Factory Parts Catalog
PRODUCT NO.
BASE MODEL NO.
FRT21HR6AB0
FRT21HR6A
FRT21HR6AB1
FRT21HR6A
FRT21HR6AQ0
FRT21HR6A
FRT21HR6AQ1
FRT21HR6A
FRT21HR6AW0
FRT21HR6A
FRT21HR6AW1
FRT21HR6A
MARKET
North America
WIRING DIAGRAM - # 240379007
OWNER'S GUIDE - # 240400104
SERVICE DATA SHEET - # 240379007
ELECTROLUX HOME PRODUCTS NORTH AMERICA
P.O. Box 212378, Augusta, GA 30917
SERIES
COLOR
R134a
black
R134a
black
R134a
bisque
R134a
bisque
R134a
white
R134a
white
Publication No.
5995360756
011105
-EN/SERVICE/KHB
357
FACTORY
PARTS CATALO
VOLTS
115
115
115
115
115
115
TOP MOUNT
REFRIGERATOR
Model No.
FRT21HR6A
©2001 White Consolidated Industries, Inc.
All rights reserved
G
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Frigidaire FRT21HR6A
Summary of Contents for Frigidaire FRT21HR6A
- Page 1 PRODUCT NO. BASE MODEL NO. FRT21HR6AB0 FRT21HR6A FRT21HR6AB1 FRT21HR6A FRT21HR6AQ0 FRT21HR6A FRT21HR6AQ1 FRT21HR6A FRT21HR6AW0 FRT21HR6A FRT21HR6AW1 FRT21HR6A MARKET North America WIRING DIAGRAM - # 240379007 OWNER’S GUIDE - # 240400104 SERVICE DATA SHEET - # 240379007 ELECTROLUX HOME PRODUCTS NORTH AMERICA P.O.
- Page 2 Publication No. FRT21HR6A 5995360756 DOOR 11/01...
- Page 3 A = FRT21HR6A (FRT21HR6AB0) B = FRT21HR6A (FRT21HR6AB1) C = FRT21HR6A (FRT21HR6AQ0) D = FRT21HR6A (FRT21HR6AQ1) E = FRT21HR6A (FRT21HR6AW0) F = FRT21HR6A (FRT21HR6AW1) POS. NO PART NO 240390705 240514611 240390702 240514607 240390704 240514612 240390701 240514608 240337703 240381303 240381302 240381301...
- Page 4 Publication No. FRT21HR6A 5995360756 CABINET 11/01...
- Page 5 A = FRT21HR6A (FRT21HR6AB0) B = FRT21HR6A (FRT21HR6AB1) C = FRT21HR6A (FRT21HR6AQ0) D = FRT21HR6A (FRT21HR6AQ1) E = FRT21HR6A (FRT21HR6AW0) F = FRT21HR6A (FRT21HR6AW1) POS. NO PART NO 240355402 240367001 5303001028 240367401 5308000010 5300157666 5303292396 240313606 240371303 10*# 240385402 5303208309...
- Page 6 Publication No. FRT21HR6A 5995360756 SHELVES 11/01...
- Page 7 A = FRT21HR6A (FRT21HR6AB0) B = FRT21HR6A (FRT21HR6AB1) C = FRT21HR6A (FRT21HR6AQ0) D = FRT21HR6A (FRT21HR6AQ1) E = FRT21HR6A (FRT21HR6AW0) F = FRT21HR6A (FRT21HR6AW1) POS. NO PART NO 215667501 240358003 5303299664 240380202 240362601 240392601 14 # 240413601 240436701 241500701 240368101...
- Page 8 Publication No. FRT21HR6A 5995360756 SYSTEM 11/01...
- Page 9 A = FRT21HR6A (FRT21HR6AB0) B = FRT21HR6A (FRT21HR6AB1) C = FRT21HR6A (FRT21HR6AQ0) D = FRT21HR6A (FRT21HR6AQ1) E = FRT21HR6A (FRT21HR6AW0) F = FRT21HR6A (FRT21HR6AW1) POS. NO PART NO 240444401 218944001 240375301 240496101 6* # 240375501 6* # 240385402 14 #...
-
Page 10: Wiring Schematic
Publication No. FRT21HR6A 5995360756 WIRING SCHEMATIC 11/01... -
Page 11: Wiring Diagram
FRT21HR6A Publication No. 5995360756 WIRING DIAGRAM # = Fast-moving Parts 11/01 * = Non-Illustrated Parts...
