Factory Parts Catalog
PRODUCT NO.
BASE MODEL NO.
FRT21HR6AB2
FRT21HR6A
FRT21HR6AQ2
FRT21HR6A
FRT21HR6AW2
FRT21HR6A
MARKET
North America
WIRING DIAGRAM - 240379009
OWNER'S GUIDE - 240400105
SERVICE DATA SHEET - 240379009
P.O. Box 212378, Augusta, GA 30917
SERIES
COLOR
R134a
black
R134a
bisque
R134a
white
Publication No.
5995365987
020214
-EN/SERVICE /MLR
924
FACTORY
PARTS CATALO
VOLTS
115
115
115
TOP MOUNT
REFRIGERATOR
Model No.
FRT21HR6A
All rights reserved
G
Advertisement
Related Manuals for Frigidaire FRT21HR6A
Summary of Contents for Frigidaire FRT21HR6A
- Page 1 FACTORY PARTS CATALO PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS FRT21HR6AB2 FRT21HR6A R134a black FRT21HR6AQ2 FRT21HR6A R134a bisque FRT21HR6AW2 FRT21HR6A R134a white MARKET North America WIRING DIAGRAM - 240379009 OWNER’S GUIDE - 240400105 TOP MOUNT SERVICE DATA SHEET - 240379009 REFRIGERATOR Model No.
- Page 2 Publication No. FRT21HR6A 5995365987 DOOR 02/02...
- Page 3 FRT21HR6A Publication No. 5995365987 DOOR A = FRT21HR6A (FRT21HR6AB2) B = FRT21HR6A (FRT21HR6AQ2) C = FRT21HR6A (FRT21HR6AW2) POS. NO PART NO DESCRIPTION 240514611 A - - Gasket-frzr door,black ,magnetic 240514607 - B C Gasket-frzr door,white ,magnetic 240514612 A - - Gasket-refr door,black ,magnetic 240514608 - B C...
- Page 4 Publication No. FRT21HR6A 5995365987 CABINET 02/02...
- Page 5 FRT21HR6A Publication No. 5995365987 CABINET A = FRT21HR6A (FRT21HR6AB2) B = FRT21HR6A (FRT21HR6AQ2) C = FRT21HR6A (FRT21HR6AW2) POS. NO PART NO DESCRIPTION 240355402 A B C Cover-fan 240367001 A B C Knob-damper control 5303001028 A B C Nut,push-on 240367401 A B C Damper-fan cover 5308000010 A B C...
- Page 6 Publication No. FRT21HR6A 5995365987 SHELVES 02/02...
- Page 7 FRT21HR6A Publication No. 5995365987 SHELVES A = FRT21HR6A (FRT21HR6AB2) B = FRT21HR6A (FRT21HR6AQ2) C = FRT21HR6A (FRT21HR6AW2) POS. NO PART NO DESCRIPTION 215667501 A B C Tray-ice,plastic 240358003 A B C Shelf-freezer 5303299664 A B C Spacer-shelf 240380202 A B C Diffuser-air,top 240362601 A B C...
- Page 8 Publication No. FRT21HR6A 5995365987 SYSTEM 02/02...
- Page 9 FRT21HR6A Publication No. 5995365987 SYSTEM A = FRT21HR6A (FRT21HR6AB2) B = FRT21HR6A (FRT21HR6AQ2) C = FRT21HR6A (FRT21HR6AW2) POS. NO PART NO DESCRIPTION 240444401 A B C Condenser,dynamic 218944001 A B C Drier-filter,R134a System 240496101 A B C Wiring Harness,machine compt ,w/electric cord 6* # 240375501 A B C...
-
Page 10: Wiring Schematic
Publication No. FRT21HR6A 5995365987 WIRING SCHEMATIC 02/02... -
Page 11: Wiring Diagram
FRT21HR6A Publication No. 5995365987 WIRING DIAGRAM # = Fast-moving Parts 02/02 * = Non-Illustrated Parts...
