- Page 1 PRODUCT OPERATING MANUAL PANBLAST AIRSTOP REMOTE CONTROL HANDLE Manual Number: ZVP‐PC‐0075‐01 ...
- Page 2 SECTION GENERAL INFORMATION INTRODUCTION INSTALLATION OPERATING INSTRUCTIONS MAINTENANCE TROUBLE SHOOTING GUIDE ASSEMBLIES, PARTS LISTING & EXPLODED VIEW...
- Page 3 1.3.3 Any work performed on electrical wiring or components must only be carried out by It can be used with the PanBlast™ range of suitably qualified registered electrical remote control valve systems such as the UniFlo, trades’...
- Page 4 THIS PROBLEM PROBABLE SOLUTION EQUIPMENT/APPARATUS. Ensure that the “safety” mini ball valve or pet cock on the remote PanBlast™ AirStop Pneumatic Remote control valve has been closed. Control Handle is a spool type plunger valve deadman handle. When the handle lever is in the Open the “safety”...
- Page 5 ASSEMBLIES, PARTS LISTING & EXPLODED VIEW AirStop BSP Pneumatic Control Handle Assembly Stock Code Description Weight BAC-RC-PB-0084 Airstop Pneumatic Control Handle 0.28Kg (0.62lbs) 7.1.1 AirStop BSP Pneumatic Control Handle Parts Listing Item Stock Code Description YAC-RC-PB-0048 Lever YAC-RC-PB-0049 Body YAC-RC-PB-0050 Plunger Plug YAC-RC-PB-0051 Hinge Pin...
- Page 6 7.1.3 AirStop BSP Pneumatic Control Handle Exploded View - 4 -...
- Page 7 AirStop NPT Pneumatic Control Handle Assembly Stock Code Description Weight BAC-RC-PB-0180 Airstop NPT Pneumatic Control Handle 0.25Kg (0.55lbs) 7.2.1 AirStop NPT Pneumatic Control Handle Parts Listing Item Stock Code Description YAC-RC-PB-0048 Lever YAC-RC-PB-0181 Body YAC-RC-PB-0050 Plunger Plug YAC-RC-PB-0051 Hinge Pin YAC-FN-0352-00 Screw YAC-RC-PB-0053...
- Page 8 7.2.3 AirStop NPT Pneumatic Control Handle Exploded View - 6 -...
