UP-3GHAT01
Quick Installation Guide
- 1 -
Previous
Page
Next
Page
1
2
3
4
5
Advertisement
Related Manuals for Asus Aaeon UP-3GHAT01
Motherboard ASUS P7H55-M User Manual
(78 pages)
Motherboard Asus UP-895MD Series User Manual
(180 pages)
Motherboard Asus VivoMini UN66 User Manual
(74 pages)
Motherboard Asus AAEON UP Xtreme UP-WHL01 User Manual
Maker board (104 pages)
Motherboard Asus AAEON UP-POE01 User Manual
Up poe hat maker board (21 pages)
Motherboard Asus AAEON UP Xtreme Lite UPX-WHL02 User Manual
Maker board (43 pages)
Motherboard Asus AAEON UP Xtreme i11 User Manual
Maker board (55 pages)
Motherboard Asus AAEON UP Squared Pro User Manual
Maker board (53 pages)
Motherboard Asus Aaeon UP Xtreme UPX-WHL01 User Manual
(105 pages)
Motherboard Asus AAEON UP Squared V2 User Manual
Maker board (50 pages)
Motherboard Asus Aaeon UP 4000 EDGE User Manual
(35 pages)
Motherboard Asus AAEON UP Xtreme i12 User Manual
Maker board (57 pages)
Motherboard Asus AAEON UPX-EDGE-TGL01 User Manual
Maker board system (59 pages)
Motherboard Asus Aaeon UP Squared i12 User Manual
Maker board (51 pages)
Motherboard Asus AAEON UP Xtreme 7100 User Manual
(49 pages)
Motherboard Asus AAEON UP Xtreme 7100 Edge User Manual
Maker board system (35 pages)
Summary of Contents for Asus Aaeon UP-3GHAT01
Page 1
UP-3GHAT01 Quick Installation Guide - 1 -...
Page 2
REVISION HISTORY Comments Revision Date R.0.1 2016/11/22 Initial version R.0.2 2016/11/30 Change P1/JP2: RS-485 TX、RX Select Add COM2 RS-422/485 Pin define R.0.3 2016/12/23 Change P1/JP2: RS-485 Select and Change UP-3GHAT01 Layout - 2 -...
Page 3
Table of Content 1. UP-3GHAT01 Layout………………..…………………………………...…..…….…..……...- 2. Connector, References……………………………………….………….…0 Switch 3. Switch Settings……………………………………………….…………………….…..1 4. Connector Pin Assignments…………………………………..………………..2 - 3 -...
Page 4
1. UP-3GHAT01 Layout - 4 -...
Page 5
Connector, Switch References Connector Index Reference Functional Description Connector Type Designation RS-232/422/485 Select Header 222-97-03GBE1 RS-232/422/485 Select Header 222-97-03GBE1 Wifi pin7 Header 22Y8242-14D10B-01G BT pin4 Header 22N8561-04R10B-01G HAT1 5V IN Header 22N8562-40SA2B-01G USB1 USB 2.0 Header 1204-700-10RM COM1 RS-232/422/485 DB9 Connector 3117-000-09P COM2 RS-232/422/485 Connector...
Page 6
3. Switch Settings 3.1 JP1/JP2: RS-232/422/485 Select Header Functional Description 3-5, 4-6 RS-422 3-5, 2-4 RS-232 (default) 1-3, 2-4 RS-485 www.aaeon.com AAEON Technology Inc. Focus • Agility • Competitiveness...
Page 7
4. Connector Pin Assignments 4.1 CN1: Wifi Header Signal Description Signal Description USB2_WF_TX USB2_WF_TX WF_PWM WF_PWM USB2_WF_DN_L USB2_WF_DN_L USB2_WF_PN_L USB2_WF_PN_L USB2_WF_LED# USB2_WF_LED# 4.2 CN2: BT Header Signal Description BT_PWM USB2_BT_DN_L USB2_BT_PN_L 4.3 HAT1: 5V IN Header www.aaeon.com AAEON Technology Inc. Focus •...
Page 8
Signal Description Signal Description +3.3V HAT_TXD HAT_RXD G_LED Y_LED +3.3V www.aaeon.com AAEON Technology Inc. Focus • Agility • Competitiveness...
Page 9
4.4 USB1: USB 2.0 Header Signal Description USB_VCC USB2_D- USB2_D+ USB_VCC USB2_D- USB2_D+ UART0_RXD UART0_TXD 4.5 COM1: RS-232/422/485 DB9 Connector Signal Description DCDA / RS422TX- / RS485- RXA / RS422TX+ / RS485+ TXA / RS422RX+ DTRA / RS422RX- DSRA RTSA CTSA www.aaeon.com AAEON Technology Inc.
Page 10
4.6 COM2: RS-232/422/485 Connector Signal Description DCDB / RS422TX- / RS485- RXB / RS422TX+ / RS485+ TXB / RS422RX+ DTRB / RS422RX- DSRB RTSB CTSB 4.7 SIM1: SIM Card Connector Signal Description Signal Description P_UIM_PWRF P_UIM_RSTC P_UIM_DATC P_UIM_CLKC P_UIM_VPPC GND_UIM www.aaeon.com AAEON Technology Inc.
Page 11
4.8 MINI1: Mini PCIe Connector Signal Description Signal Description P3V_3G P_UIM_PWR P_UIM_DAT P_UIM_CLK P_UIM_RST P_UIM_VPP 3G_EN 3G_RST P3V_3G USB2_HUB1_P1_DN USB2_HUB1_P1_DP WLAN_LED WLAN_LED WLAN_LED P3V_3G www.aaeon.com AAEON Technology Inc. Focus • Agility • Competitiveness...
Page 12
Mouser Electronics Authorized Distributor Click to View Pricing, Inventory, Delivery & Lifecycle Information: AAEON UP-3GHAT-A20-0001...
This manual is also suitable for:
Aaeon up-3ghat01-a20-0001
