ALL SAFETY RULES AND OPERATING INSTRUCTIONS
Write Model & Serial No. here:
Model: ______________________
Ser.No:______________________
MEDICAL FREEZERS
VT65M and VT65ML series
CM405
(including BI and ADA models),
ALF620, ALF620BI,
ALF620L and ALFB621
Instruction Manual
BEFORE USE, PLEASE READ AND FOLLOW
CM411L
CM421BL
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Summit Accucold ALF620
Summary of Contents for Summit Accucold ALF620
- Page 1 MEDICAL FREEZERS VT65M and VT65ML series Models CM405 (including BI and ADA models), CM411L ALF620, ALF620BI, CM421BL ALF620L and ALFB621 Instruction Manual BEFORE USE, PLEASE READ AND FOLLOW ALL SAFETY RULES AND OPERATING INSTRUCTIONS Write Model & Serial No. here: Model: ______________________ Ser.No:______________________...
-
Page 2: Important Safeguards
IMPORTANT SAFEGUARDS Your safety and the safety of others are very important. We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety messages. This is the Safety Alert Symbol. This symbol alerts you to potential hazards that can kill or injure you and others. - Page 3 • Use two or more people to move and install the freezer. Failure to do so can result in back or other injury. • To ensure proper ventilation for your freezer, the front of the unit must be completely ° °...
-
Page 4: Table Of Contents
Table of Contents Important Safeguards ..................... 1 - 2 Location of Parts ......................4 Technical Information ....................5 Installation Instructions ..................6 - 9 Before Using Your Freezer ................. 6 Installing the Freezer ..................6 Electrical Connection ..................6 – 7 Extension Cord .................... -
Page 5: Location Of Parts
Location of Parts Manual thermostat (ADA and ALF models have a digital thermostat on the kick plate) Indicator lights: Compressor on (yellow) Temperature alert (red) Removable drawers Door Kick plate (front ventilation Fixed slots) shelves Defrost water outlet Leveling legs NOTE: Models VT65ML and ALF620L have a lock located on the front of the door. -
Page 6: Technical Information
Technical Information VT65MADA VT65M VT65MBI VT65MLADA Model Number VT65ML ALF620BI VT65MLBI ALF620, ALF620L, (with lock) ALFB621 Color White Capacity 3.5 cu. ft. Electrical Input 115V AC/60Hz Rated Current 1.3A Coldest Internal -25°C Temperature Refrigerant R134a, 2.7 oz. Built-in or Built-in or Installation Free-standing Free-standing... -
Page 7: Installation Instructions
Installation Instructions Before Using Your Freezer • Remove the exterior and interior packing. • Check to be sure you have all of the following parts: 3 drawers 1 short drain tube 2 keys (VT65ML and ALF620L models only) •... -
Page 8: Extension Cord
This unit should be properly grounded for your safety. The power cord of this unit is equipped with a three-prong plug that mates with a standard three-prong wall outlet to minimize the possibility of electrical shock. Do not under any circumstances cut or remove the third ground prong from the power cord supplied. -
Page 9: Reversing The Door Swing
Reversing the Door Swing Your freezer can be opened from either the right side or the left. By default, the door hinge is on the right side. If you prefer it on the left, please follow the appropriate instructions below: NOTE: All of the parts that are removed must be kept for the reinstallation of the door. -
Page 10: Door Handle Installation
For Models VT65MADA, VT65MLADA, ALF620/L, ALF620BI and ALFB621 1. Take off the upper hinge cover from the door and remove the screws that hold the top hinge. 2. Lift the hinge straight up to free the hinge pin from the socket in the top of the door. 3. -
Page 11: Operating Your Freezer
Operating Your Freezer NOTE: If the unit is unplugged, has lost power, or is turned off, you must wait 3 to 5 minutes before restarting the unit. If you attempt to restart before this time delay, the freezer will not start. Temperature Control for models VT65M, VT65ML, VT65MBI and VT65MLBI •... -
Page 12: Temperature Control For Ada Models And Models Alf620, Alf620Bi, Alf620L And Alfb621
Switching on the Empty Freezer Plug in the freezer and set the thermostat to the super position (continuous operation). (The red and yellow control lights are on.) When the red light goes off, set the thermostat for normal operation. Wait a couple of hours, then load the freezer. -
Page 13: Storing Frozen Items
Storing Frozen Items Frozen items may be stored in the three drawers, or can be placed directly on the cooling shelves if one or more of the drawers is removed. Defrosting Your Freezer For the most efficient operation and minimum energy consumption, defrost the freezer when the frost on the freezer walls reaches 1/8 to 1/4 inch in thickness. -
Page 14: Care And Maintenance
Care and Maintenance Cleaning Your Freezer: CAUTION : Failure to unplug the unit before cleaning can result in electrical shock or personal injury. Unplug the freezer and remove the frozen items and drawers. Wash the inside surfaces with a solution of lukewarm water and vinegar. Wipe dry with a clean, soft cloth. -
Page 15: Troubleshooting
Troubleshooting When using the freezer, you may come across some problems that in many cases result from improper handling of the appliance and can easily be eliminated. TROUBLESHOOTING GUIDE The appliance fails to operate after being connected to the power source. •... -
Page 16: Limited Warranty
Limited Warranty ONE-YEAR LIMITED WARRANTY Within the 48 contiguous United States, for one year from the date of purchase, when this appliance is operated and maintained according to instructions attached to or furnished with the product, warrantor will pay for factory-specified parts and repair labor to correct defects in materials or workmanship. Service must be provided by a designated service company.
