- Page 1 UP Xtreme Lite Maker Board UPX-WHL02 User’s Manual 1 Last Updated: August 21, 2020...
- Page 2 Copyright Notice This document is copyrighted, 2020. All rights are reserved. The original manufacturer reserves the right to make improvements to the products described in this manual at any time without notice. No part of this manual may be reproduced, copied, translated, or transmitted in any form or by any means without the prior written permission of the original manufacturer.
- Page 3 Acknowledgement All other product names or trademarks are properties of their respective owners. Microsoft Windows and Windows 10 are registered trademarks of Microsoft ⚫ Corp. Intel®, Celeron® and Intel Core™ are registered trademarks of Intel ⚫ Corporation ITE is a trademark of Integrated Technology Express, Inc. ⚫...
- Page 4 Packing List Before setting up your product, please make sure the following items have been shipped: Item Quantity UPX-WHL02 If any of these items are missing or damaged, please contact your distributor or sales representative immediately. Preface...
- Page 5 About this Document This User’s Manual contains all the essential information, such as detailed descriptions and explanations on the product’s hardware and software features (if any), its specifications, dimensions, jumper/connector settings/definitions, and driver installation instructions (if any), to facilitate users in setting up their product. Users may refer to the product page at AAEON.com for the latest version of this document.
- Page 6 Safety Precautions Please read the following safety instructions carefully. It is advised that you keep this manual for future references All cautions and warnings on the device should be noted. Make sure the power source matches the power rating of the device. Position the power cord so that people cannot step on it.
- Page 7 If any of the following situations arises, please the contact our service personnel: Damaged power cord or plug Liquid intrusion to the device iii. Exposure to moisture Device is not working as expected or in a manner as described in this manual The device is dropped or damaged Any obvious signs of damage displayed on the device...
- Page 8 FCC Statement This device complies with Part 15 FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received including interference that may cause undesired operation.
- Page 9 China RoHS Requirements (CN) 产品中有毒有害物质或元素名称及含量 AAEON Main Board/ Daughter Board/ Backplane 有毒有害物质或元素 部件名称 铅 汞 镉 六价铬 多溴联苯 多溴二苯醚 (Pb) (Hg) (Cd) (Cr(VI)) (PBB) (PBDE) 印刷电路板 ○ ○ ○ ○ ○ ○ 及其电子组件 外部信号 ○ ○ ○ ○ ○ ○ 连接器及线材...
- Page 10 China RoHS Requirement (EN) Poisonous or Hazardous Substances or Elements in Products AAEON Main Board/ Daughter Board/ Backplane Poisonous or Hazardous Substances or Elements Hexavalent Polybrominated Polybrominated Component Lead Mercury Cadmium Chromium Biphenyls Diphenyl Ethers (Pb) (Hg) (Cd) (Cr(VI)) (PBB) (PBDE) PCB &...
-
Page 11: Table Of Contents
Table of Contents Chapter 1 - Product Specifications..................1 Specifications ......................2 Chapter 2 – Hardware Information ..................4 Dimensions ....................... 5 Jumpers and Connectors ..................6 List of Jumpers and Connectors ................8 2.3.1 Power Button (SW2) ..................9 2.3.2 RTC (CN1) ....................... - Page 12 Introduction ......................24 Installation for Windows 10.................. 24 Installation for Windows IoT Core ..............27 Appendix A – Cables and Connectors ................29 Cables and Connectors ..................30 Preface...
-
Page 13: Chapter 1 - Product Specifications
Chapter 1 Chapter 1 - Product Specifications... -
Page 14: Specifications
Specifications System Processor 8th generation Intel® Core i7/i5/i3/Celeron Processor SoC Graphics Intel® Graphics, GEN 9 RJ45 Ethernet Connector x 2 HDMI/DP STACK Connector x 1 Power Button / LED x 1 Audio Jack (Line out + MIC) x 1 DC connector (Lockable) x 1 10 pin USB2.0 [2 set] x 1 / HSUART x 1 SATA Connector with power connector (5V, GND) x 1... - Page 15 System Expansion M.2 2230 E Key x 1 M.2 2280 M Key x 1 M.2 3042/3052 B Key x 1 40-pin HAT Connector x 1 RTC battery, CR2032 x 1 Power 12V - 24VDC Dimension 122 x 120 mm Memory DDR4 SO-DIMM slot x 1, up to 16GB Storage SATA3 (6Gb/s) x 3:...
