PRODUCT NO.
BASE MODEL NO.
GLHT180SAQ0
GLHT180SA
GLHT180SAW0
GLHT180SA
MARKET
North America
WIRING DIAGRAM - # 240379007
OWNER'S GUIDE - # 240400104
SERVICE DATA SHEET - # 240379007
ELECTROLUX HOME PRODUCTS NORTH AMERICA
P.O. Box 212378, Augusta, GA 30917
SERIES
COLOR
R134a Gallery
bisque
R134a Gallery
white
Publication No.
5995360780
011106
-EN/SERVICE/DS
390
FACTORY
PARTS CATALO
VOLTS
115
115
TOP MOUNT
REFRIGERATOR
Model No.
GLHT180SA
©2001 White Consolidated Industries, Inc.
All rights reserved
G
Advertisement
Related Manuals for Frigidaire GLHT180SA
Summary of Contents for Frigidaire GLHT180SA
- Page 1 PRODUCT NO. BASE MODEL NO. GLHT180SAQ0 GLHT180SA GLHT180SAW0 GLHT180SA MARKET North America WIRING DIAGRAM - # 240379007 OWNER’S GUIDE - # 240400104 SERVICE DATA SHEET - # 240379007 ELECTROLUX HOME PRODUCTS NORTH AMERICA P.O. Box 212378, Augusta, GA 30917 SERIES...
- Page 2 Publication No. GLHT180SA 5995360780 DOOR 11/01...
- Page 3 A = GLHT180SA (GLHT180SAQ0) B = GLHT180SA (GLHT180SAW0) POS. NO 37A* 37A* 37A* # = Fast-moving Parts * = Non-Illustrated Parts GLHT180SA DOOR PART NO DESCRIPTION 240370905 Gasket-frzr door,white ,magnetic 240370906 Gasket-refr door,white ,magnetic 240311502 Support-door rack,2 liter ,RH 240311501...
- Page 4 Publication No. GLHT180SA 5995360780 CABINET 11/01...
- Page 5 A = GLHT180SA (GLHT180SAQ0) B = GLHT180SA (GLHT180SAW0) POS. NO 13 # # = Fast-moving Parts * = Non-Illustrated Parts GLHT180SA CABINET PART NO DESCRIPTION 240355401 Cover-fan 240367001 Knob-damper control 5303001028 Nut,push-on 240367401 Damper-fan cover 5308000010 Fan Blade,red ,evaporator fan...
- Page 6 Publication No. GLHT180SA 5995360780 SHELVES 11/01...
- Page 7 A = GLHT180SA (GLHT180SAQ0) B = GLHT180SA (GLHT180SAW0) POS. NO 14 # 17* # 21 # 23 # # = Fast-moving Parts * = Non-Illustrated Parts GLHT180SA SHELVES PART NO DESCRIPTION 215667501 Tray-ice,plastic 240358002 Shelf-freezer,full width 5303299664 Spacer-shelf 240362502 Diffuser-air,top...
- Page 8 Publication No. GLHT180SA 5995360780 SYSTEM 11/01...
- Page 9 A = GLHT180SA (GLHT180SAQ0) B = GLHT180SA (GLHT180SAW0) POS. NO 6* # 6* # 14 # 15 # 21 # 30 # 55 # 60 # 61 # # = Fast-moving Parts * = Non-Illustrated Parts GLHT180SA SYSTEM PART NO...
-
Page 10: Wiring Schematic
Publication No. GLHT180SA 5995360780 WIRING SCHEMATIC 11/01... -
Page 11: Wiring Diagram
GLHT180SA Publication No. 5995360780 WIRING DIAGRAM # = Fast-moving Parts 11/01 * = Non-Illustrated Parts...
