Parts List - Beghelli Fortezza Combo RM Instructions

CHARGER BOARD
STANDARD TRIPLE INPUT VERSION
BATTERY+
LAMPS
LAMP +
-
LAMP
FUSE
POS NEG
-
+
BATTERY -
CHARGER PC BOARD
BATTERY
ASSEMBLY

PARTS LIST

1. Torx tamper proof screw 8-32 x 1
2. "O" ring 1/16 wide x 5/32 ID x 9/32 OD
3. Stencil
4. Running man pictogram
5. Frame
6. LED holder
7. LED indicator
8. LED board
9. Socket
10. FTZ combo lens
11. FTZ combo base
3
12. Torx tamper proof screw 8-32-1/2"
13. 8-32 x 1/2 inch oval head screw, Phillips
14. Test switch
15. MR16 holder
16. MR16 lamps
17. FTZ combo cover
18. Backplate
19. Capscrews
20. Switch cover
21. Circuit board
22. Inside mounting plate
28
23. Gasket for canopy to frame sealing
24. Canopy
25. Canopy gasket
26. Mounting base for canopy
27
27. Bushing
28. Octagon box (supplied by others)
26
29. Battery
30. Back plate gasket
25
24
23
Beluce Canada Inc., 3900 14th Avenue, Markham, ON L3R 4R3 Tel: (905) 948-9500 Fax: (905) 948-8673
926000221
D
WHITE - Neutral / Common
BLACK - 120V Line / Hot
RED - 347V Line / Hot
Figure 1
ORANGE - 277V Line / Hot
GREEN - Ground
2
C
1
AC ON
CHARGE
TEST
B
A
Figure 2
19
13
5
22
4
3
6 7
8
9
10
2
4
29
18
28
27
26
25
24
23
14
20
11
17
15
16
12
PART #
19
3
18
30
02/25/2020
18
27
21