-
Page 16: Chapter 2 - Hardware Information
Chapter 2 – Hardware Information Chapter 2... -
Page 17: Dimensions
Dimensions Chapter 2 – Hardware Information... -
Page 18: Jumpers And Connectors
Jumpers and Connectors Top: CN19 CN15 CN14 CN10 CN20 CN24 Chapter 2 – Hardware Information... - Page 19 Bottom: CN16 COM1 COM2 CN13 CN22 CN32 CN33 CN30 SIM1 Chapter 2 – Hardware Information...
-
Page 20: List Of Jumpers And Connectors
List of Jumpers and Connectors Please refer to the table below for all of the board’s jumpers, connectors and switches. Label Function M.2 2230 E Key M.2 2280 M Key SATA Connector SATA Power LAN1 LAN2 CN10 HDMI/DP CN14 USB Type A Connector 1 CN15 USB Type A Connector 1 CN16... -
Page 21: Power Button (Sw2)
2.3.1 Power Button (SW2) Signal Signal PWR_SW#_CTL_R PWR_SW#_CTL_R SW1_LED_P SW1_LED_N 2.3.2 RTC (CN1) Signal RTC_VCC Chapter 2 – Hardware Information... -
Page 22: 2230 E Key (Cn3)
2.3.3 M.2 2230 E Key (CN3) Signal Signal +3.3VAUX_WIFI BT_DP +3.3VAUX_WIFI BT_DM CNV_WR_LANE1_DN CNV_RF_RST# CNV_WR_LANE1_DP CNV_PCMOUT_CLKREQ_R CNV_WR_LANE0_DN CNV_WR_LANE0_DP CNV_WR_CLK_DN CNV_RGI_RSP_R CNV_WR_CLK_DP GPP_F6_CNV_RGI_DT_UAR T0_TXD CNV_BRI_DT_R Chapter 2 – Hardware Information... - Page 23 Signal Signal PCIE_C_TXP10 CNV_BRI_DT PCIE_C_TXN10 PCIE_P10_RX_DP PCIE_P10_RX_DN PCIE_REFCLK5_P1_P PCIE_REFCLK5_P1_N SUS_CLK_CPU WIFI_RST# PCIE_M2_CLKREQ# BT_EN WAKE_M2_N WIFI_EN CNV_WT_LANE1_DN CNV_WT_LANE1_DP CLKIN_XTAL_LCP_R CNV_WT_LANE0_DN CNV_WT_LANE0_DP CNV_WT_CLK_DN 3.3VAUX_WIFI CNV_WT_CLK_DP 3.3VAUX_WIFI Chapter 2 – Hardware Information...
