- Page 1 Kat Klowder A S S E M B LY G U I D E Kat Klowder w/Dual Sliding Doors Kat Klowder w/Dutch Door PN# 908.0000.01 PN# 908.0000.02 Save This Guide For Future Reference PN: 006.9080.01 SEPTEMBER 2019...
- Page 2 INTRODUCTION INTRODUCTION Introduction Thank you for purchasing Shor-Line products. As a leader in animal care equipment, our commitment to provide quality products and personable customer service is the same as it was in 1927. This Guide provides information regarding the installation, use, and care of your Shor-Line product.
-
Page 3: Table Of Contents
Shipment Inventory And Inspection..............4 Shipment Inventory ......................4 Shipment Inspection ......................4 Damage Reporting ......................4 Shor-Line’s Kat Klowder ..................... 4 Sliding Door Model - Component List ................. 5 Dutch Door Model - Component List .................. 7 Kat Klowder Dimensions ....................9 SECTION TWO, SAFE USE PROCEDURES Safe Use Procedures ...................10... -
Page 4: General Information
Refer to the Guide, images and content to assist with the installation of the product. Throughout the Guide, safety notices provide help for a successful installation. The Kat Klowder is also referred to as "unit" in this document. SAFETY FIRST! -
Page 5: Safety Warnings Included In This Guide
Maintain full control of the unit when operating the caster foot operated pedal, which if not avoided, could result in MINOR to MODERATE INJURY. Do NOT attempt to set-up, collapse or move the Kat Klowder with one person; the unit could tip causing personal injury and/or damage to the product could occur. -
Page 6: Safety Decal Locations
The following procedures require two people to safely collapse (fold) the Kat Klowder. Both sides of the unit must be folded simultaneously. Do not attempt to collapse the Kat Klowder while the space is occupied, clear the Kat Klowder of all animals and debris. Fold (up) all perch shelves in their full upright position. -
Page 7: Section One, Pre-Assembly
Keep hands clear of possible pinch areas when moving parts which, if not avoided, could result in MINOR to MODERATE INJURY. Do NOT attempt to set-up, collapse or move the Kat Klowder with one person; the unit could tip causing personal injury and/or damage to the product could occur. -
Page 8: Sliding Door Model - Component List
SECTION ONE Sliding Door Model - Component List SCREW PUSH CLIP FIGURE 1.1 - Sliding Door Kat Klowder (908.0000.01) Item Part Number Description CASTER, w/LOCK NUT DOOR HANDLE, w/LOCK (2 KEYS) 808.0000.02 SHELF ASSEMBLY • 062.3110.05 • SCREW 5/16-18x1.00 BUTTON HEAD •... - Page 9 • WASHER 1/4" FLAT (3ea BOTH ENDS) • 3266 • SELF TAP SCREW • 92196A533 • SCREW, 18-8 SOCKET HEAD CAP MISCELLANEOUS PARTS 064.2500.34 1/4-20 T-NUT, BLACK 25-1961 1/4-20 T-NUT, SILVER 3376 1/4-20 INSERT NUT NOTE 1 - Contact Shor-Line Technical Service Department (1.800.444.1579) Shor-Line.com...
-
Page 10: Dutch Door Model - Component List
SECTION ONE Dutch Door Model - Component List FIGURE 1.2 - Dutch Door Kat Klowder (908.0000.02) Item Part Number Description CASTER, w/LOCK NUT DOOR HANDLE, w/LOCK (2 KEYS) 808.0000.02 SHELF ASSEMBLY • 062.3110.05 • SCREW 5/16-18x1.00 BUTTON HEAD • 062.2503.12 •... - Page 11 • WASHER 1/4" FLAT (3ea BOTH ENDS) • 3266 • SELF TAP SCREW • 92196A533 • SCREW, 18-8 SOCKET HEAD CAP MISCELLANEOUS PARTS 064.2500.34 1/4-20 T-NUT, BLACK 25-1961 1/4-20 T-NUT, SILVER 3376 1/4-20 INSERT NUT NOTE 1 - Contact Shor-Line Technical Service Department (1.800.444.1579) Shor-Line.com...
-
Page 12: Kat Klowder Dimensions
DD = 27 1/2" DD = 27 1/2" CASTER CASTER CASTER ENGAGED DISENGAGED ENGAGED 60" SIDE VIEW SD = 79" SD = 79" DD = 78" DD = 78" CASTER ENGAGED CASTER DISENGAGED FIGURE 1.3 - Kat Klowder Dimensions Shor-Line.com... -
Page 13: Section Two, Safe Use Procedures
Safe Use Procedures Kat Klowder Models Shor-Line's Kat Klowder is available with a sliding door or with a Dutch door. Both models are designed to collapse (fold) into itself to free up floor space when not in use and while moving the unit to different locations. - Page 14 Klowder. Both sides of the unit must unfold simultaneously. The Kat Klowder unfolds like an accordion, but the back panel must be stabilized by resting on the floor. Lowering the unit disengages the back panel casters and will prevent the back panel from moving during the set-up procedures.
- Page 15 The pin rests inside the door frame track, preventing the door panel from sliding in or out during use. STEP 7: Casters - Once the Kat Klowder is in the correct location and is clear of people and obstructions, safely disengage the front panel casters. Collapse Procedures The following procedures require two people to safely collapse (fold) the Kat Klowder.
-
Page 16: Shelf Operation
MINOR to MODERATE INJURY. FIGURE 2.8 - Caster Foot Pedal When the Kat Klowder is left unattended and in the collapsed position, always NOTICE disengage the casters to prevent the unit from unintentional movement. -
Page 17: Section Three, Maintenance And Care Maintenance And Care
Adjust as required. Care Recommendations NOTICE Routine product care will extend the quality and life of Shor-Line products and aids in protecting animals from transmittable diseases and infections. Avoid ammonia-based cleaners that are typically used on glass windows. These chemical cleaners can damage acrylic surfaces, leaving them looking cloudy and dull. -
Page 18: Section Four, Terms & Conditions
Shor-Line. If products are damaged, defective, shorted or appear not to conform to the order, Customer shall discontinue their use and immediately notify the carrier and Shor-Line of such condition and afford a reasonable opportunity to inspect the same. -
Page 19: Limited Warranty
SECTION FOUR Limited Warranty In the event the Customer is not fully satisfied with the quality or workmanship of a product, Shor-Line in its sole discretion may arrange either to credit Customer's account (excluding shipping and handling costs) or replace the product. -
Page 20: Contact Information
Vale of Glamorgan CF71 7PF Kansas City, Kansas 66105, USA United Kingdom PHONE: 800.444.1579 PHONE: +44 1446 77 20 41 LOCAL: 913.281.1500 FAX: +44 1446 77 36 68 FAX: 913.281.5339 EMAIL: quality@shor-line.co.uk EMAIL: guides@shor-line.com WEB ADDRESS: SHOR-LINE.co.uk WEB ADDRESS: SHOR-LINE.com Shor-Line.com …...
