Summary of Contents for Visual Vibes ViVi

  • Page 1 Quick Start Guide...
  • Page 2 SAFETY Only plug 5 Volt power into ViVi. 12V will damage ViVi! ViVi is not designed for outdoor use. Do not expose this unit to rain or moisture. Install in locations that are safe from liquid spills. Do not operate with any connectors, cables, or LEDs that are damaged.

  • Page 3: What's Included

    WHAT’S INCLUDED: ViVi Controller 3.5mm AUX Audio 3.5mm Aux Audio Cable, Splitter Cable male-to-male, 3 meters LED Strip 5ft (1.5m) LED Strip Adapter Cables Extension Cables USB-to-Barrel Plug Cable External 3.5mm For portable use only Wired Microphone Note: Four Strip Kit also includes (4) LED Strips, (1) 5V Power Supply,...
  • Page 4 Use the LED strip adapter and extension cables to connect your ViVi unit to your LED strips. LED Strip Extension Cable LED Strip Adapter Cable Dev. Port Bass Treble Mids LED Strips...
  • Page 5 Connect your audio device into the 3.5mm AUDIO port, use the included audio splitter to connect to both ViVi and your speakers. OR use the included microphone to detect sound instead. 3.5mm Aux Audio Cable (or use microphone) Sound System 3.5mm Aux Audio...
  • Page 6 Getting Audio to ViVi. Audio Source (e.g. phone) Bluetooth Sound system streaming to sound Receiver Setup has Aux port? system via bluetooth? Mic Setup Audio Source has Aux port? Aux/Line-in Sound system Setup has Aux port? Have Aux dongle or adapter for...
  • Page 7 Choose your audio setup. Aux/Line-in Setup Bluetooth Receiver Mic Setup (Recommended) Setup 3.5mm Aux 3.5mm Aux Audio Cable Audio Cable External Wired Microphone 3.5mm Aux 3.5mm Aux Audio Audio Sound System Sound System Splitter Splitter (speakers) (speakers) Cable Cable Bluetooth Receiver Sound System (speakers)
  • Page 8 Plug in Power from a 5 Volt power supply. 5V DC Power Supply...
  • Page 9 Play your music and watch it come to light automatically! You're good to go! Sit back, relax, and enjoy the show with ViVi's default settings. To adjust and customize light show settings, follow steps on next page.
  • Page 10 Download “ViVi VibeLink” app via App Store/Google Play Store or scan the QR code below. Apple Store Google Play Store...
  • Page 11 In the app, under Setup, adjust strip length for each output (BASS, MIDS, TREBLE). The app will light an LED in the beginning, middle, and end of the strip to assist you with setting the correct number of LEDs. The default length setting for each output is 120 LEDs. Each strip contains 150 LEDs, so to utilize the entire strip the length will need to be adjusted from 120 to 150 for each output.

  • Page 12: Default Settings

    DEFAULT SETTINGS These are our favorite settings. Frequency Auto-Anim. Output Animation Color Mode Range Change Continuous Scale LED 1 Bass Fade Slow Brightness Occasional LED 2 Mids Lasers Quick Change Section Change Every LED 3 Treble Flash Beat For animations, a maximum of 300 LEDs can be controlled per output. It is possible to control more than 300 LEDs by mirroring LED strips through the use of splitters.

  • Page 13: Power Supply Guidelines

    POWER SUPPLY GUIDELINES ViVi can pass through a maximum of 5 amps of continuous current. If this is exceeded, a protective circut shuts down the controller and any lit LEDs turn red and the animation will freeze. Use these guidelines to stay within the limit. If you want a setup that exceeds the limit, you can attach more power directly to the LED strips;...

  • Page 14: Troubleshooting

    TROUBLESHOOTING Problem Possible Causes Solution Reduce brightness to reduce power draw. To reset ViVi unplug the power, wait 30 Animation Stops, Too Much Power Draw seconds, and plug back in. Unplug LED LEDs Turn Red Through ViVi strips if ViVi crashes before you can change brightness in the app.

  • Page 15: Year Limited Warranty

    . No accessories should be shipped with the product. If any accessories are shipped with the product, Visual Vibes shall have no liability whatsoever for loss of or damage to any such accessories, nor for the safe return thereof.
  • Page 16 If you have any issues or questions, send an email to support@visualvibes.io to receive personal support from the Visual Vibes team. Tips, Troubleshooting, FAQs, and more detailed information is available at VisualVibes.io...
