Sony DCR-TRV9 Service Manual page 55

VC-206
Ref. No. Part No. Description
< CONNECTOR >
CN201 1-784-995-21 CONNECTOR, BOARD TO BOARD 50P
CN2701 1-573-350-11 CONNECTOR, FFC/FPC 10P
CN3100 1-784-421-11 CONNECTOR, FFC/FPC (ZIF) 27P
CN3103 1-573-351-11 CONNECTOR, FFC/FPC (ZIF) 11P
CN3106 1-784-421-11 CONNECTOR, FFC/FPC (ZIF) 27P
CN9901 1-784-939-11 CONNECTOR, BOARD TO BOARD 60P
CN9902 1-784-681-11 CONNECTOR, BOARD TO BOARD 100P
CN9903 1-750-321-41 CONNECTOR, BOARD TO BOARD 20P
CN9905 1-784-421-11 CONNECTOR, FFC/FPC (ZIF) 27P
CN9907 1-573-936-11 CONNECTOR, FFC/FPC (ZIF) 27P
CN9908 1-764-518-21 CONNECTOR, FFC/FPC (ZIF) 9P
CN9909 1-784-939-11 CONNECTOR, BOARD TO BOARD 60P
CN9910 1-784-420-11 CONNECTOR, FFC/FPC (ZIF) 21P
CN9911 1-778-075-11 CONNECTOR, BOARD TO BOARD 70P
* CN9912 1-695-320-21 PIN, CONNECTOR (1.5MM)(SMD) 2P
< DIODE >
D1900 8-719-055-86 DIODE KV1470TL1-3
D1901 8-719-027-95 DIODE HSM88WK-TL
D1902 8-719-055-86 DIODE KV1470TL1-3
D1903 8-719-027-95 DIODE HSM88WK-TL
D1904 8-719-055-86 DIODE KV1470TL1-3
D2300 8-719-421-27 DIODE MA728-TX
D2301 8-719-056-23 DIODE MA2S111-(K8).SO
D2302 8-719-420-51 DIODE MA729-TX
D2303 8-719-420-51 DIODE MA729-TX
D2304 8-719-056-23 DIODE MA2S111-(K8).SO
D2305 8-719-056-23 DIODE MA2S111-(K8).SO
D2702 8-719-052-27 DIODE 1SS351-TB
D2703 8-719-052-27 DIODE 1SS351-TB
D3102 8-719-056-61 DIODE 015AZ8.2-TPL3
D3103 8-719-062-16 DIODE 01ZA8.2(TPL3)
D6100 8-719-027-95 DIODE HSM88WK-TL
D6101 8-719-055-86 DIODE KV1470TL1-3
D7901 8-719-055-86 DIODE KV1470TL1-3
D9901 8-719-062-16 DIODE 01ZA8.2(TPL3)
D9902 8-719-062-16 DIODE 01ZA8.2(TPL3)
D9903 8-719-062-16 DIODE 01ZA8.2(TPL3)
D9904 8-719-056-61 DIODE 015AZ8.2-TPL3
D9905 8-719-062-16 DIODE 01ZA8.2(TPL3)
D9906 8-719-062-16 DIODE 01ZA8.2(TPL3)
D9930 8-719-062-16 DIODE 01ZA8.2(TPL3)
< FERRITE BEAD >
FB201 1-414-228-11 INDUCTOR CHIP 0UH (TRV9/TRV9E:AEP,UK)
FB201 1-414-445-11 FERRITE
FB202 1-414-228-11 INDUCTOR CHIP 0UH (TRV9/TRV9E:AEP,UK)
FB202 1-414-445-11 FERRITE
FB203 1-414-228-11 INDUCTOR CHIP 0UH (TRV9/TRV9E:AEP,UK)
FB203 1-414-445-11 FERRITE
FB204 1-414-228-11 INDUCTOR CHIP 0UH (TRV9/TRV9E:AEP,UK)
FB204 1-414-445-11 FERRITE
FB205 1-414-226-21 FERRITE
FB205 1-543-955-11 FERRITE
Remarks
