Anviz FaceDeep 5 Quick Manual page 4

Height
Suggested installation height (the distance between the lens and the ground) is 1.4m, as the
recognizable body height range, 0.5m distance away from the device, is 1.3m-1.7m; the
recognizable body height range, 1m distance away from the device, is 1m-2m. (There are some
deviations)
Steps
1
Keep the mounting bracket parallel with the ground and 1.2m distance to the
ground. Drill 2 screw holes on the wall according to the rmounting bracket ,
2
Please punch out the tail lines from the outlet hole before installing the
mounting bracket and use the screws to fix the mounting bracket on the wall.
Use the screwdriver to tighten thescrew follow the direction indicated, to
complete the installation.
120cm
Floor
Fig.(1) Installation Position
Expansion Pipe
Screw Hole
Screw Hole
145cm 200cm
50cm
>100cm
1
Outlet Hole D=
Drill outlet hole for device wiring
Trapezoidal
Screw Hole
Trapezoidal
Screw Hole
Screw
/
3
"
5 (40mm)
