REFRIGERATOR and FREEZER
BEFORE USE, PLEASE READ AND FOLLOW ALL SAFETY RULES AND OPERATING INSTRUCTIONS.
Write Model and Serial Nos. (on lower left
corner of inside cabinet) here:
Model No.: _______________________
Serial No.: _______________________
FROST-FREE
MODEL NOS.
Refrigerator:
Freezer:
INSTRUCTION MANUAL
ACR45L
ACF33L
Felix Storch, Inc.
ISO 9001:2015 registered
770 Garrison Avenue
Bronx, NY 10474
www.summitappliance.com
Advertisement
Table of Contents
Related Manuals for Summit accucold ACR45L
Summary of Contents for Summit accucold ACR45L
- Page 1 FROST-FREE REFRIGERATOR and FREEZER MODEL NOS. Refrigerator: ACR45L Freezer: ACF33L INSTRUCTION MANUAL BEFORE USE, PLEASE READ AND FOLLOW ALL SAFETY RULES AND OPERATING INSTRUCTIONS. Write Model and Serial Nos. (on lower left Felix Storch, Inc. corner of inside cabinet) here: ISO 9001:2015 registered 770 Garrison Avenue Model No.: _______________________...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Appliance Safety Important Safeguards Location of Parts Installation Instructions Before Using Your Appliance Installation of Your Appliance Electrical Connection Extension Cord Reversing the Door Swing of Your Appliance Installing the Stainless Steel Handle Operating Your Appliance 8-12 Control Panel for ACR45L Control Panel for ACF33L 9-10... -
Page 3: Appliance Safety
APPLIANCE SAFETY Your safety and the safety of others are very important. We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety messages. This is the Safety Alert Symbol. The symbol alerts you to potential hazards that can kill or injure you and others. - Page 4 In the event of any damage: - Avoid open flames and anything that creates a spark, - Disconnect from the power supply, - Air the room in which the appliance is located for several minutes, and - Contact the Service Department for advice. The more coolant there is in an appliance, the larger the room it should be installed in.
-
Page 5: Location Of Parts
LOCATION OF PARTS MODEL ACR45L – FROST-FREE REFRIGERATOR MODEL ACF33L – FROST-FREE FREEZER... -
Page 6: Installation Instructions
INSTALLATION INSTRUCTIONS BEFORE USING YOUR APPLIANCE Remove the exterior and interior packing. Before connecting the appliance to the power source, let it stand upright for approximately 2 hours. This will reduce the possibility of a malfunction in the cooling system from handling during transportation. Clean the interior surface with lukewarm water using a soft cloth. -
Page 7: Extension Cord
appliance by pulling on the power cord. Always grip the plug firmly and pull straight out from the receptacle. Repair or replace immediately all power cords that have become frayed or otherwise damaged. Do not use a cord that shows cracks or abrasion damage along its length or at either end. When moving the appliance, be careful not to damage the power cord. -
Page 8: Installing The Stainless Steel Handle
INSTALLING THE HANDLE This appliance includes a handle that is not required to operate the unit. To install the handle, follow the instructions below: 1. Use a screwdriver to remove the screws on the side of door where the handle is to be installed. 2. -
Page 9: Control Panel For Acf33L
Setting the Temperature Control You can set the temperature by pressing the UP and DOWN symbols. When you press either of the two buttons for the first time, the LED readout will show the original temperature set previously. (The temperature preset at the factory is 39°F or 4°C.) The temperature you are setting will increase by one degree each time you press the UP symbol, and will decrease by one degree each time you press the DOWN symbol. -
Page 10: Temperature Memory Function
from Fahrenheit to Celsius or from Celsius to Fahrenheit, press and hold the SUPERFREEZE key for 5 seconds. Setting the Temperature Control You can set the temperature by pressing the UP and DOWN keys. When you press either of the two keys for the first time, the LED readout will show the original temperature set previously. -
Page 11: Door Alarm
DOOR ALARM If the door has been left open for more than 60 seconds, the alarm will sound. Pressing the POWER key once or closing the door can switch off the audible alarm. DOOR LOCK Your unit is provided with a lock and key combination. The keys are located inside the plastic bag that contains the Instruction Manual. - Page 12 Function of Controls MODE/RESET Key: Press ONCE to reset Max/Min temperature record. When the unit is sounding an alarm, press ONCE to turn off the beeping sound. HI/LO Key: Press ONCE to display high alarm setting. Press TWICE to display low alarm setting. Press THREE TIMES to display current temperature reading.
-
Page 13: Care And Maintenance
CARE AND MAINTENANCE CLEANING YOUR APPLIANCE Turn off the power, unplug the appliance, and remove all items, including shelves. Wash the inside surfaces with a solution of warm water and baking soda (about 2 tablespoons of baking soda to a quart of water). Wash the shelves with a mild detergent solution. -
Page 14: How To Remove The Thermometer / Alarm
HOW TO REMOVE THE THERMOMETER / ALARM If you need to disconnect the thermometer / alarm, please follow these steps: 1. Gently pull out the Thermometer / Alarm (1) and then disconnect it from the temperature sensor cable. (Fig. 1) 2. -
Page 15: Troubleshooting
TROUBLESHOOTING You can solve many common problems easily, saving you the cost of a possible service call. Try the suggestions below to see if you can solve the problem before calling the servicer. PROBLEM POSSIBLE CAUSE REMEDY Appliance is not connected to a power Connect the appliance. - Page 16 “E1”. “E2”, for 3-zone models. “E3”, “E4”, “E1” or “E2” indicates that the air “E5” or “E7”. temperature sensor has failed. “E3” or “E4”indicates that the defrost sensor in the evaporator has failed. “E5” indicates a defrost heater failure. “E7” indicates a door switch failure. Has the appliance door been open for If yes, close the door.
- Page 17 NOTES...
- Page 18 NOTES...
- Page 19 NOTES...
-
Page 20: Limited Warranty
LIMITED WARRANTY ONE-YEAR LIMITED WARRANTY Within the 48 contiguous United States, for one year from the date of purchase, when this appliance is operated and maintained according to instructions attached to or furnished with the product, warrantor will pay for factory-specified parts and repair labor to correct defects in materials or workmanship. Service must be provided by a designated service company.