-
Page 24: 2280 M Key (Cn4)
2.3.4 M.2 2280 M Key (CN4) Signal Signal +3.3V SOC_I2C1_SCL PCIE_TXN0 +3.3V SOC_I2C1_SDA PCIE_TXP0 FULL_CARD_PWR_OFF# PCIE_RXN0 PCIE_RXP0 PLT_RST# PCIE_CLKREQ# PCIE_CLK_N WAKE_M2 PCIE_CLK_P Chapter 2 – Hardware Information... -
Page 25: Sata Connector (Cn5)
Signal Signal PCIE_P15_SATA_P1B_RXN PCIE_P15_SATA_P1B_RXP +3.3V +3.3V PCIE_P15_SATA_P1B_TXN +3.3V PCIE_P15_SATA_P1B_TXP VPU_EN 2.3.5 SATA Connector (CN5) Signal Signal SATA_TXP0_C SATA_TXN0_C SATA_RXN0_C SATA_RXP0_C Chapter 2 – Hardware Information... -
Page 26: Sata Power (Cn6)
2.3.6 SATA Power (CN6) Signal Signal +V5S 2.3.7 LAN1/ LAN2 (CN7/CN8) Signal Signal LAN1_TMDI0+ LAN1_TMDI2- LAN1_TMDI0- LAN1_TMDI1- LAN1_TMDI1+ LAN1_TMDI3+ LAN1_TMDI2+ LAN1_TMDI3- Chapter 2 – Hardware Information... -
Page 27: Hdmi/ Dp (Cn10)
2.3.8 HDMI/ DP (CN10) Signal Signal DDI0_TXP_DP_0 DDI0_TXN_DP_0 DDI0_TXP_DP_1 DDI0_TXN_DP_1 DDI0_TXP_DP_2 DDI0_TXN_DP_2 PORT0_CLK+ PORT0_CLK- CONFIG1 CONFIG2 DP_AUX_P DP_AUX_N DDI0_TYPE_C_HPD 3.3V DDI1_TXP_HDMI_0 DDI1_TXN_HDMI_0 DDI1_TXP_HDMI_1 DDI1_TXN_HDMI_1 DDI1_TXP_HDMI_2 DDI1_TXN_HDMI_2 DDI1_CLK+_HDMI DDI1_CLK-_HDMI HDMI1_CEC_D DDC_CLK DDC_DATA DDI1_TYPE_C_HPD Chapter 2 – Hardware Information... -
Page 28: Usb Type A Connector (Cn14/ Cn15)
2.3.9 USB Type A Connector (CN14/ CN15) Signal Signal USB2_D1- USB2_D1+ USB3_RX1- USB3_RX1+ USB3_TX1- USB3_TX1+ USB2_D2- USB2_D2+ USB3_RX2- USB3_RX2+ USB3_TX2- USB3_TX2+ 2.3.10 USB 2.0 1x10P Wafer (CN16) Signal Signal USB2_D1- USB2_D1+ UART_RX UART_TX Chapter 2 – Hardware Information... -
Page 29: Fan (Cn19)
2.3.11 FAN (CN19) Signal Signal VCC_FAN_CPU_CON FAN_TAC_CPU_CON FAN_CTL_CPU_CON 2.3.12 DC Jack (DC: 12~24V) (CN20) Signal DC_IN Chapter 2 – Hardware Information... -
Page 30: Hat 40 (Cn22)
2.3.13 HAT 40 (CN22) Signal Signal +V3.3_HAT +V5_HAT +V3.3_HAT +V5_HAT +V1.8_HAT VIO_3V3OR1V8 +V1.8_HAT ISH_GPIO_0 ISH_GPIO_1 ISH_I2C0_SCL ISH_GPIO_2 ISH_I2C0_SDA ISH_GPIO_3 ISH_GPIO_4 ISH_I2C1_SCL ISH_GPIO_5 ISH_I2C1_SDA ISH_GPIO_6 ISH_GPIO_7 ISH_I2C2_SCL ISH_GPIO_8 ISH_I2C2_SDA ISH_GPIO_9 ISH_GPIO_10 ISH_UART0_TXD ISH_UART0_RXD ISH_SPI_CS0# ISH_SPI_CS1# ISH_UART1_TXD ISH_SPI_CLK ISH_UART1_RXD ISH_SPI_MISO ISH_SPI_MOSI Chapter 2 – Hardware Information... -
Page 31: Audio Jack (Cn24)
2.3.14 Audio Jack (CN24) Signal Signal MIC_LR_CN AGND LOUT_R LOUT_L 2.3.15 M.2 3042/3052 B Key (CN30) Signal Signal +3.3V PCIE_P12_SATA_P1A_RXP +3.3V PCIE_P12_SATA_P1A_RXN FULL_CARD_PWR_OFF# Chapter 2 – Hardware Information... - Page 32 Signal Signal USB_D+ 3GPW_EN USB_D- PCIE_P12_SATA_P1A_TXN PCIE_P12_SATA_P1A_TXP PLT_RST# PCIE_CLKREQ# PCIE_REFCLK2_N WAKE_M2 PCIE_REFCLK2_P PCIE_P5_USB31_P5_RXN WWAN_RESET P_UIM_RST PCIE_P5_USB31_P5_RXP M.2_3052_DET P_UIM_CLK +3.3V P_UIM_DAT +3.3V PCIE_P5_USB31_P5_TXN P_UIM_PWR +3.3V PCIE_P5_USB31_P5_TXP M.2_3052_DEV Chapter 2 – Hardware Information...
