Frigidaire FRT21H7AS Factory Parts Catalog
Top mount refrigerator r134a series
Hide thumbs
Also See for FRT21H7AS:
- Factory parts catalog (11 pages) ,
- Factory parts catalog (11 pages) ,
- Factory parts catalog (11 pages)
Advertisement
Quick Links
Product No.
Series
Color
Volts
Wiring Diagram
Owner's Guide
Market
Energy Guide
Service Data Sheet
Installation Instructions 240568300
N05L00002.eps N05DCDBBA11.eps N05BBBABD0.eps N05SBBAFC12.eps
N05CAAAAC0.eps
240398801.eps 240398601.eps
ELECTROLUX HOME PRODUCTS, INC.
P.O. Box 212378, Augusta, GA 30917
FRT21H7ASB6 FRT21H7ASB7 FRT21H7ASB8 FRT21H7ASB9 FRT21H7ASK5 FRT21H7ASK6 FRT21H7ASK9
R134a
R134a
R134a
stain/blk RH
stain/blk RH
stain/blk RH
115
115
115
240398801
240398801
240398801
240400111
240400111
240400111
North America
North America
North America
240465001
240465001
240465001
240379014
240379014
240379014
240568300
240568300
Publication No.
5995424677
04/12/16
(EN/SERVICE/DCS)
357
R134a
R134a
R134a
stain/blk RH
stain/blk LH
stain/blk LH
115
115
115
240398801
240398801
240398801
240400112
240400111
240400111
North America
North America
North America
240465001
240465001
240465001
240379014
240379014
240379014
240568300
240568300
240568300
TOP-MOUNT
REFRIGERATOR
Model No.
FRT21H7AS
©
Copyright
All rights reserved.
R134a
stain/blk LH
115
240398801
240400112
North America
240465001
240379014
240568300
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Frigidaire FRT21H7AS
Summary of Contents for Frigidaire FRT21H7AS
- Page 1 Product No. FRT21H7ASB6 FRT21H7ASB7 FRT21H7ASB8 FRT21H7ASB9 FRT21H7ASK5 FRT21H7ASK6 FRT21H7ASK9 Series R134a R134a R134a R134a R134a R134a R134a Color stain/blk RH stain/blk RH stain/blk RH stain/blk RH stain/blk LH stain/blk LH stain/blk LH Volts Wiring Diagram 240398801 240398801 240398801 240398801 240398801 240398801 240398801 Owner's Guide...
- Page 2 Publication No: 5995424677 FRT21H7AS DOOR 21 14B N05DCDBBA11 12/04...
- Page 3 FRT21H7AS Publication No: 5995424677 DOOR Model Index: A FRT21H7AS (FRT21H7ASB6) B FRT21H7AS (FRT21H7ASB7) C FRT21H7AS (FRT21H7ASB8) D FRT21H7AS (FRT21H7ASB9) E FRT21H7AS (FRT21H7ASK5) F FRT21H7AS (FRT21H7ASK6) G FRT21H7AS (FRT21H7ASK9) POS. NO PART NO. DESCRIPTION 240514611 A B C D E F G Gasket, seal, black, frzr door, magnetic 240514612 A B C D E F G...
- Page 4 Publication No: 5995424677 FRT21H7AS CABINET 12/04...
- Page 5 FRT21H7AS Publication No: 5995424677 CABINET Model Index: A FRT21H7AS (FRT21H7ASB6) B FRT21H7AS (FRT21H7ASB7) C FRT21H7AS (FRT21H7ASB8) D FRT21H7AS (FRT21H7ASB9) E FRT21H7AS (FRT21H7ASK5) F FRT21H7AS (FRT21H7ASK6) G FRT21H7AS (FRT21H7ASK9) POS. NO PART NO. DESCRIPTION 240355404 A B C D E F G Cover-fan 5308000010 A B C D E F G...
- Page 6 Publication No: 5995424677 FRT21H7AS SHELVES 12/04...
- Page 7 FRT21H7AS Publication No: 5995424677 SHELVES Model Index: A FRT21H7AS (FRT21H7ASB6) B FRT21H7AS (FRT21H7ASB7) C FRT21H7AS (FRT21H7ASB8) D FRT21H7AS (FRT21H7ASB9) E FRT21H7AS (FRT21H7ASK5) F FRT21H7AS (FRT21H7ASK6) G FRT21H7AS (FRT21H7ASK9) POS. NO PART NO. DESCRIPTION 215667501 A B C D E F G Tray, ice cube, plastic 240358003 A B C D E F G...
- Page 8 Publication No: 5995424677 FRT21H7AS SYSTEM 12/04...
- Page 9 FRT21H7AS Publication No: 5995424677 SYSTEM Model Index: A FRT21H7AS (FRT21H7ASB6) B FRT21H7AS (FRT21H7ASB7) C FRT21H7AS (FRT21H7ASB8) D FRT21H7AS (FRT21H7ASB9) E FRT21H7AS (FRT21H7ASK5) F FRT21H7AS (FRT21H7ASK6) G FRT21H7AS (FRT21H7ASK9) POS. NO PART NO. DESCRIPTION 240444401 A B C D E F G Condenser, dynamic 218944001 A B C D E F G...
-
Page 10: Wiring Schematic
Publication No: 5995424677 FRT21H7AS WIRING SCHEMATIC 12/04... -
Page 11: Wiring Diagram
FRT21H7AS Publication No: 5995424677 WIRING DIAGRAM 12/04 # Functional Parts * Non-Illustrated Parts...