(TRV9/TRV9E:EXCEPT AEP,UK)
0UH
0UH
0UH
0UH
0UH
0UH (TRV9/TRV9E:AEP,UK)
6-24
Ref. No. Part No. Description
FB206 1-414-226-21 FERRITE
FB206 1-543-955-11 FERRITE
FB207 1-414-444-11 FERRITE
FB207 1-500-284-21 INDUCTOR CHIP 0UH (TRV9/TRV9E:AEP,UK)
FB208 1-414-228-11 INDUCTOR CHIP 0UH (TRV9/TRV9E:AEP,UK)
FB208 1-414-445-11 FERRITE
FB209 1-414-444-11 FERRITE
FB209 1-500-284-21 INDUCTOR CHIP 0UH (TRV9/TRV9E:AEP,UK)
FB210 1-414-228-11 INDUCTOR CHIP 0UH (TRV9/TRV9E:AEP,UK)
FB210 1-414-445-11 FERRITE
FB1101 1-414-226-21 INDUCTOR CHIP 0UH
FB1600 1-414-226-21 INDUCTOR CHIP 0UH
FB1601 1-414-226-21 INDUCTOR CHIP 0UH
FB2100 1-414-226-21 INDUCTOR CHIP 0UH
FB3100 1-414-226-21 INDUCTOR CHIP 0UH
FB6100 1-414-226-21 INDUCTOR CHIP 0UH
FB9930 1-414-385-11 FERRITE
FB9930 1-500-113-11 FERRITE
FB9931 1-414-385-11 FERRITE
FB9931 1-500-113-11 FERRITE
FB9932 1-414-385-11 FERRITE
FB9932 1-500-113-11 FERRITE
< FILTER >
FL1101 1-233-733-21 FILTER, LOW PASS
FL1102 1-233-732-21 FILTER, BAND PASS (3.58MHz)(TRV9)
FL1102 1-233-735-21 FILTER, BAND PASS (4.43MHZ)(TRV9E)
FL2700 1-411-951-21 DELAY LINE, LC (23NS)
FL2701 1-233-734-21 FILTER, LOW PASS
< IC >
IC202 8-752-386-72 IC CXD2444R-T4
IC203 8-759-462-43 IC AD9800JCSTRL
IC204 8-759-445-93 IC AK6440AM-E2
IC206 8-752-897-30 IC CXP912032-084R-T6
IC207 8-759-497-43 IC CXD8691R-TEB
IC209 8-752-389-54 IC CXD3124R-T6
IC1001 8-752-384-33 IC CXD3121R-T4
IC1002 8-759-523-81 IC TC74VHC08FT(EL)
IC1101 1-801-474-11 IC TGA-D3100HA
IC1102 8-759-082-58 IC TC7W08FU(TE12R)
IC1103 8-752-081-19 IC CXA2008R-T4
IC1104 8-759-522-83 IC uPD6466GS-627-GLG-E2
IC1105 8-759-327-60 IC TC7W125FU-TE12R
IC1600 8-759-488-73 IC ZA4024GFZR
IC1601 1-801-689-11 IC TGA-D3103HA
IC1602 8-759-488-73 IC ZA4024GFZR
IC1700 8-759-433-17 IC uPD482445LG4-B10-9MH-E2-HDC
IC1701 1-801-484-11 IC TGA-uPD82014UB-501-J
IC1900 8-752-378-75 IC CXD3106R
IC1901 8-752-379-31 IC CXD3107R-T6
IC2100 1-803-261-11 IC TGA-P912032-HA-MP2SP
IC2300 8-759-398-90 IC S-81236PG-P7-T1
IC2301 8-759-424-79 IC S-8423YFS-T2
IC2302 8-759-540-86 IC S579C15APZ-TEB
IC2303 8-759-445-93 IC AK6440AM-E2
Remarks
0UH
0UH (TRV9/TRV9E:AEP,UK)
0UH
0UH
0UH
0UH
0UH
0UH (TRV9/TRV9E:AEP,UK)
0UH
0UH (TRV9/TRV9E:AEP,UK)
0UH
0UH (TRV9/TRV9E:AEP,UK)