-
Page 33: Jumper (Cn32)
2.3.16 5V Jumper (CN32) 1 2 3 A (Default) 2.3.17 3.3V Jumper (CN33) 1 2 3 A (Default) 2.3.18 SIM Card Slot (SIM1) Pin Name Signal Type Signal Level UIM_PWR UIM_RST UIM_CLK UIM_VPP UIM_DATA Chapter 2 – Hardware Information... -
Page 34: Com Port 1/ Port 2 (Com1/Com2)
2.3.19 COM Port 1/ Port 2 (COM1/COM2) Signal DCDA / RS422TX- / RS485- RXA / RS422TX+ / RS485+ TXA / RS422RX+ DTRA / RS422RX- DSRA RTSA CTSA Chapter 2 – Hardware Information... -
Page 35: Chapter 3 - Up Framework Sdk Installation
Chapter 3 Chapter 3 – UP Framework SDK Installation... -
Page 36: Introduction
Introduction This section provides instructions for the installation of the UP Framework SDK. Instructions are provided for Windows 10 and Windows IoT Core. You can download the latest version of UP Framework SDK from the UP community: https://downloads.up-community.org/download/up-sdk-for-windows-10-and-windows-iot/ Installation for Windows 10 Step 1 Locate the downloaded file UpFrameworkSetup.msi and run the installer. - Page 37 Step 2 Select the installation folder. Default destination path is C:\Program Files(x86)\AAEON\ You may also choose to install the UP Framework SDK for all users or only the current user. Press “Next” to continue installation. Step 3 Press “Next” to confirm the installation. Chapter 3 –...
- Page 38 Step 4 Press “Close” to exit once setup is complete. Chapter 3 – UP Framework SDK Installation...
-
Page 39: Installation For Windows Iot Core
Installation for Windows IoT Core Before you begin, make sure you have downloaded and installed the latest version of the Windows IoT Core image from the UP community. Installation requires using a connected PC with the UP Framework SDK software downloaded and saved. - Page 40 Step 2 Download the UP Framework SDK to your PC and unzip the files. Open PowerShell as an Administrator. Run the command RemoteInstallation.ps1 to install the UP Framework SDK. Enter the IP address of the UP IoT Core device when prompted. Chapter 3 –...
-
Page 41: Appendix A - Cables And Connectors
Appendix A Appendix A – Cables and Connectors... -
Page 42: Cables And Connectors
Cables and Connectors This table provides detailed information about the cables and connectors used by the UP Xtreme Lite (UPX-WHL02). If you have any questions about the configuration of your board, please contact your AAEON sales representative. Mating Cable Mating Cable Label Connector PN Description Description... - Page 43 Mating Cable Mating Cable Label Connector PN Description Description CN24 1652708203 AUDIO JACK CN30 1654207536 M.2 B key CN32 165300310G 5V JUMP CN33 165300310G 3.3V JUMP SIM1 1654900800 SIM CARD COM Cable.D-SUB COM1 1655901000 10-pin RS 232 Header 1701100180 9P(M).10P .1.0mm Housing.15cm COM Cable.D-SUB COM2 1655901000...
