Frigidaire FRT21H7AS Factory Parts Catalog
  1. Manuals
  2. Brands
  3. Frigidaire Manuals
  4. Refrigerator
  5. FRT21H7AS
  6. Factory parts catalog
Frigidaire FRT21H7AS Factory Parts Catalog

Frigidaire FRT21H7AS Factory Parts Catalog

Top mount refrigerator r134a series
Hide thumbs Also See for FRT21H7AS:

Advertisement

Quick Links

Download this manual
PRODUCT NO.
BASE MODEL NO.
FRT21H7ASB0
FRT21H7AS
MARKET
North America
ENERGY GUIDE LABEL - # 240465001
OWNER'S GUIDE - # 240400105
SERVICE DATA SHEET - # 240379009
SERIES
COLOR
R134a
stain/blk
Publication No.
5995369351
020402
-EN/SERVICE/DCS
357
VOLTS
115
TOP MOUNT
REFRIGERATOR
Model No.
FRT21H7AS

Advertisement

loading
Need help?

Need help?

Do you have a question about the FRT21H7AS and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Frigidaire FRT21H7AS

Summary of Contents for Frigidaire FRT21H7AS

  • Page 1 PRODUCT NO. BASE MODEL NO. FRT21H7ASB0 FRT21H7AS MARKET North America ENERGY GUIDE LABEL - # 240465001 OWNER’S GUIDE - # 240400105 SERVICE DATA SHEET - # 240379009 SERIES COLOR R134a stain/blk TOP MOUNT REFRIGERATOR FRT21H7AS Publication No. 5995369351 020402 -EN/SERVICE/DCS VOLTS Model No.
  • Page 2 DOOR...
  • Page 3 DOOR POS. NO PART NO 240514611 240514612 240338303 240381305 240450323 240416304 240312405 240312406 240494005 240383603 240450428 240339203 240339208 240383401 218252200 240311202 240338101 240338201 240495801 240345506 218490900 DESCRIPTION Gasket-frzr door,black ,magnetic Gasket-refr door,black ,magnetic Door,dairy ,clear Plug-button,gray ,hinge brg hole ,(2) Panel-frzr door,stainless steel, complete assy Label-nameplate,black Door Stop,black ,ref...
  • Page 4 CABINET...
  • Page 5 CABINET POS. NO PART NO 240355404 5308000010 5300157666 5303292396 240313606 240371303 10*# 240385402 5303208309 240366801 240374401 13 # 240369701 218931001 5303292397 240433201 240411901 218252200 215774918 240335501 240314003 240311301 240313803 240336801 240516401 240337603 240313701 240354404 5303001609 5308009759 240315301 240335003 218233300 5303292395 218362500 240516501 5303001343...
  • Page 6 SHELVES...
  • Page 7 SHELVES POS. NO PART NO 215667501 240358003 5303299664 240417802 240362601 240466001 14 # 240505801 240436701 241500701 240407301 17*# 240375501 240360801 21 # 5304421256 240468201 23 # 240375801 5303001259 240355214 240364718 240361201 240361301 240343803 3201150 240530903 240385201 240356501 240365401 240350654 5308016566 240366401 240366602 240366501...
  • Page 8 SYSTEM...
  • Page 9 SYSTEM POS. NO PART NO 240444401 218944001 240496101 6* # 240375501 6* # 240385402 14 # 5303918247 15 # 5303918250 5308000110 240434002 240362301 240362401 21 # 5303918202 240330001 218252200 218513300 240491501 240332602 5303918265 30 # 218721120 240493301 240405201 218897001 5308000039 5303001199 5308016566 55 #...

  • Page 10: Wiring Schematic

    WIRING SCHEMATIC...

  • Page 11: Wiring Diagram

    5995369351 WIRING DIAGRAM...

This manual is also suitable for:

Frt21h7asb0
