TOP MOUNT
REFRIGERATOR
Model No.
GLHT186TA
©2001 White Consolidated Industries, Inc.
All rights reserved
G
Advertisement
Related Manuals for Frigidaire GLHT186TA
Summary of Contents for Frigidaire GLHT186TA
- Page 1 PRODUCT NO. BASE MODEL NO. GLHT186TAQ0 GLHT186TA GLHT186TAQ2 GLHT186TA GLHT186TAW0 GLHT186TA GLHT186TAW2 GLHT186TA MARKET North America WIRING DIAGRAM - #240398801 OWNER’S GUIDE - #240400105 SERVICE DATA SHEET - #240379007 ELECTROLUX HOME PRODUCTS NORTH AMERICA P.O. Box 212378, Augusta, GA 30917...
- Page 2 Publication No. GLHT186TA 5995359774 DOOR 10/01...
- Page 3 A = GLHT186TA (GLHT186TAQ0) B = GLHT186TA (GLHT186TAQ2) C = GLHT186TA (GLHT186TAW0) D = GLHT186TA (GLHT186TAW2) POS. NO # = Fast-moving Parts * = Non-Illustrated Parts GLHT186TA DOOR PART NO DESCRIPTION 240514605 A B C D Gasket-frzr door,white ,magnetic 240514606...
- Page 4 Publication No. GLHT186TA 5995359774 CABINET 10/01...
- Page 5 A = GLHT186TA (GLHT186TAQ0) B = GLHT186TA (GLHT186TAQ2) C = GLHT186TA (GLHT186TAW0) D = GLHT186TA (GLHT186TAW2) POS. NO 13 # 114# # = Fast-moving Parts * = Non-Illustrated Parts GLHT186TA CABINET PART NO DESCRIPTION 240355403 A B C D Cover-fan...
- Page 6 Publication No. GLHT186TA 5995359774 SHELVES 10/01...
- Page 7 A = GLHT186TA (GLHT186TAQ0) B = GLHT186TA (GLHT186TAQ2) C = GLHT186TA (GLHT186TAW0) D = GLHT186TA (GLHT186TAW2) POS. NO 14 # 17*# 21 # 23 # 130* # = Fast-moving Parts * = Non-Illustrated Parts GLHT186TA SHELVES PART NO DESCRIPTION 215667501...
- Page 8 Publication No. GLHT186TA 5995359774 SYSTEM 10/01...
- Page 9 A = GLHT186TA (GLHT186TAQ0) B = GLHT186TA (GLHT186TAQ2) C = GLHT186TA (GLHT186TAW0) D = GLHT186TA (GLHT186TAW2) POS. NO 6* # 6* # 14 # 15 # 21 # 30 # 30 # 55 # 60 # 60 # 61 #...
-
Page 10: Wiring Schematic
Publication No. GLHT186TA 5995359774 WIRING SCHEMATIC 10/01... -
Page 11: Wiring Diagram
GLHT186TA Publication No. 5995359774 WIRING DIAGRAM # = Fast-moving Parts 10/01 * = Non-Illustrated Parts...
