- Page 1 PRODUCT OPERATING MANUAL PANBLAST PB1500P PRESSURE CABINET Manual Number: ZVP-PC-0227-00...
-
Page 2: General Information
SECTION GENERAL INFORMATION ASSEMBLY & INSTRUCTIONS OPERATING INSTRUCTIONS MAINTENANCE TROUBLE SHOOTING GUIDE ASSEMBLIES, PARTS LISTING & EXPLODED VIEW BLAST CABINET SERIAL NUMBER:... - Page 3 OF THE SYSTEM THAT MAY CAUSE SERIOUS area that may be exposed to any hazards INJURY OR DEATH. generated by the abrasive blasting process. The PanBlast™ PB1500P Blast Cabinet is a 1.3.2 Suitably approved respiratory protection should freestanding unit, which should be installed in also be worn when handling abrasive media, a dry area, on a flat and level surface.
- Page 4 CONNECTIONS MUST 3.10 Turn on the main power supply, switch on the APPROPRIATE PRESSURE RATING. cabinet light at the switch on the front of the cabinet, and start the dust collector fan by The compressed air supply must also be clean depressing the on green button located on the and dry for the blast cabinet to operate fan starter assembly.
- Page 5 On a daily basis 4.2.5 Open the dust collector inspection door, and visually inspect the filter cartridge for any 4.1.1 All piping, fittings and hoses must be checked damage, wear or excessive dust build up. If the daily for tightness and leakage. filter media is damaged in any way, or there is dust present in the air being discharged from 4.1.2...
- Page 6 seating ring out of the seat. When re-fitting the seating ring, ensure that it is correctly seated within the seating ring housing. - 4 - ZVP-PC-0227-00-R0...
- Page 7 TROUBLE SHOOTING GUIDE Item Problem Possible Cause Corrective Actions Door safety interlock not fully Check that the main cabinet door is engaged filly closed and the interlock is engaged Blasting system will not Door safety interlock faulty Check/repair/replace door interlock operate assembly as required Faulty foot pedal operation...
- Page 8 Description Weight 800 kg (1764 lbs) BEC-CA-0557-00 PB1500P/NZ /AU Pressure Cabinet Assembly 800 kg (1764 lbs) BEC-CA-0556-00 PB1500P/SG Pressure Cabinet Assembly 6.1.1 PANBLAST™ PB1500P Pressure Cabinet Parts Listing Item Stock Code Description BAC-CA-PB-0137 Rectangular Window BAC-CA-PB-0141 Cabinet Window Seal BAC-GL-PB-0003 10"...
- Page 9 6.1.2 PANBLAST™ PB1500P Pressure Cabinet Exploded View - 7 - ZVP-PC-0227-00-R0...
